Summary of Contents for DIVIN DV5 Series
- Page 1 www.divinwinefridges.com.au...
- Page 2 Thank you very much for choosing DIVIN wine fridge to store your precious collections! We hope you may enjoy using it. Purchase Date: *The purchase date is the date when the warranty begins. Serial Number: *The serial number is located on the data plate, which can be found on the inner wall of the wine fridge.
-
Page 3: General Instructions Before Usage
● Make sure your power supply sources have met all the electrical standards required by laws. DO NOT use extension cords; use an exclusive and properly installed outlet instead. Further assistance from DIVIN Website-Support: https://divinwinefridges.com.au/support/ E-mail: info@divinwinefridges.com.au Tel: 0484 308 208... -
Page 4: Table Of Contents
Table of Contents General Instructions Before Usage.......... Important Safeguards & Warnings........... Installation................The Touch Controls and Operation.......... Temperature Setting & Energy Saving Recommendations..Wine Rack & Bottle Configurations.......... Bottle Capacity................. Care and Maintenance............. Troubleshooting Guide............. Warranty and Terms.............. -
Page 5: Important Safeguards & Warnings
Important Safeguards & Warnings ● All the instructions of this user manual must be read and adhered carefully to ensure safety, proper performance of the product, and the validity of DIVIN’s warranty. ● This wine fridge is designed for commercial and residential indoor environments (excluding garages and other places that can have extreme temperature shifts) only for storing a wide variety of wines. - Page 6 ● When cleaning, DO NOT spray any cleaning chemicals around the front exhaust openings and the back of the appliance. This can avoid damages to the metal pipes that are around the compressor. When damages happen, refrigerant may leak and eventually cause the malfunction of the cooling system.
-
Page 7: Installation
Installation 59.5 cm 53 cm 115° 71.5 cm 83 cm 82 cm *Reserve 3cm extra distance only when the power outlet is right behind the wine fridge. *The reserved built-in space does not include the projection of the handles (4.3cm). -
Page 8: The Touch Controls And Operation
The Touch Controls and Operation There are 2 touch control panels in each temperature zone (the left and right cabinets), which operate separately when adjusting temperature settings. NOTE: Just a gentle touch is required to activate multiple settings from the touch control panels. -
Page 9: Temperature Setting & Energy Saving Recommendations
High/Low Temperature Alarm When the temperature of the wine fridge is over 23°C or lower than 0°C, an alarm with beeps will begin, which will stop once the temperature is lower than 23°C or higher than 0°C. NOTE: The alarm can be deactivated by pressing any buttons on the control panels. -
Page 10: Wine Rack & Bottle Configurations
Wine Shelves & Bottle Configurations Standard Bordeaux Burgundy Burgundy Barolo, Brunello di Montalcino 750mL 750mL 750mL 750mL 24.2 23.6 26.2 11.5 Riesling Sparkling or Champagne Bordeaux Burgundy Champagne 750mL 750mL 375mL 375mL 375mL Unit: cm Detachable Beechwood Shelves *When taking/placing bigger bottles on a beechwood shelf, raise up the shelf that is right above it for easier access. - Page 12 A/B/C D/E/F Fixed Shelves *The max. bottle height is around 30cm. 5 Standard Bordeaux Diverse wine storage (750mL)
-
Page 13: Bottle Capacity
Bottle Capacity According to the industry standard, the total storage capacity of 40 bottles are measured based on the standard Bordeaux bottle 750mL. Total Capacity: 40 bottles (standard 750mL Bordeaux) -
Page 14: Care And Maintenance
Cleaning and Maintenance ● Please keep the interior and exterior of your wine fridge clean and tidy to avoid any spillage of wine in the fridge. If there’s any spillage please clean up with clean rugs as soon as possible. ● Glass Doors: We recommend using alcohol wipes, glass cleaning cloths, and also glass cleaner to wipe and clean the outer layer. -
Page 15: Troubleshooting Guide
Troubleshooting Guide Possible Causes & Solutions Problems ● Check if the unit is plugged into a working power outlet. ● Touch the Power On/Off button once and hold until the Wine fridge does not operate control panel shows the number of temperatures. ●... - Page 16 ● In case of power outage, please do not open the door to prevent the temperature from rising due to the loss of cool air inside the wine fridge. DIVIN wine cooler is equipped with a temperature memory function, which...
-
Page 17: Warranty And Terms
Warranty & Terms The warranty of DIVIN wine fridges includes 2-year warranty for the products (except for consumables like the activated charcoal filters) and 3-year for compressor (except for solenoid valves) from purchase date. Any faulty parts will be repaired and/or replaced at no charge under warranty conditions, due to manufacturing faults, which do not extend to negligence or misuse caused by the users. - Page 18 ● Consumables: e.g. activated charcoal filters. ● Loss of any wine or other products, stored in the DIVIN wine fridges, due to compressor failure. ● Damages caused by acts of God, pest and rat Infestation, or inadequate power supply. ● Influenced by the special environment, which is high-corrosion areas, such as brimstone area, high salinity coastal zone, marsh gas, chemical corrosion or on a boat.
