Musica M822C Specifications

Finished Good # M822C
Component Criteria
Driver Size(s) 8" Woofer
Mounting Hardware Integral mounting wings
Xover Encl Type Back mounted PCB
Tweeter Type (2) 12mm Balanced domes w/Neodymium motor
Dampening/Filler N.A.
Port Flange N.A.
Physical Data
6/each input Ω
Minimum Impedance
Enclosure Finish White injection molded baffle
Enclosure Style Round inceiling speaker
Performance Criteria
Nominal Impedance 8 Ω
Sensitivity (±2%) 80.2 dB @ 2.83V/1m
Freq Resp (±3dB) 34Hz - 20kHz
Application Criteria
Enclosure Type VB
Infinite Baffle N/A
Sealed
Vented
Single Reflex BP
Dual Reflex BP
Package Information
Units per Carton 1 ea.
Unit Weight 3.5 lb
Carton Length 12.204"
Carton Width 5.275"
Carton Depth 12.677"
Additional Information
Works with wall thiknesses ranging from 1/8" to 1½"
Uses rough in kit RIK8C
Cutout DIA. = 9- 7/16"
5-color gift box w/ Styro packaging inserts
3-color Magnet label
Mounting depth = 3- 7/16"
Includes a PVC paint shield
f3=34Hz, f6=29Hz, f10=26Hz
Power Handling: 65Wrms/Input
Approvals
Designed By: MJD

System Specifications

Manufacturing Cost
Driver Type(s)
Xover Type
Grill Type
Terminal Type
Special Cosmetics
Port Flange Quantity
Enclosure Height
Enclosure Width
Enclosure Depth
RMS Power
Peak Music Pwr
Recom'd Amp Pwr
VF FB (back)
N/A N/A
N/A N/A
N/A
N/A
Cartons per Master Carton
1.6 kg Packaged Weight
31.0 cm Master Carton Length
13.4 cm Master Carton Width
32.2 cm Master carton Depth
Date: 9/22/2006 Approved By:
$
Dual voice coil / Polypropylene cone / 1¼" voice
coil Rubber surround, 13 oz. ceramic magnet
12dB/ oct. high pass
White painted aluminum w/ cloth insert
Plastic spring terminals (x2)
N.A.
"
10.750"
3.937"BD
65 Wrms
130 W
10 - 65 Wrms
FB (front) F3 (low) F3 (high)
N/A 34Hz N/A
N/A N/A
N/A N/A
4
22.440"
13.000"
13.860"
.0 cm
27.3 cm
"TD 10. cm
Ripple Power
65W
lb .0 kg
57.0 cm
33.0 cm
35.2 cm
Date:
SPECS 09/06/2002
