- Page 1 User’s Manual Network Appliance Model Number SCB-6971 ® ® Desktop AMD Geode LX800 Network Appliance with four LAN or three LAN and four switch, Mini PCI User’s Manual Version 1.0 AEWIN Technologies Co., Ltd Aug, 2006...
- Page 2 For more information on SCB-6971 or other AEWIN products, please visit our website http://www.aewin.com.tw. For technical supports or free catalog, please send your inquiry to info@aewin.com.tw...
-
Page 3: Table Of Contents
3.13 Exit Without Saving..................29 Chapter 4. Utility & Driver Installation ...............30 4.1 Operation System Supporting ................30 4.2 System Driver Installation ................30 4.3 VGA Driver Installation...................30 4.4 LAN Driver Installation...................31 Appendix A: Optional Accessory and Cable List............33 AEWIN Technologies Co., Ltd Aug, 2006... -
Page 4: Chapter 1. General Information
Chapter 1. General Information 1.1 Introducing The SCB-6971 series is a low cost, low power network appliance. There are two combinations. One is equipped with four 10/100Mbps LAN ports, the other is with three 10/100 LAN and four 10/100 switch. Also, the system is equipped with one RJ45 console port. -
Page 5: Order Information
SCB-6971. Keep the box and carton when you probably ship or store SCB-6971 in near future. After you unpack the goods, inspect and make sure the packaging is intact. Do not plug the power adapter to the main board of SCB-6971 if you already find it appears damaged. - Page 6 Ground yourself before removing any system component from it protective anti-static packaging. To ground yourself, grasp the expansion slot covers or other unpainted parts of the computer chassis. Handle the SCB-6971 control board by its edges and avoid touching the components on it. AEWIN Technologies Co., Ltd...
-
Page 7: System Layout
User’s Manual 1.6 System Layout SCB-6971A-050-A: (Front Side) (Rear Side) SCB-6971B-050-B: (Front Side) (Rear Side) AEWIN Technologies Co., Ltd Aug, 2006... -
Page 8: Board Dimension
User’s Manual Board Layout: (SCB-6971B-050-B) 1.7 Board Dimension SCB-6971A-050-A Main board AEWIN Technologies Co., Ltd Aug, 2006... - Page 9 User’s Manual SCB-6971B-050-B Main board AEWIN Technologies Co., Ltd Aug, 2006...
-
Page 10: Chapter 2. Connector/Jumper Configuration
User’s Manual Chapter 2. Connector/Jumper Configuration 2.1 Connector/Jumper Location and Definition AEWIN Technologies Co., Ltd Aug, 2006... -
Page 11: Connector And Jumper Setting
Chassis Ground CN3: COM1 RJ45 connector CN8: Four port switch Define Define CTS# DTR# TXD# Console Detect# Chassis Ground Chassis Ground RXD# DSR# Chassis Ground RTX# Chassis Ground CN4/5/6/7: 10/100 RJ45 connector CN10: VGA connector AEWIN Technologies Co., Ltd Aug, 2006... - Page 12 DTR# PDD0 PDD15 Ground Ground PDDREQ Ground CN13: LPC bus connector The connector is proprietary for LPC PDIOW# Ground port 80 card. PDIOR# Ground PDIORDY Ground PDDACK# Ground IRQ14 V5P0 PDA1 PD66# PDA0 PDA2 AEWIN Technologies Co., Ltd Aug, 2006...
- Page 13 GPin1 GPIn2 LINK4+ LINK4- GPin3 GPout0 SPEED4+ 8 SPEED4- GPout1 GPout2 GPout3 C20: Switch LED (Optional) CN17: USB pin header Define VSBVCC Pin Define Pin Define DATA- Switch 1 LINK+ Switch 1 LINK- DATA+ AEWIN Technologies Co., Ltd Aug, 2006...
- Page 14 User’s Manual Switch 1 Switch 1 SPEED- SPEED+ Switch 2 LINK+ Switch 2 LINK- Switch 2 Switch 2 SPEED- SPEED+ Switch 3 LINK+ Switch 3 LINK- AEWIN Technologies Co., Ltd Aug, 2006...
- Page 15 IDE ACTIVE- PW LED+ PW LED- JP1/JP4: DDR Speed & Voltage Detect Setting 1-2 (ON) DDR-400/2.6V 1-2 (OFF) DDR-333/2.5V JP2: Compact Flash Select Setting Master 1-2 (ON) (Default) 1-2 (OFF) Slave JP3: Clear CMOS Setting AEWIN Technologies Co., Ltd Aug, 2006...
- Page 16 User’s Manual Normal (Default) Clear CMOS AEWIN Technologies Co., Ltd Aug, 2006...
-
Page 17: Chapter 3 Bios Setup
User’s Manual Chapter 3 BIOS Setup The ROM chip of your SCB-6971 board is configured with a customized Basic Input/Output System (BIOS) from Phoenix-Award BIOS. The BIOS is a set of permanently recorded program routines that give the system its fundamental operational characteristics. -
Page 18: Entering The Cmos Setup Program
1. Turn on or reboot the system. After the BIOS performs a series of diagnostic checks, the following message appears: “Press DEL to enter SETUP” 2. Press the <DEL> key to enter CMOS Setup program. The main menu appears: AEWIN Technologies Co., Ltd Aug, 2006... -
Page 19: Menu Options
Configure the CPU speed and, if the optional system monitor IC is installed, view system information LOAD OPTIMIZED DEFAULTS: Loads optimized BIOS settings SET USER PASSWORD: Configure the system so that a password is required when the system boots or AEWIN Technologies Co., Ltd Aug, 2006... -
Page 20: Save And Exit Setup
PgUP/PgDN/+/- keys. Some fields let you enter numeric values directly. Option Description Date (mm:dd:yy) Type the current date Time (hour: min: sec) Type the current time (24-hour clock) IDE channel Select from “Auto”, “User”, or “None” AEWIN Technologies Co., Ltd Aug, 2006...
