TXTRB10BB
Subwoofer Enclosure Port Module
Attaching the Port:
Unscrew the eight #2 Philips speaker mounting screws and
remove the subwoofer from the TXTRB10 subwoofer enclosure.
Unscrew the side panel from the TXTRB10 subwoofer enclosure
using 4mm and 5mm Allen wrenches. Push out the side panel
from inside of enclosure.
Align and attach the foam gasket to TXTRB10BB (Port).
Align the TXTRB10BB (Port) next to TXTRB10 (Enclosure).
Place a rubber washer on the four inner bolts. From inside
the enclosure, align the four bolts through the enclosure
into the threaded holes on the port. Tighten using a 10mm
socket.
Install two additional bolts on the bottom side of the
enclosure stand.
Reconnect the speaker wire from the TXTRB10 enclosure
to the subwoofer the same way as before it was removed.
Reinstall the subwoofer using a #2 Philips screwdriver.
Foam Gasket
Adhesive Side
