SPECIFICATIONS
All specifications and descriptions contained in this document are
verified to be accurate at the time of printing. However, because
continuous improvement is a goal at iCS, we reserve the right to
make product modifications at any time.
Model
Voltage and Wiring
230V AC single-phase: LIVE,
Current and Power
Maximum 32A
Frequency
Internal RCD
Data Protocol
Charging Connector
Buttons
RFID
Display
Network Connectivity
Working Temperature
Storage Temperature
Working Humidity
Dimension (H x W x D)
Backplate Material
Weight
IP Rating
EN 61851-1:2020, EN61851-21-2, EN 61000-3
Certifications
1
ICSW7C
ICSW22C
400V AC three-phase: L1, L2, L3,
Maximum 32A
50-60 Hz
AC 30mA, DC 6mA
OCPP 1.6J
IEC62196 Type-2 socket
1 x Physical Button
ISO 14443 A/B
2.8'' LCD
Ethernet, WLAN, Cellular
-30°C to 50°C
-40°C to 70°C
5% - 95% without condensation
380 x 288 x 141 mm
316 Stainless Steel
5.3Kg
5.4Kg
IP55
PME EARTH FAULT MONITORING
The charger has been developed for installations to meet and comply
with wiring regulations BS7671:2018 including amendment 1:2020.
If installed on a TN-C-S (PME) system, a dedicated earth rod to the
charge point may not be required, as our hardware meets the
requirements of the revised regulation 722.411.4.1 for use of an open
protective earthed-neutral (PEN) detection device. Upon detection of
a fault, charging is stopped and the car isolated from the supply
(including earth ).
SELF-MONITORING AND RECOVERY
The charger will automatically reset after a minor fault such as Over
Voltage Protection (OVP), Under Voltage Protection (UVP), Over
Temperature Protection (OTP) or Over Current Protection (OCP),
with no user intervention required. Resetting of internal RCD or PME
faults can be configured to manual or automatic.
OCPP 1.6J FULL PROFILES & SMART CHARGING SUPPORT
The charger supports OCPP 1.6J full profiles, including the latest
smart charging to manage the load of charging stations with limited
power supply. iCS offer our own OCPP software, contact iCS for more
information.
