- Page 1 Thermometer Hygrometer TH-104...
- Page 2 HELLO Thank you for purchasing Thermometer Hygrometer. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Wi-Fi Connectivity Thermometer Hygrometer connects to the Internet via Wi-Fi. Rechargable Battery Using a last-longing rechargable battery, Thermometer Hygrometer works for a...
- Page 3 Thermometer operating range -10 to +85°C Hygrometer operating range 0 to %100 RH For the best result, install Thermometer Hygrometer horizontally with the char- ging port facing up. When device is charging, the data won't be accurate.
- Page 4 How to Install Download Blocklychain App Product Installation Guide Create a New Account: Click on Create Account Type your e-mail address Type your password Re-type your password Click on Create Account Check your e-mail to verify your account , then click on I'm Already Verified...
- Page 5 Sign In: Click on Sign In Type your e-mail address Type your password Click on Sign In...
- Page 6 To install a new device in Android, make sure the mobile Bluetooth is turned on and allowing the app to "access device's location / Bluetooth"...
- Page 7 How to Install Device Connect Thermometer Hygrometer to a USB Type-C charger. Before continuing installation process, let's device battery get fully charged. * A solid green indicator light shows the battery is fully charged. Connect the device to a charger then click on the button on your device...
- Page 8 Find your device from the list, then click on Connect Click on Search Wi-Fi Searching for available Wi-Fi networks Choose your Wi-Fi SSID Type your Wi-Fi password Click on Set Device Wi-Fi...
- Page 9 If the device installation process finishes successfully, the message be displayed. Otherwise, the message will be displayed. It indicates that something went wrong and you will need to redo the installation process again.
- Page 10 How to Monitor Your Device Back to home in app. Then, go to the BKC control Panel. Click on BKC Control Panel icon Click on Devices This is Device Card...
- Page 11 Name of the device Temperature and humidity data Last activity time Battery indicator Device dashboard Device connection indicator...
-
Page 12: Update Device
Update device Connect the device to a charger. Click on the button on your device. Go to BKC Control Panel. Go to Devices page. On the device card, click on the device dashboard button. Go to the Config tab. Click on Update Now. Reset Factory On your Thermometer Hygrometer Click and release the button, then press and... -
Page 13: Device Dashboard
Device Dashboard Clicking on the gear icon on the Thermometer Hygrometer card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about device functions. ThermoHumid Thermometer Hygrometer Monitor Data Graph Config Temperature Humidity Battery Wakeup-interval Data Graph In Data Graph tab, a bar chart represent power consumption during time. - Page 14 Config In Config tab, you can update firmware, rename device, and remove your device from BKC Control Panel. ThermoHumid Thermometer Hygrometer Config Monitor Data Graph FC:F5:C4:A5:0D:E2 Device Details Type Thermometer_Hygrometer Firmware Version 1.2.0 Install Time 2 August 2021 Su 5:23 Hardware Version Rename Device New Version Available...
-
Page 15: Led's Status
LED's Status Status Indicator Description Connection 4 seconds 4 seconds Problem connecting to server 2 seconds 2 seconds Ready to install 0.2 second 0.2 second Connecting to Wi-Fi 0.1 second 0.1 second App connected to device Solid Orange Connecting to server Battery 0.2 second 0.2 second... - Page 16 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion. Do not heat, open, puncture, mutilate, or dispose of your device or its battery in fire.
-
Page 17: Specification
Specification Device Product Name Thermometer Hygrometer Model TH-104 Size 7x2x2 cm Weight 22 g Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V Lithium rechargeable Charger USB Type-C Sensor Temperature Sensor Accuracy ±0.4 °C (max), –10 to 85 °C Hygrometer operating range... -
Page 18: Package Content
Package Content 1x Thermometer Hygrometer For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
