- Page 1 Motion 9200 USER GUIDE...
- Page 2 © 2023 Copyright Careium Sweden AB, Rev E Careium Sweden AB, Jörgen Kocksgatan 1 B, 211 20 Malmö, Sweden Corporate identification number: 556569-9740...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION ........................4 Medical units ........................... 5 Important information ........................5 PACKING CONTENTS .......................... 6 FUNCTIONCAL DESCRIPTION ......................6 Overview............................7 Motion and the basic functions ....................8 9200 A – Motion alarm, basic mode ...................... 9 B –... -
Page 4: Safety Information
SAFETY INFORMATION Always read and follow the safety information accompanied by this symbol. Always test the system according to the instructions before use and always test the • product after adjustments have been made. The device is not always suitable for all users and should not be seen as a substitute •... -
Page 5: Medical Units
All systems using radio and network communication are subject to interference beyond the user’s control. Products from Careium are designed to minimize the impact of such interference. Nevertheless, the user must be aware that system components can be subjected to interference or other influences that may cause malfunction. -
Page 6: Packing Contents
PACKING CONTENTS The packing contains: One Motion including mounted batteries. • Screws for mounting the Motion on a wall, door frame etc. • FUNCTIONCAL DESCRIPTION The Motion is a wireless radio accessory with a built in motion sensor to alarm when motions are detected in the sensor’s detection area. -
Page 7: Overview
Overview Motion sensor Folding stand Indicator lamp Reset button ON/OFF switch Sliding cover Micro-USB... -
Page 8: Motion And The Basic Functions
Motion and the basic functions 9200 By opening the sliding cover to the first position access is given to the function selector with 10 optional setups. Choose position, A-J, depending on how the unit shall be used. Use a suitable screwdriver for setting the knob in correct position. -
Page 9: A - Motion Alarm, Basic Mode
A – Motion alarm, basic mode When the Motion is set to position A, the unit is working as a motion alarm. An alarm is triggered when motions are registered by the motion sensor. B – Motion alarm, inactivity alarm When the Motion is set to position B, the unit is working as an inactivity alarm. -
Page 10: Installation
Motion is used for the first time. Pairing the Motion with a carephone The Motion can be paired to a Careium Carephone as described in the following sections for each selectable mode. The Motion can also be connected to other social alarm systems, please refer to that... -
Page 11: Installation Of Motion
Installation of Motion Place the Motion in the area that shall be overseen and point the motion sensor into the field of interest. Be aware of pointing the sensor in a direction which doesn’t register passing people, this could trigger a false alarm. For a stable mounting, use the supplied screws and attach the unit against the wall, door frame etc. -
Page 12: A - Motion Alarm, Basic Mode
A – Motion alarm, basic mode Turn the function selector to position A and power the Motion unit on. Place the Motion on the floor with the sensor directed towards the area of interest. See the picture for an example. The stabilization of the motion sensor takes about 45 seconds, the indicator lamp is flashing orange during this time. -
Page 13: E - Motion Alarm, On/Off Disabled
2. Activate Motion by making movements in front of the sensor, a melody can be heard from the carephone. 3. Confirm the activation by pressing the red button on the Carephone. A confirmation melody is heard from the Carephone. 4. The units are now connected, make a test alarm by activating the motion sensor to verify the function. -
Page 14: Maintenance
MAINTENANCE Cleaning All accessories from Careium can be cleaned with a slightly damp cloth. Do not use strong detergents or solvents. Battery By opening the sliding cover to the second position, access is given to the batteries. Use only Alkaline AA (LR06) batteries with good quality. -
Page 15: Technical Information
TECHNICAL INFORMATION Motion Article number: 300 155 Dimensions: 110 x 70 x 41/100 mm Power supply: 2x 1.5V LR6/AA Alkaline batteries Duration: Up to 6 months running on batteries Radio frequency: 869,2 MHz Equipment class: Class 1 radio equipment ENVIRONMENT Temperature: +5 to +35 ºC Humidity:... -
Page 16: Environmental Information
The product can be returned free of charge to a recycling station that is connected, directly or via a recycling system, to Careium or to your distributor. For detailed instructions, please check with your distributor or visit our website, www.careium.com...
