TXFBB12
®
12" SWING GATE MOUNTED
SUBWOOFER ENCLOSURE
FOR FORD BRONCO
INSTALLATION GUIDE
NOTE! Read this installation guide thoroughly before disassembling or modifying
the vehicle. Installation of this product requires technical skill, experience and
specialized tools. If in doubt, it's recommended to have it professionally installed
by an authorized Stinger or Phoenix Gold Dealer.
A video installation guide is available at:
https://stingerelectronics.com/products/txfbb12
Advertisement
Table of Contents
Related Manuals for AAMP Global Stinger TXFBB12
Summary of Contents for AAMP Global Stinger TXFBB12
- Page 1 TXFBB12 ® 12” SWING GATE MOUNTED SUBWOOFER ENCLOSURE FOR FORD BRONCO INSTALLATION GUIDE NOTE! Read this installation guide thoroughly before disassembling or modifying the vehicle. Installation of this product requires technical skill, experience and specialized tools. If in doubt, it’s recommended to have it professionally installed by an authorized Stinger or Phoenix Gold Dealer.
-
Page 2: Limited Warranty
Limited Warranty Stinger warrants this product to be free of defects in materials and workmanship for a period of one (1) years from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Stinger dealer in the United States of America only. -
Page 3: Installation Notes
INSTALLATION NOTES For models equipped with a factory subwoofer, unplugging the factory subwoofer is recommended. Some installation steps are more easily completed with a second person. Speaker wire is required before the enclosure is mounted. Recommended amplifier rating: 400-800 watts @ 2ohms. ... - Page 4 HARDWARE M6 FLANGED HEX HEAD BOLT (2) M6 ALLEN HEAD BOLT (4) M6 SPLIT LOCK WASHER (2) M6 METAL WASHER (3) 40mm / 1.57in Length 20mm / .78in Length 11mm / .43in Diameter 18mm / .71in Diameter M6 RUBBER WASHER (2) BOTTOM L BRACKET (2) FOAM BRACKET PAD (2) MOUNTING TEMPLATE (1)
-
Page 5: Installation
INSTALLATION Using scissors or a straight edge and utility knife, cut out the template along the dashed lines. A C C E S S O R Y R E A D Y Position the template on the on the inside of the swing gate using the plastic trim panel as a guide as shown. - Page 6 INSTALLATION A C C E S S O R Y R E A D Y Using a center punch, mark the four mounting locations on the template. Remove the template and drill pilot holes at the four locations. CAUTION: To prevent the drill bit from hitting the outer side of the swing gate, wrap a significant amount of tape around the drill bit...
- Page 7 INSTALLATION If a rivet nut setter is not available, follow the directions below for each of the four holes: A. Insert a R1 rivet nut into the hole. B. Slide an W2 metal washer, a N1 spacer nut and a W4 tooth lock washer onto one of the B4 bolts.
- Page 8 INSTALLATION In the two lower threaded inserts, install L1 brackets using B2 allen bolts. Apply the L2 Foam Bracket Pads to the brackets. Run a suitable length of speaker wire into the swing gate following the factory wire harness. Connect the speaker wire to the terminals.
- Page 9 INSTALLATION Align the speaker enclosure on the L Brackets. Loosley install the indicated hardware into the upper mounting holes from inside the enclosure. Install the two B2 Allen Head Bolts through the L Brackets and into the bottom of the enclosure.
-
Page 10: Specifications
SPECIFICATIONS Model Number TXFBB12 Speaker Model P-TX12D4 Subwoofer Size 12” Voice Coil Dual 4 ohm DC Resistance (Re) 2 ohm Sensitivity 1W/M (SPL) 87 dB Frequency Response 20Hz - 250Hz RMS Power 400 watts Peak Power 800 watts Speaker Displacement 0.06 cu ft / 1.82 Ltr Speaker Weight 12.5 lbs... -
Page 12: Technical Support
Phone: 888-228-5560 Technical Support Stinger and the Stinger logo are trademarks or registered trademarks of Phone: 727-592-5991 AAMP Global in the United States and Email: support@stingerelectronics.com other countries. Chat: stingerelectronics.com © 2021 AAMP Global. All rights reserved. | IG-TXFBB12 REV 030122...
