EOA7535 Quick Start Guide
Dual Radio Concurrent AP/CB
EOA7535 equips with two powerful independent RF interfaces which support 802.11a and
802.11b/g. With certified IP‐68 protection, it is designed to deliver high reliability under harsh outdoor
environment.
Built‐in advanced multi‐functions provide flexibility in constructing scalable WiFi networks for all
possible applications. With two individual interfaces, each can be configured into 3 different modes
with maximum of 8 combinations. EOA7535 offers bandwidth up to 54Mbps to accommodate heavy
traffic services such as multimedia streaming. Establishing backbone network using 802.11a ensures
stability and reduces interference while 802.11b/g offers great compatibility to all wireless clients.
EOA7535 provides wide‐range of authentication and encryption standards (including WEP, WPA,
WPA2, TKIP/AES and IEEE 802.1X) to enforce maximum security. Furthermore, friendly security
management user interface reduces configuration complexity. EOA7535 is a true carrier‐grade
product which is guaranteed to fulfill any business proposals.
IP Address Configuration
The default IP address of the device is
192.168.1.2. In order to log into this device,
you must first configure the TCP/IP settings
of your PC/Notebook.
1. In the control panel, double click
Network Connections and then
double click on the connection of
your Network Interface Card (NIC).
You will then see the following
screen.
2. Select Internet Protocol (TCP/IP) and
then click on the Properties button.
This will allow you to configure the
TCP/IP settings of your PC/Notebook.
3. Select Use the following IP Address
radio button and then enter the IP
address (192.168.1.21) and subnet
mask (255.255.255.0). Ensure that
the IP address and subnet mask are
on the same subnet as the device.
Click on the OK button to close this
4.
window, and once again to close LAN
properties window.
Logging In
1. To configure the device through the
web‐browser, enter the IP address of
the device (default: 192.168.1.2) into
the address bar of the web‐browser
and press Enter.
Quick Start Guide v.1.0
Refer to User's Manual for complete instructions
Administration
2. After connecting to the IP address, the
web‐browser will display the login page.
Specify admin as the default User
Name and Password, and then click on
the Login button.
1. Under Management section, click on
the [Admin] link. This option allows
you to modify the default password for
the device. For security it is highly
recommended for security reasons.
2. Old Password: please type in admin
3. Password: Specify a password into this
field and then re‐type the password
into the Confirm New Password field.
Then click on the Apply button.
Click on the [Apply] button to save the
4.
changes.
