- Page 1 PARAVAN Lancia Voyager User manual User manual/Lancia/Version 1.00...
-
Page 2: Table Of Contents
Operation by using rocker switches ..................5 2.2. Manual operation of the sliding door and ramp ..............6 2.3. Electric operation of the PARAVAN Lancia Sliding Door ............7 2.3.1. Remote Control (Original LANCIA + PARAVAN) .............. 8 Lowered Floor ........................10 Re-routed exhaust-pipe installation .................. -
Page 3: Introduction
All information contained in the Owner`s Manual is accurate at the time of publication. PARAVAN reserves the right to make changes at any time so that our policy of continual product improvement can be carried out. -
Page 4: Operation Of Sliding Door And Ramp
Make sure that no person or article rule in the range of the driven out ramp To unlock the vehicle use the original LANCIA Remote Control. Pressing “1” at the PARAVAN Remote Control will open the right sliding door, lower the car (if vehicle is equipped) and extend the ramp. -
Page 5: Operation By Using Rocker Switches
Operation by using rocker switches You can also open the right sliding door, lower the car and extent the ramp by using rocker switches. They are located: A) At the dashboard B) on the B-Pillar right side Benutzerhandbuch/Paravan Lancia V1.0 Seite 5 von 18... -
Page 6: Manual Operation Of The Sliding Door And Ramp
Pull out the ramp horizontally of the intermediate compartment in the floor until it reaches the rear end by using the handle of the ramp that you will find below the ramp cover. Allen Key to unlock the ramp Continues on page 6 Benutzerhandbuch/Paravan Lancia V1.0 Seite 6 von 18... -
Page 7: Electric Operation Of The Paravan Lancia Sliding Door
You can also open the sliding door by using the original LANCIA Remote Control. In this case the ramp will not be not extended. To lower the car and extend the ramp press button “1” on the PARAVAN Remote Control The ramp does not have an automatic stop and reversal function ! Never intentionally place any object or part of your body in the path of the ramp. -
Page 8: Remote Control (Original Lancia + Paravan)
“1” Ramp out “2” Ramp in To lower the car and extend the ramp press button „1“ on the PARAVAN Remote Control To stop the ramp at any position press “1” again. To continue extending the ramp press “1” within 10 sec. - Page 9 The ramp does not have an automatic stop and reversal function ! Never intentionally place any object or part of your body in the path of the ramp. This could result in serious injury or cause damage to the vehicle. Benutzerhandbuch/Paravan Lancia V1.0 Seite 9 von 18...
-
Page 10: Lowered Floor
Because of the vehicle’s lowered chassis, the exhaust system has been re-routed through a sideways running duct in the floor assembly – which is one of the reasons why you should drive with care. Make especially sure that there is enough clearance underneath the vehicle. Benutzerhandbuch/Paravan Lancia V1.0 Seite 10 von 18...
