Summary of Contents for Blocklychain TH-104
- Page 1 Thermometer Hygrometer TH-104...
- Page 2 HELLO Thank you for purchasing Smart Button. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Wi-Fi Connectivity Thermometer Hygrometer provides Wi- Fi to connect directly to the Internet. Rechargable Battery Using a last-longing rechargable battery, Thermometer Hygrometer works for a...
- Page 3 How to Install Thermometer Hygrometer Connect Thermometer Hygrometer to a USB Type-C charger. Go to www.blocklychain.io www.blocklychain.io...
- Page 4 Log into your account in BKC Control Panel. [or signup if you don’t have an account.] www.blocklychain.io Login Click on Devices on the menu. My Home My Home Today Devices Services Tuesday, 29 September 2021 Home 12:28 Home Europe/London Devices...
- Page 5 Select Thermometer Hygrometer from the list. My Home Add New Device Choose your device type Home Choose the type of your new device you want to install Devices Service Market Installed Services Motion Detector Door Sensor Smart Button Smart Plug Smart Speaker Activity Service Creator...
- Page 6 Go to the Wi-Fi setting on your laptop/mobi- le and switch it to Thermometer_Hygrometer Wi-Fi. Thermometer_Hygrometer HomeWi-Fi James ST1QTJ1 Tigerx 2:28 pm 12/6/2020 Go back to BKC Control Panel and click on Next. My Home Add New Device Change your Wi-Fi Home Go to Setting on your mobile and connect to the Wi-Fi name “Thermometer_Hygrometer ”.
- Page 7 Choose your home Wi-Fi from the list and type the password. Then, click on Check Wi-Fi. My Home Add New Device Set your home Wi-Fi Home Choose your home Wi-Fi from the list below. Devices Manual Setting Available Wi-Fi list My Wi-Fi Service Market Wi-Fi X...
- Page 8 How to Control Your Device Log into your account in BKC Control Panel. Then, go to the Devices page. Your Thermometer Hygrometer card will be like below. Name of the device Temperature and humidity data Last activity time Battery indicator Device dashboard Device connection indicator...
-
Page 9: Update Device
Update device Connect the device to a charger. Click on the button on your device. Go to BKC Control Panel. Go to Devices page. On the device card, click on the device dashboard button. Go to the Config tab. Click on Update Now. Reset Factory On your Thermometer Hygrometer Click and release the button, then press and... -
Page 10: Device Dashboard
Device Dashboard Clicking on the gear icon on the Smart Plug card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about device functions. ThermoHumid Thermometer Hygrometer Monitor Data Graph Config Temperature Humidity Battery Wakeup-interval Data Graph In Data Graph tab, a bar chart represent power consumption during time. - Page 11 Config In Config tab, you can update firmware, rename device, set Wi-Fi, and remove your device from BKC Control Panel. ThermoHumid Thermometer Hygrometer Monitor Data Graph Config FC:F5:C4:A5:0D:E2 Device Details Type Thermometer_Hygrometer Firmware Version 1.2.0 Install Time 2 August 2021 Su 5:23 Hardware Version Rename Device New Version Available...
- Page 12 Thermometer operating range -10 to +85°C Hygrometer operating range 0 to %100 RH For the best result, install Thermometer Hygrometer horizontally with the char- ging port facing up. When device is charging, the data won't be accurate.
- Page 13 BKC Control Panel In BKC Control Panel, you can register, monitor, and control your BKC devices. www.blocklychain.io...
-
Page 14: Installing Control Panel
Installing Control Panel On the phone Open the Google Chrome browser. Go to www.blocklychain.io Click on Login. Log into your account. On the pop-up page, click on Add to Home Screen. On the desktop Open the Google Chrome browser. Go to www.blocklychain.io Click on Login. - Page 15 Blocklychain Services In BKC Control Panel, BKC Services are mini apps that add new functionalities to smart devices. You can access hundreds of BKC Services in Service Market or easily develop new services on Service Creator to extend the functionality of your Thermometer Hygrometer.
- Page 16 Service Creator In BKC Control Panel, using Service Creator, you can develop new services. How to create Blocklychain Services There are two programming consoles in Service Creator: 1. Blockly Console 2. Coding Console My Home 8952 Created Service Published Service Installed Service...
- Page 17 Math Activity Text Service Creator 2. Coding Console Coding Console enables professional devel- opers to program BKC services by JavaScript syntax for Blocklychain-enabled devices including Thermometer Hygrometer. My Home * Describe this function ... Home Thermo_Hygrometer1.PAYLOAD.temperature (>35)) ; Devices if ((Motion1.PAYLOAD.state === 'Detected')) {...
- Page 18 Status Indicator Description Connection Orange Connecting to Blocklychain (Blinking every 4 seconds) server on the Internet Orange Connecting to Wi-Fi (Blinking every 1seconds) Battery Blinking Red Very low battery Solid Red Low battery Solid Blue Charging Solid Green Full charge...
- Page 19 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion.
-
Page 20: Specification
Specification Device Product Name Thermometer Hygrometer Model TH-104 Size 7x2x2 cm Weight 22 g Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V Lithium rechargeable Charger USB Type-C Sensor Temperature Sensor Accuracy ±0.4 °C (max), –10 to 85 °C Hygrometer operating range... -
Page 21: Package Content
Package Content 1x Thermometer Hygrometer For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
