Arbor Technology ELIT-1850 User Manual

Digital signage player w/ intel core™ i7-5650u/i3-5010u cpu
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ELIT-1850
Digital Signage Player
w/ Intel
Core™ i7-5650U/i3-5010U CPU
®
User's Manual
Version 1.0
2016.04
P/N: 4016185000100P
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELIT-1850 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arbor Technology ELIT-1850

Summary of Contents for Arbor Technology ELIT-1850

  • Page 1 ELIT-1850 Digital Signage Player w/ Intel Core™ i7-5650U/i3-5010U CPU ® User’s Manual Version 1.0 2016.04 P/N: 4016185000100P...
  • Page 2 This page is intentionally left blank. - 2 -...
  • Page 3 Revision History Version Date Description April. 2016 Initial release - i -...

  • Page 4: Table Of Contents

    Contents Revision History ................i Preface.................... v Copyright Notice ..................v Declaration of Conformity ................. v CE ...................... v FCC Class B ..................v RoHS ....................vi SVHC / REACH .................vi Important Safety Instructions ..............vii Warning ....................viii Replacing Lithium Battery ............... viii Technical Support ...................
  • Page 5 Contents Chapter 5 - BIOS ................41 5.1. Main ....................44 5.2. Advanced ..................46 5.2.1. CPU Configuration ..............47 5.2.2. ACPI Settings ................. 48 5.2.3. AMT Configuration ..............49 5.2.4. Super IO Configuration ............50 5.2.5. Hardware Monitor ..............51 5.2.6.
  • Page 6 This page is intentionally left blank. - iv -...

  • Page 7: Preface

    Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such...

  • Page 8: Rohs

    (PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed...

  • Page 9: Important Safety Instructions

    Preface Important Safety Instructions Read these safety instructions carefully Read all cautions and warnings on the equipment. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage Make sure the correct voltage is connected to the equipment. For pluggable equipment, the socket outlet should be near the equipment and should be easily accessible.

  • Page 10: Warning

    Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: Disconnect your Box PC from the power source when you want to work on the inside.

  • Page 11: Warranty

    Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
  • Page 12 This page is intentionally left blank. - x -...

  • Page 13: Chapter 1 - Introduction

    Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 14: The Computer

    Introduction 1.1. The Computer The ELIT-1850 is the digital signage player designed to answer the market needs for powerful video performance. The computer comes loaded with Intel Core™ i7-5650U/i3-5010U to support three displays and satisfy most ® demanding digital signage applications.

  • Page 15: Specifications

    Introduction 1.3. Specifications System Soldered onboard Intel Core™ i7-5650U, ® 2.2GHz 4M L2 Cache, up to 3.1GHz, 15W TDP Soldered onboard Intel Core™ i3-5010U, ® 2.1GHz 3M L2 Cache, 15W TDP BIOS AMI BIOS Chipset Generation Intel Core™ ULT SoC ®...
  • Page 16 Introduction Environment Operating Temp. -20 ~ 60°C (-4 ~ 140°F), ambient w/ air flow Storage Temp. -30 ~ 70°C (-22 ~ 158°F) Operating Humidity 10 ~ 95% @ 60°C (non-condensing) Vibration 3 Grms/5 ~ 500Hz/random operation Shock Operating 40G (11ms); Non-operating 80G with SSD Mechanical Construction Aluminum alloy...

  • Page 17: Inside The Package

    Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: One ELIT-1850 Digital Signage Player One Driver DVD One User’s Manual 1.5.

  • Page 18: Optional Accessories

    Introduction 1.5.1. Optional Accessories The following items are normally optional, but some vendors may include them as a standard package, or some vendors may not carry all the items. PAC-B065W-1 19V/3.4A 65W AC/DC adapter kit 1.5.2. Configure-to-Order Service Make the computer more tailored to your needs by selecting one or more components from the list below to be fabricated to the computer.

  • Page 19: Chapter 2 - Getting Started

    Chapter 2 Getting Started Chapter 2 - Getting Started - 7 -...

  • Page 20: Dimensions

    Getting Started 2.1. Dimensions The following illustration shows the dimensions of the computer, with the measurements in width, depth, and height called out. 20.00 50.00 35.00 100.00 35.00 170.00 Unit: mm - 8 -...

