Harol SC900 Installation Instructions Manual

Surface-mounted screen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SURFACE-MOUNTED SCREEN
SC900 - SC910
art.no. 60447
GATES
SHUTTERS
PORTES
VOLETS
INSTALLATION INSTRUCTIONS
SUN PROTECTION
PROTECTION SOLAIRE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC900 and is the answer not in the manual?

Questions and answers

Related Manuals for Harol SC900

Summary of Contents for Harol SC900

  • Page 1 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 art.no. 60447 GATES SHUTTERS SUN PROTECTION PORTES VOLETS PROTECTION SOLAIRE...

  • Page 2: Table Of Contents

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 TABLE OF CONTENTS 1. INTRODUCTION 2. GENERAL WARNINGS 3. LIST OF TOOLS REQUIRED 4. INSTALLATION STEPS 4.1. Determine the type of screen 4.2. Check the package 4.3. Check the product 4.4. Check the height and width 4.5.

  • Page 3: Introduction

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 1. INTRODUCTION The SC900 screen is a flat hanging sun screen, which is fitted on top of the window with a 'zipper system' on each side of the fabric. This makes the screen particularly resistant to high winds and keeps the fabric perfectly in place.

  • Page 4: List Of Tools Required

    Make sure the screen box can always be opened so the mechanical parts inside can be reached easily. If these rules are not respected, Harol cannot be held responsible for the cost of demolition work or any paint work or wallpapering.

  • Page 5: Installation Steps

    Also check the height of the guide rails, including the end stop, and make sure they correspond to the height of the window. In the following steps logos are used to show the difference between mounting the SC900 and SC910 screens.

  • Page 6: The Actual Assembly In 10 Steps

    • Remove the cover and the insulation. • (SC900) The support plate and base plate are connected. The advantage of this is SC900 that the base plate does not bend when handling the box. Remove these screws before mounting the screen! SC910 •...
  • Page 7 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 • Then unscrew the two screws at the back that connect to the base plate. SC900 SC910 Please note that this operation must be carried out on both sides of the box before proceeding to the next step.
  • Page 8 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 Step 3 SC900 • Centre the base plate on the window and screw it down. SC910 The touch component for the bottom lath of the SC910 screen is supplied separately. This is mounted on the base plate at a later stage! Tab at the bottom of the base profile forms the abutment with the window.
  • Page 9 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 Step 4 SC900 • Attach the clip profiles with the hole in a downward position. • First position the upper side of the clip profile against the tab on the bottom side of the base plate (Fig.
  • Page 10 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 Step 5 SC900 • Clip both lateral guides - together with the holder with zipper profile - onto the clip profile. • No screws are required! SC910 Plan view of the clip profile and guide rail...
  • Page 11 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 Step 6 SC900 • Place the box back on the base profile exactly as it was initially constructed (Fig. 3a-3b) (see Step 1). • Guide the bottom lath to the zipper guide profile, position the zipper in the zipper SC910 guide profile and let it drop down (Fig.
  • Page 12 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 SC900 Step 8 • Use the supplied screws to screw the bottom of the support plate to the base plate (Fig 7). • Position the supplied clips into the base profile and clip until fastened (Fig. 8).
  • Page 13 Window anchors In order to fix the box into the wall recess, the following window anchor types can be used: for the SC900 a minimum length of 160 mm is required. − ALIPLAST ACVL 130 (160x38x2). − REYNAERS window cl. Fulchs 439.119 (200x25x2) - available from Harol (optional).

  • Page 14: Installation Of Two Or More Adjacent Screens

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 4.6 (a). Installation of two or more adjacent screens Step 1 • Mount box according to the prescribed installation procedure. 03/15...
  • Page 15 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 4.6 (b). Installation of two or more adjacent screens SC910 adjacent Step 1 • Mount box according to the prescribed installation procedure. Step 2 • Mount the guide rails for the second/next box onto the window.

  • Page 16: Checking The Assembly

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 − 4.7. Checking for squareness Make sure that the screens are always dead level and installed perfectly square. This can be checked and corrected in one way only. Check first whether the whole assembly is mounted dead level.

  • Page 17: Electrical Connections

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 5. ELECTRICAL CONNECTIONS Note: The connections must be carried out by a registered installer (refer to guarantee card 2.1.) Electrical installation and connection diagrams must be applied correctly, the electrical accessories employed must comply with the current standards and/or requirements.

  • Page 18: Adjusting The Motor - Limit Switches

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 5.2. Adjusting the motor - limit switches Temporarily connect the motor to a test cable. On the control side of the screen, at the height of the support plate, there is a viewing panel.
  • Page 19 INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 Why use an RI2 relay box? If several LT or LS motors are operated using the same switch, you must always use a relay box. If relay boxes are not used, the integral limit switches will soon burn out due to the high inductive and capacitive voltages which are mutually generated.

  • Page 20: Troubleshooting And Repairs

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 6. TROUBLESHOOTING AND REPAIRS 6.1. The screen will not roll up or down. • The internal limit switch of the motor has not been activated in any direction. Press both setting buttons and proceed with the setting of the end positions.

  • Page 21: Automatic Control Does Not Operate Properly

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 6.10. Automatic control does not operate properly. • See installation instructions: automatic wind and sun screens. 6.11. The bottom lath sticks or shudders when the screen is lowered or raised. • Check whether the whole assembly is dead level.

  • Page 22: Notes

    INSTALLATION INSTRUCTIONS SURFACE-MOUNTED SCREEN SC900 - SC910 9. NOTES 03/15...
