Zip XTRA204 Quick Start Manual

1
2
3
4
5
6
*Note different models may vary
Step by Step First Time Setup
1. Connect the monitor to the DVR using a HDMI or VGA cable for the video, and turn on the monitor.
2. Connect the cameras to the DVR and Power up the DVR using the power supply provided. Note - do not use a 3rd
party or different power supply unless instructed to do so by the manufacturer.
3. Once the DVR has booted up, connect the USB, see Operation below and connect the Network cable to the DVR.
See Troubleshooting if you do not get an image on the monitor after "System Configuring".
4. Program the basic settings using Smart Setup.
Operation
IR Remote
1
Control
2
3
4
5
6
7
8
9
10
11
12
Document ref: qXTRA204, qXTRA208, qXTRA216
SEARCH 7 MENU/ESC
MUTE 8 Arrows
CH-/CH+ 9 OK/PTZ
ALL 10 PWR
PLAY/PAUSE 11 HDD
REC
Numeric Buttons
Display All
Menu / Escape
Mute
Sub-menu
Navigation / Enter
Rewind
Fast Forward
Play
OSD Keyboard
Record
Stop
Pause
ZipDVR.com
Zip Xtra Next Gen DVR Quick Start Guide
Mouse
Left-
Click
Right-
Click
Scroll-
Wheel
Zip is a registered trademark of System Q Ltd
www.zipnvr.com/pdf/xZip-
DVR-Manual.pdf
1 Audio In (Secondary)
2 e-SATA Interface
3 Audio In (Primary)
4 CVBS Spot Out
5 Audio Out
6 Video In
7 VGA
8 HDMI
9 RS485 Interface
10 LAN Interface
11 USB Interface & Reset Button
12 Alarm In/Out
13 DC Power Socket
14 Power Switch
15 IR Extender (Not supplied)
Live view: display Quick Setting toolbar
Single Click
Menu: select and enter
Live view: drag channel
Privacy Masking and Motion Detection:
Click & Drag
select target area
Digital zoom-in: zoom in to target area
Single Click Live view: show menu
Menu: exit current menu to upper level
Scrolling Scroll up / down through highlighted field /
drop down list
Delete character to left of the cursor
Confirm input
Switch keyboard to upper case letters and
Insert a space
Move courser left / right
© 2022 System Q Ltd
menu
symbols