  • Page 21: Take A Tour

    Getting Started 2.2. Take A Tour The computer has some I/O ports, status LED light and controls on the front and rear panels. The following illustrations show all the components called out . Front View status Serial Serial port port Power USB ports button...
  • Page 22 Getting Started Rear View DC-in Line DVI-D HDMI LAN2 LAN1 port port port ports port Display port Side View - 10 -...

  • Page 23: Driver Installation Notes

    2.3. Driver Installation Notes The computer supports the operating systems of Windows 7 and Windows 8. For these operating systems, find the necessary device drivers on the CD that comes with your purchase. For different operating systems, the installation of drivers/utilities may vary slightly, but generally they are similar.
  • Page 24 This page is intentionally left blank. - 12 -...

  • Page 25: Chapter 3 - System Configuration

    Chapter 3 System Configuration Chapter 3 - System Configuration - 13 -...

  • Page 26: Board Layout

    System Configuration 3.1. Board Layout The main board FMB-i88U1 forms the engine of the computer. This section will provide an thorough view of this board. FMB-i88U1: Board Top - 14 -...

  • Page 27: Jumpers And Connectors

    System Configuration 3.2. Jumpers and Connectors The main board FMB-i88U1 comes with some connectors to join some devices and also some jumpers to alter hardware configuration. The following in this chapter will explicate each of these components. 3.2.1. Jumpers JRTC1 Function: CMOS Setting Jumper Type: Onboard 2.54mm-pitch 1x3-pin header Setting:...
  • Page 28 System Configuration JME1 Function: ME Flash function Jumper Type: Onboard 2.54mm-pitch 1x3-pin header Setting: Function Setting ME Flash Disable (Default) ME Flash Enable Board Top - 16 -...

  • Page 29: Connectors

    System Configuration 3.2.2. Connectors SATA1 Description: Serial ATA Connector Connector Type: SATA port with data & power vertical connector (7+15pin) Desc. Desc. Desc. 3.3V 3.3V 3.3V Board Top - 17 -...
  • Page 30 System Configuration JPWR1 Description: Power Connector Connector Type: 2-pole Power Terminal Block Description ADAPTER IN + ADP_GND Board Top Rear Panel - 18 -...
  • Page 31 System Configuration CN1~2 Description: USB ports Connector Type: Double-stacked type-A USB 3.0 ports Desc. Desc. USB SSRX- USB D- USB SSRX+ USB D+ USB SSTX- USB SSTX+ Front Panel Board Top - 19 -...
  • Page 32 System Configuration Description: USB ports Connector Type: Double-stacked type-A USB 2.0 ports 5 6 7 8 Lower Upper Pin Desc. Desc. 1 2 3 4 USB D- USB D- USB D+ USB D+ Front Panel Board Top - 20 -...
  • Page 33 System Configuration LAN1&LAN2 Description: Ethernet connector Connector Type: RJ-45 connector that supports 10/100/1000Mbps fast Ethernet Pin Description Pin Description MDI0 MDI3 MDI0# 10 MDI3# MDI1 11 LED2 G-O+ MDI1# 12 LED2 G+O- MDI2 13 LED1 Y- MDI2# 14 LED1 Y+ MDI3 X1 CGND X2 CGND...
  • Page 34 System Configuration COM1 & COM2 Description: Serial ports. Connector Type: External 9-pin D-sub male connector RS-232 Pin Description Description Description LPC_AD1 RS485 Mode Pin Description Description RS485_TX- RS485_TX+ Front Panel Board Top - 22 -...
  • Page 35 System Configuration JBAT1 Description: Battery connector Connector Type: 1.25mm-pitch 1x2-pin wafer connector Description battery power Board Top - 23 -...
  • Page 36 System Configuration JPH1 Function: RESET/POWER Button (For Remote) Connector Type: Onboard 2.54mm-pitch 2x3-pin header Setting: Description Reset Power ON/OFF Power LED Board Top JPH1 - 24 -...
  • Page 37 System Configuration DVI1 The computer features a DVI (digital visual interface) port, supporting DVI-D (analog only) video output. Description: DVI-D port (digital) Connector Type: 24-pin DIP-type female DVI connector w/o screw Pin Desc. Pin Desc. Pin Desc. T.M.D.S DATA 2- T.M.D.S DATA 1- T.M.D.S DATA 0- T.M.D.S DATA 2+...
  • Page 38 System Configuration Description: DP (TOP)+ HDMI (bottom) Connector Connector Type: ,DISPLAYPORT+HDMI connector The pin assignments conform to the industry standard. HDMI: The pin assignments conform to the industry standard. Board Top Rear Panel - 26 -...
  • Page 39 System Configuration JLOUT1 Description: Audio output Connector Type: Lime green 3.5mm audio jack with shield LINEOUT Description Audio Left Audio Right Audio Jack Detect Audio GND Audio GND Board Top Rear Panel - 27 -...
  • Page 40 System Configuration JMIC1 Description: Microphone Connector Type: Pink 3.5mm audio jack with shield MIC IN Description MICL MIC_R MIC1_JD AU_GND AU_GND Board Top Rear Panel - 28 -...
  • Page 41 System Configuration NGFF1 Description: NGFF Card Slot Connector Type: NGFF, 75P, KEY E, APCI0154-P002A The pin assignments conform to the industry standard. Board Top - 29 -...
  • Page 42 This page is intentionally left blank. - 30 -...

