Stoane Lighting inter-lux Pipien Spike Installation And Maintenance Instructions

Download this manual

Pipien Spike

IMPORTANT: All wiring connections must be made before switching on mains power.

SL Type S 2.85V

1.4W @ 500mA

Please retain these instructions for future reference

Installation and Maintenance Instructions

410 381 1497 inter-lux.com answers@inter-lux.com

Inter-lux reserves the right to make technical changes without notice.

IP66 Dust tight and protected against powerful jets of water.

Need help?

Do you have a question about the inter-lux Pipien Spike and is the answer not in the manual?

Page 1 Pipien Spike Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. SL Type S 2.85V 1.4W @ 500mA IP66 Dust tight and protected against powerful jets of water. Please retain these instructions for future reference 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
Page 2 Contact SL for support if required. Fully isolate the fitting and allow to cool. All Stoane Lighting products are covered by a five year Warranty and a 25 year Duty of Care. Products are Clean the fitting with a slightly damp lint free cloth designed to be upgraded, adapted and refreshed using from a mild solution of soap and water.
Page 3 Pipien Spike 230/240V Mains Tilt Lock INTERIOR EXTERIOR Seal (by others) Fitting Soft ground Wire in series Waterproof Connector Wiring by MSL Wiring by others 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
Page 4 Pipien Spike Optic Change Fully isolate and allow fitting to cool sufficiently before handling. Always perform an optic change in a clean and dry environment. Step 1 Access the existing optic by holding the central section of the fitting and unscrewing the bezel. (Note:The back section is secured with additional thread locker and should not be opened) Step 2 Carefully remove the spacer and the optic...
