Musica M622C Specifications

Finished Good # M622C
Component Criteria
Driver Size(s) 6 1/2" Woofer
Mounting Hardware Integral mounting wings
Xover Encl Type Back mounted PCB
Tweeter Type (2) 12mm balanced domes
Dampening/Filler N.A.
Port Flange N.A.
Physical Data
5 Ω
Minimum Impedance
Enclosure Finish White injection molded baffle
Enclosure Style Round In-Ceiling
Performance Criteria
Nominal Impedance 8 Ω
Sensitivity (±2%) 82.1 dB @ 2.83V/1m
Freq Resp (±3dB) 51Hz - 20kHz
Application Criteria
Enclosure Type VB
Infinite Baffle N/A
Sealed
Vented
Single Reflex BP
Dual Reflex BP
Package Information
Units per Carton 1 piece
Unit Weight 2.0 lb
Carton Length 10.945"
Carton Width 10.433"
Carton Depth 5.354"
Additional Information
Works with walls ranging in thickness from 1/8" to 1½"
Uses RIK6C rough in kit
Cutout DIA. = 7- 11/16"
Pole mount tweeter design
3-color Magnet label f3=51Hz, f6=42Hz, f10=35Hz, Power handling: 50Wrms/Input
5-color gift box w/ Styro packaging inserts
Mounting depth = 2- 7/8"
Stereo input speaker
Includes a PVC paint shield
Approvals
Designed By: MJD

System Specifications

Manufacturing Cost
Driver Type(s)
Xover Type
Grill Type
Terminal Type
Special Cosmetics
Port Flange Quantity
Enclosure Height
Enclosure Width
Enclosure Depth
RMS Power
Peak Music Pwr
Recom'd Amp Pwr
VF FB (back)
N/A N/A
N/A N/A
N/A
N/A
Cartons per Master Carton
.9 kg Packaged Weight
27.8 cm Master Carton Length
26.5 cm Master Carton Width
13.6 cm Master carton Depth
Date: 9/22/2006 Approved By:
$
Polypropylene cone / Rubber Surround ,
1" Dual voice coil 8 oz. ceramic magnet
6dB oct. - low pass / 12dB oct. - high pass
White painted aluminum w/ cloth insert
Plastic spring clips (x2)
N.A.
"
9.000"
3.625"BD
50 Wrms
100 W
10 - 50 Wrms
FB (front) F3 (low) F3 (high)
N/A 51Hz N/A
N/A N/A
N/A N/A
4
21.812"
11.653"
12.125"
.0 cm
22.9 cm
"TD 9.2 cm
Ripple Power
50W
lb .0 kg
55.4 cm
29.6 cm
30.8 cm
Date:
SPECS 09/06/2002