  • Page 43: Chapter 4 - Installation And Maintenance

    Chapter 4 Installation and Maintenance Chapter 4 - Installation and Maintenance - 31 -...

  • Page 44: Install Hardware

    Installation & Maintenance 4.1. Install Hardware The computer is constructed based on modular design to make it easy for users to add hardware or to maintain the computer. The following sections will guide you to the simple hardware installations for the computer. 4.1.1.
  • Page 45 Installation & Maintenance Slide out the bottom cover and remove the bottom cover from the computer. The inside of the computer comes to view. To adjust jumpers or connect/disconnect devices to/from the main board, 3.2.1. Jumpers on page 3.2.2. Connectors on page 17.

  • Page 46: Install Memory Module

    Installation & Maintenance 4.1.2. Install Memory Module The main board has one dual inline memory module (DIMM) sockets. Load the computer with a memory module of higher capacity to make programs run faster. The memory module for the computer’s SO-DIMM socket should be a 204-pin memory with a “key notch”...
  • Page 47 Installation & Maintenance Confront the memory module’s edge connector with the SO-DIMM slot connector. Align the memory module’s key notch at the break on the SO- DIMM slot connector. Memory module’s key SO-DIMM slot notch connector's break Aligh the memory module’s key notch at the SO-DIMM slot connector's break.
  • Page 48 Installation & Maintenance To uninstall the memory module: Pull back both locks from the memory module. The memory module will be auto-released from the socket. Remove the memory module. Restore the bottom cover to the computer. - 36 -...

  • Page 49: Install 2.5" Ssd Storage Device

    Installation & Maintenance 4.1.3. Install 2.5" SSD Storage Device Remove the bottom cover from the computer as described in 4.1.1. Open the Computer on page 32. The inside of the computer comes to view. See the illustration below and find the bracket for an SSD. Loosen and remove the four screws.
  • Page 50 Installation & Maintenance Fix the assemblage with four screws - two screws on each side of the bracket. Two screws on one side. The other two screws on the other side. Plug the SSD (with the bracket) to the onboard SATA connector. SATA connector Plug the SSD to the onboard SATA connector.

  • Page 51: Mount The Computer

    Installation & Maintenance 4.2. Mount the Computer Integrate the computer to where it works by mounting it to a wall in the surroundings or to the rear of a display monitor. 4.2.1. Wall-Mount Follow through the guide below to mount the computer to a wall. Find the four cutouts as marked in the illustration below: Mount the computer to a wall by the said cutouts.
  • Page 52 This page is intentionally left blank. - 40 -...

  • Page 53: Chapter 5 - Bios

    Chapter 5 BIOS Chapter 5 - BIOS - 41 -...
  • Page 54 Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit BIOS Information Choose the system default Project Version ELIT-1850 language. BIOS Version 1.00 Build Date and Time 11/17/2015 11:17:06 System Language [English] System Date...
  • Page 55 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and configure the utility. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items.

