Pipien
IMPORTANT: All wiring connections must be made before switching on mains power.
SL Type S 2.85V
1.4W @ 500mA
F
Please retain these instructions for future reference
Installation and Maintenance Instructions
410 381 1497 inter-lux.com answers@inter-lux.com
Inter-lux reserves the right to make technical changes without notice.
IP66 Dust tight and protected against powerful jets of water.
1
Advertisement
Table of Contents
Related Manuals for Stoane Lighting inter-lux Pipien
Summary of Contents for Stoane Lighting inter-lux Pipien
- Page 1 Pipien Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. SL Type S 2.85V 1.4W @ 500mA IP66 Dust tight and protected against powerful jets of water. Please retain these instructions for future reference 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
- Page 2 The fitting must be completely dry before reconnecting power. All Stoane Lighting products are covered by a five year Warranty and a 25 year Duty of Care. Products are Incompatible or abrasive chemicals can damage the designed to be upgraded, adapted and refreshed using fitting, contact SL for advice if required.
- Page 3 Pipien Secure to mounting surface with 2 suitable fixings. 500mA SELV supply (Constant current) 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
- Page 4 Pipien Optic Change Fully isolate and allow fitting to cool sufficiently before handling. Always perform an optic change in a clean and dry environment. Step 1 Access the existing optic by holding the central section of the fitting and unscrewing the bezel. (Note:The back section is secured with additional thread locker and should not be opened) Step 2 Carefully remove the spacer and the optic...
- Page 5 Pipien Adjustment To adjust the tilt and pan of the fitting use a 2mm Allen key to loosen off the tilt and pan lock fixings. Once the desired angle is achieved lock off the fixings. DO NOT adjust the flat tip grub fixing DO NOT over tighten the fixings as this could damage the lock and cause it to no longer function.
- Page 6 Pipien Series Wiring SUPPLY Installation must be carried out by a qualified electrician in accordance with BS 7671:2008 Wiring Regulations. 230/240V AC 50/60Hz mains supply. Mains cables must be double insulated and strain relieved. Observe polarity: Positive (+) is marked as RED. Incorrect supply or reverse polarity can cause irreparable damage.
