- Page 1 Hotel Card Lock System ALV3 Series Card lock operation and maintenance manual HOTEL CARD LOCK ALV3M Series < Type ALV3MA/ALV3M, V3HTMA/V3HTM > Operation and maintenance manual Ver．1.0 June 22, 2021 Miwa Lock Co., Ltd. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
-
Page 2: Table Of Contents
3.2 Confirmation of locking, door lever, and construction status ........12 3.3 Card authentication and operation check..............12 3.4 Smartphone authentication and operation Check (V3HTMA/V3HTM only) ..12 3 Periodic maintenance ....................13 3.1 Battery replacement ....................13 Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 3: Functional Overview
"Unlock" button, and hold the smartphone over it. The operation method is subject to change without notice for the purpose of improving convenience and security. ※1:The operation method may differ depending on the smartphone app used. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 4: Appearance And Names Of Parts
■ type ALV3M/V3HTM Card Reader/BLE Communications Target mark Department Infrared (IrDA) sensor Latch bolt Handle Door lever Door lever Trigger bolt seat Dead bolt Thumb turn Outside view Inside view Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 5: Mechanism
・Even in the locked state, unlock from the indoor side only with the door lever operation. ・Even in the double lock state, the dead bolt is pulled in by operating the door lever to unlock. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 6: Functional Overview
・When master card/ sub-master card/ master lock-out card/ housekeeping lock-out card/ cancel card/ daylight saving card/ is used, you can detect low remaining battery level by using LED and buzzer (low battery detect function). Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. - Page 7 Power can be supplied externally when the battery runs out. ・Time hold function Clock in a lock runs for 5min during a battery exchange. ※Complete battery exchange within 5 minutes. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
-
Page 8: How To Operate
22mm at centering ※Bringing a hand, metal, or other object that carries electricity close to the card reader part may cause the LED to flash in red four times. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. - Page 9 However, it varies depending on the cover and body material. ※Bringing a hand, metal, or other object that carries electricity close to the card lock reading part may cause the LED to flash in red four times. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
-
Page 10: In Case Of Emergency
When a second room is set for the guest card and the Standby Card smartphone, hold the card over the lock in the appropriate Guest Mobile (Smartphone) second room as well. Passage card (continuous unlock card) Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 11: Periodic Maintenance
・Be careful not to reverse-insert the battery. Incorrect orientation of the battery may cause operation failure, battery leakage, symptom battery depletion, etc. (Check the direction of + and-thoroughly.) ・Dispose of used batteries according to local regulations. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 12: Confirmation Of Locking, Door Lever, And Construction Status
LED flashes yellow. (2)After unlocking, does the LED turn off and lock after the set time elapse. If the LED lights in red or flashes in red, start over the procedure. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. -
Page 13: Periodic Maintenance
(2) This unit must accept any interference received, including interference that may cause undesired operation. FCC Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD. - Page 14 FCC radio frequency (RF) Exposure Guidelines as this equipment has very low levels of RF energy. ・Responsible Party – U.S. Contact Information MIWA LOCK CO.,LTD. USA Office 9272 Jeronimo Road, Suite 119, Irvine, CA 92618 Telephone：1-949-328-5280 / FAX：1-949-328-5281 Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
- Page 15 Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’ISDE puisque cet appareil a une niveau tres bas d'energie RF. Copyright(c) 2021 All rights reserved by MIWA LOCK CO., LTD.