  • Page 56: Main

    Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit BIOS Information Choose the system default Project Version ELIT-1850 language. BIOS Version 1.00 Build Date and Time 11/17/2015 11:17:06 System Language [English] System Date...
  • Page 57 BIOS Key Commands BIOS Setup Utility is mainly a key-based navigation interface. Please refer to the following key command instructions for navigation process. Keystroke Function Move to highlight a particular configuration screen from the top ◄ ► menu bar / Move to highlight items on the screen ▼...

  • Page 58: Advanced

    BIOS 5.2. Advanced The “Advanced” setting page provides you the options to configure the details of your hardware, such as ACPI, CPU, SATA, AMT, USB and Super IO. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Chipset Security Boot Save &...

  • Page 59: Cpu Configuration

    BIOS USB Configuration Section 5.2.9 USB Configuration on page 55 Intel(R) Ethernet Section 5.2.10 Intel(R) Ethernet Connection I218-LM on page 57 Connection I218-LM Intel(R) I210 Giigabit Section 5.2.11 Intel(R) Ethernet Connection I210 on page 58 Network Connection 5.2.1. CPU Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.

  • Page 60: Acpi Settings

    BIOS 5.2.2. ACPI Settings Access this submenu to configure system ACPI parameters. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. ACPI Sleep State [S3 only(Suspend to RAM)] Enable Hibernation...

  • Page 61: Amt Configuration

    BIOS 5.2.3. AMT Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Enable/Disable Intel (R) Intel AMT [Enabled] Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled. This option just controls the BIOS extension execution. If enabled, this requires additional firmware in the SPI device.

  • Page 62: Super Io Configuration

    BIOS 5.2.4. Super IO Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Second Super IO Configuration Set Parameters of Serial Port 1 (COMA) Second Super IO Chip F71869A Serial Port 1 Configuration Serial Port 2 Configuration →←: Select Screen ↓↑: Select Item Enter: Select...

  • Page 63: Hardware Monitor

    BIOS 5.2.5. Hardware Monitor Select this submenu to view the main board’s hardware status. Select it to run a report of various info as depicted below: Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Pc Health Status Chipset temperature : +65 °c...

  • Page 64: S5 Rtc Wake Settings

    BIOS 5.2.6. S5 RTC Wake Settings Access this submenu to control whether the system can wake from S5 using the RTC alarm. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Enables or disables [Disabled] Wake system from S5 system wake on alarm event.

  • Page 65: Sata Configuration

    BIOS 5.2.7. SATA Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced SATA Controller(s) [Enabled] Console Redirection Enable or SATA Mode Selection [AHCI] Disable. [Default] SATA Controller Speed Serial ATA Port 0 Empty Software Preserve Unknown Port 0 [Enabled] Hot Plug [Disabled]...

  • Page 66: Csm Configuration

    BIOS 5.2.8. CSM Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced Compatibility Support Module Configuration UPON REQUEST - GA20 can be disabled using CSM16 Module Version services. ALWAYS -do 07.76 not allow disabling GA20; this option is GateA20 Active [Upon Request] useful when any RT...

  • Page 67: Usb Configuration

    BIOS 5.2.9 USB Configuration Select this submenu to view the status of the USB ports and configure USB features. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected.
  • Page 68 BIOS This is a submenu to configure the features of USB hardware delay and time-out. The featured settings are: Setting Description Use this item to set the time-out value for control, bulk, and interrupt USB transfer transfers. time-out Options available are: 1 sec, 5 sec, 10 sec, 20 sec Use this item to set USB mass storage device start unit command...

  • Page 69: Intel(R) Ethernet Connection I218-Lm

    BIOS 5.2.10 Intel(R) Ethernet Connection I218-LM Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Advanced PORT CONFIGURATION MENU Click to configure the network NIC Configuration [Disabled] device port. Blink LEDs PORT CONFIGURATION INFORMATION UEFI Driver: Intel(R) PRO/1000 6.1.16 PCI-E Adapter PBA: FFFFFF-OFF Chip Type:...

