3.
Tools
Use clean grease-free tools to install the terminal correctly.
Appropriate tooling will be required for correctly installing the removal protection nut.
The following are needed for preparing a terminal:
• door opening tool (ref. 135964),
• square key (ref. 135078),
• ratchet handle,
• 16-mm socket.
The following are needed for fastening the terminal on flat ground or in an
excavation:
• rule,
• spirit level,
• 24-mm eye type spanner,
• ratchet handle,
• 24-mm socket.
The following are needed for installing the upper part of the terminal:
• ratchet handle,
• 13-mm socket.
4.
Dimensions
Keep minimum clearance around the terminal (30 x 30 cm) to enable movement
during installation and when it is used by motorists:
• 20 cm at the rear and on the sides,
• 1 metre in front.
Installation in an excavation will require a hole that is 60 cm long x 60 m wide x
60 cm deep, in keeping with the dimensional constraints of the terminal.
The mains cable (optional mains power supply) goes through the centre of the
housing.
Strada Evolution 2 - Transfer and Rapide - Installation manual
3 - Tools
8 / 42
