Summary of Contents for Hidrotermal MRS-4.5
- Page 1 Residential Softener MRS-4.5 MRS-6 INSTALLATION AND MAINTENANCE MANUAL...
-
Page 2: Table Of Contents
Catalogue Preface 1.Product Profile........................2. Working Principle......................3. Assembly & Parts ......................4. Function and Characteristics..................... 5. Product Dimensions......................6. Application........................7. Technical Paramer......................8. Installation......................... 9. Usage Installation......................10. Note ..........................11. Trouble-Shooting......................12. Component Structure, Name and Code................. 13. -
Page 3: Product Profile
Preface Thanks for choosing our softener series products. These products are featured by good softening effects, stable performance, excellent appearance, compact structure and simple handling, etc. They can meet the softening water demand of family washing, bathing, cleaning and boiling, etc. Besides, they also can be applied to supplying high quality soften water for institutions, schools, group companies, and so on. -
Page 4: Function And Characteristics
4.Function and Characteristics 1. Manual control mode: In the operation of softeners, it needs to manually rotate the hand wheel or handle of the multi-port valve to complete the cyclic processes of service, backwash, brine and slow rinse, brine refill and fast rinse. 2. -
Page 5: Technical Paramer
Per Cycle(L) Water Capacity (L) Mode 1200 Down-flow MRS-4.5 ※ Water treatment capacity per cycle is various according to the difference water quality of different region. The standard testing conditions is: Water temperature:25 ℃ , Raw waterhardness: 150mg/L(CaCO3). Service Conditions: Water Pressure: 0.15-0.6MPa；... - Page 6 ※ Before installing the pipeline, please clean off the residual impurities and dust in the pipeline. After the main water inlet is closed, connect it with the device. ※ All pipelines should meet the relevant regulations. The installation and connection should comply with the local installation rules.
- Page 7 ※ For convenient maintenance, the device is suggested as the illustration shows. Note: Install three ball valves to connect the control valve and inlet/outlet pipeline. Valve B is connected with the inlet of the control valve, valve C to the outlet. When the valve body needs fixing, open valve A, then close the valve B and valve C.
- Page 8 Average Water (mg/L) Volune(L) Use (150L/Day) Use(300L/Day) 1500 MRS-4.5 2000 MRS-6 1000 Note: ● The user should conduct the operation of backwash, brine and slow rinse, refill, fast rinse according to the reference time values corresponding to the resin tank specifications.
-
Page 9: Usage Installation
Brine valve installation and usage: The brine valve plays two roles in the whole system: First, under the brine and slow rinse status, with the floating ball, the brine valve can prevent the air from being inhaled which may affect the regeneration and usability. That is, the brine valve has the function of air check. Second, under the brine refill status. -
Page 10: Note
10.Note Before reading and understanding the manual instruction, please do not operate the device. ※ Forbid installing the device near heat source or take anti-heat protective measures when install near the heat source. It is also forbidden to connect the device with the hot-water pipeline or the pipeline with the possibility of hot-water returning. -
Page 11: Trouble-Shooting
11.Trouble-Shooting Before maintenance, please check following information. Trouble details Cause Solution 1.Connector-loose 1.Screw tight connector or reconnect Leakage 2.O-ring broken 2.Replace o-ring Noise Air enters device Re-backwash, empty air High hardness of 1.Unqualified raw water 1.Contact with supplier outlet water 2.Regeneration cycle too long 2.Shorten regeneration cycle time 1.Increase inlet pressure,more than... -
Page 12: Component Structure, Name And Code
12.Componet Structure, Name and Code 12.1. Product Structure... - Page 13 12.2Component Name and Code Component Code Quantity Notice Serial Component Name MRS 4.5 MRS 6 8WRX.945.022 8WRX.945.022 Seal Ring φ28.5×φ20×3 8WRX.371.088 8WRX.371.088 Connector 8WRX.458.044 8WRX.458.044 Cabinet 8WRX.002.016 8WRX.002.017 Tube φ10×φ6.5×430 8WRX.457.101 8WRX.457.101 Resin Tank 5WRX.469.001(0713) 5WRX.469.038(0717) Resin 4WRX.030.001(4.5L) 4WRX.030.001(6L) Dustproof Cover 8WRX.005.026 8WRX.005.026 Bottom Strainer...
- Page 14 12.4.Component Name and Code Component Code Serial NO. Component Name Quantity SMV01B O-ring φ15×1.8 8WRX.378.179 Drain Line Flow Control 8WRX.468.042 Connector 8WRX.458.064 Animated Nut 8WRX.945.025 Nut, Hex.Hd. 8WRX.940.001 Tube Bushing 8WRX.457.004 Connector 8WRX.458.068 O-ring φ11ˣ2 8WRX.378.169 Brine Line Flow Control 8WRX.468.057 O-ring φ10.82×1.78 8WRX.378.012...
-
Page 15: Maintenance
13.Maintenance ※Before check-up please turn off the softener inlet valve or bypass valve to bypass position. ※Prohibited to use harmful detergents or chemicals to clean, wipe the device. ※Wipe with a moistened soft fabrics to clean equipment surface dust and foreign matter, aviod the water into the valve internal erosion electrical components causing damage.