  • Page 70: Intel(R) Ethernet Connection I210

    BIOS 5.2.11 Intel(R) Ethernet Connection I210 Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit PORT CONFIGURATION MENU Click to configure the network NIC Configuration [Disabled] device port. Blink LEDs (range 0-15 seconds) PORT CONFIGURATION INFORMATION UEFI Driver: Intel(R) PRO/1000...

  • Page 71: Chipset

    BIOS 5.3. Chipset The Chipset menu controls the system’s chipset. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit System Agent (SA) Configuration Check to enable VT-d function VT-d [Enabled] on MCH. Memory Configuration PCH-IO Configuration PCI Express Configuration...

  • Page 72: Memory Configuration

    BIOS 5.3.1. Memory Configuration Select this submenu to view the system memory info Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Chipset Memory Information Memory RC Version 2.7.1.0 Memory Frequency 1600 Mhz Total Memory 8192 MB (DDR3) Memory Voltage 1.35v DIMM#1 8192 MB (DDR3)

  • Page 73: Pci Express Configuration

    BIOS 5.3.2. PCI Express Configuration Select this submenu to configure the PCI Express Ports: Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Chipset PCI Express Configuration PCI Express Root Port 1 Settings. ► PCI Express Root Port 1 ►...

  • Page 74: Hdac Configuration

    BIOS 5.3.3. HDAC Configuration Select this submenu to configure the PCI Express Ports: Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Chipset Control Detection of the Azalia HDAC Configuration device. Azalia [Enabled] Disabled = Azalia will be unconditionally disabled Enabled = Azalia will be unconditionally Enabled Auto = Azalia will be...

  • Page 75: Lan Configuration

    BIOS 5.3.4. LAN Configuration Select this submenu to configure the LAN Configuration Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Chipset Select the Video LAN Configuration Device which will be activated during POST. PCH LAN Controller [Enabled] This has no effect if Wake on LAN [Enabled] external graphics...

  • Page 76: Security

    BIOS 5.4. Security The Security menu sets up the password for the system’s administrator account. Once the administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted.

  • Page 77: Boot

    BIOS 5.5. Boot Access this Boot menu to configure how to boot up the system such as the configuration of boot device priority. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Selct the keyboard Numlock Bootup NumLock State...

  • Page 78: Save & Exit

    BIOS 5.6. Save & Exit The Save & Exit menu features a handful of commands to launch actions from the BIOS. Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Save Changes and Exit Exit system setup after saving Discard Changes and Exit the changes.

  • Page 79: Appendices

    Appendices Appendices - 67 -...

  • Page 80: Appendix A: Install M.2 Wireless Card

    Appendices Appendix A: Install M.2 Wireless Card Remove the bottom cover from the computer as described in 4.1.1. Open the Computer on page 32. The inside of the computer comes to view. See the illustration below and find the slot for an M.2 device. Prepare the Wi-Fi module kit.
  • Page 81 Appendices Press the module down and fix the module in place using one screw. Remove a plastic plug from the computer's panel to make an antenna hole. Keep the plastic plug for any possible restoration in the future. Have the RF antenna. The antenna has an SMA connector on one end and an MHF4 connector on the other.
  • Page 82 Appendices From the other end of the RF antenna, which is an SMA connector, remove the washer and the nut. Save the washer and nut for later use. Note the SMA connector has the form of a threaded bolt, with one flat side. Among the screw Remove thread, there is a...
  • Page 83 Appendices 12. Restore the computer's bottom cover 13. Have an external antenna. Screw and tightly fasten the antenna to the SMA connector. - 71 -...

  • Page 84: Appendix B: Install M.2 To 2X Mini Pcie Daughter Board

    Appendices Appendix B: Install M.2 to 2x Mini PCIe daughter board Remove the bottom cover from the computer as described in 4.1.1. Open the Computer on page 32. The inside of the computer comes to view. See the illustration below and find the slot for an M.2 device. Prepare the daughter board SCDB-1289E.
  • Page 85 Appendices Insert the daughter board completely and place it on correct potion. Fix the daughter board with screws. One of the screws is different from others, please choose the correct screw. This screw is different. - 73 -...
