For spare parts drawings refer to the section " LIST OF COMPONENTS" enclosed to this manual.
• For any further information please contact your local dealer or call:
Technical services: RAVAGLIOLI S.p.A. - Via 1° Maggio, 3 - 40037 Pontecchio Marconi - Bologna Italy
Phone (+39) 051 6781511 - Telex 510697 RAV I - Fax (+39) 051 846349 - e-mail: aftersales@ravaglioli.com
1297-M010-0_R
G2.124R
GP2.124R
INSTRUCTION MANUAL
TRANSLATION FROM THE
GB
ORIGINAL INSTRUCTIONS
1297-M010-0_R
- Rev. n. 0 (07/2014)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G2.124R and is the answer not in the manual?

Questions and answers

Related Manuals for rav G2.124R

Summary of Contents for rav G2.124R

  • Page 1 • For any further information please contact your local dealer or call: Technical services: RAVAGLIOLI S.p.A. - Via 1° Maggio, 3 - 40037 Pontecchio Marconi - Bologna Italy Phone (+39) 051 6781511 - Telex 510697 RAV I - Fax (+39) 051 846349 - e-mail: aftersales@ravaglioli.com 1297-M010-0_R...

  • Page 2: Table Of Contents

    _____ 51 12.0 FITTING THE WHEEL ON THE MANDREL _________________________ 18 21.0 CALIBRATION ____________________ 52 12.1 Fitting of the wheel (G2.124R) _______ 18 21.1 Weight measurement sensors 12.2 Fitting of the wheel (GP2.124R)______ 20 calibration __________________________ 53 21.2 “Zero chucking-table”...
  • Page 3 1297-M010-0_R INSTRUCTION, USE AND Page 3 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 22.0 ERROR SIGNALS __________________ 59 27.0 REGISTRATION PLATE DATA _____ 63 23.0 ROUTINE MAINTENANCE _________ 60 28.0 FUNCTIONAL DIAGRAMS _________ 63 Table A - Electrical and pneumatic 24.0 TECHNICAL DATA _________________ 61...
  • Page 4 3 – Distance-diameter caliper 4 – Threaded mandrel (only for G2.124R model) 5 – Protection guard 6 – Foot brake (only for G2.124R model / pneumatic mandrel open-close pedal (only for GP2.124R model) 7 – Main switch 8 – External data gauge (optional) 9 –...

  • Page 5: Symbols Used In The Manual And On The Machine

    1297-M010-0_R INSTRUCTION, USE AND Page 5 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R SYMBOLS USED IN THE MANUAL AND ON THE MACHINE Symbols Description Symbols Description Mandatory. Operations or jobs to Read instruction manual. be performed compulsorily. FORBIDDEN! Danger! Be particularly careful.
  • Page 6 1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 6 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R INFORMATION PLATE LOCATION TABLE 999914160 • 99990758 999912940 999916310 999914170 99990114 999910050 999920530 Code numbers of plates 99990114 Arrow plate 99990758 Electricity danger plate 999910050...

  • Page 7: General Introduction

    MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R INTENDED USE NOTE: SOME OF THE PICTURES The models G2.124R - GP2.124RMACHINES, and PRESENT IN THIS MANUAL HAVE relative versions, are wheels balancing machines for BEEN OBTAINED FROM PICTURES OF PROTOTYPES, THEREFORE car and light transport, projected to be used exclu-...

  • Page 8: Safety Devices

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 8 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R SAFETY DEVICES GENERAL SAFETY RULES • Master switch positioned on the rear of the ma- chine Its function is to disconnect machine electric supply. • Protection guard •...

  • Page 9: Packing And Mobilization For Transport

    1297-M010-0_R INSTRUCTION, USE AND Page 9 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R PACKING AND MOBILIZATION OPERATORS MUST WEAR SUIT- FOR TRANSPORT ABLE WORK CLOTHES, PROTEC- TIVE GLASSES AND GLOVES, AGAINST THE DANGER FROM THE SPRAYING OF DANGEROUS...

  • Page 10: Unpacking

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 10 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R UNPACKING MOBILIZATION DURING UNPACKING, ALWAYS WEAR GLOVES TO PREVENT ANY INJURY CAUSED BY CONTACT THE LIFTING EQUIPMENT MUST WITHSTAND WITH PACKAGING MATERIAL A MINIMUM RATED LOAD EQUAL TO THE (NAILS, ETC.).

  • Page 11: Working Area

    1297-M010-0_R INSTRUCTION, USE AND Page 11 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R MACHINE ASSEMBLY Working area After having freed the various components from the Fig. 3 packing check that they are complete, and that there are no anomalies, then comply with the following in- structions for the assembly of the components making use of the attached series of illustrations.

  • Page 12: Fixtures Contained In The Packing

    The packing case contains also the fixtures box. 9.3.1 Fitting the mandrel on the flange Check that all the parts listed below are there (see Fig. 5). Only for G2.124R model For G2.124R model Screw the mandrel with an Allen wrench (Fig. 6 ref. 1) Code Description on the flange (Fig.

  • Page 13: Fitting And Removal Of The Pneumatic Mandrel On The Flange

    Page 13 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 9.3.2 Fitting and removal of the pneumatic 2. Press the brake's pedal and, at the same time, tighten the internal mandrel as far as it will go using the mandrel on the flange wrench provided (Fig.

  • Page 14: Fitting Of External Data Gauge (Optional)

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 14 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 4. Close the pneumatic mandrel by means of the pedal 9.3.3 Fitting of external data gauge (option- to access the key socket (Fig.(Fig. 11). Fig. 11 1.

  • Page 15: Fitting Of Professional External Data Gauge (Optional)

    INSTRUCTION, USE AND Page 15 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 4. Connect connector (Fig. 15 ref. 1) of the cable com- 9.3.4 Fitting of professional external data ing from inside the machine to connector (Fig. 15 gauge (optional) ref.

  • Page 16: Fitting The Wheel Cover

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 16 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 5. Fasten the cable with clamps. 9.3.5 Fitting the wheel cover 6. Enable the external data gauge and carry out the 1. Mount the protection guard (Fig. 19 ref. 1) to the device's calibration.

  • Page 17: Electrical Connection

    INSTRUCTION, USE AND Page 17 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 10.0 ELECTRICAL CONNECTION 10.1 Electrical checks B E F O R E S TA R T I N G U P T H E EVEN THE TINIEST PROCEDURE...

  • Page 18: Air Connections

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 18 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 11.0 AIR CONNECTIONS 12.0 FITTING THE WHEEL ON THE MANDREL Only for GP2.124R model IN CASE OF A CHANCE SUP- To achieve perfect balancing, the wheel must be care- PLY FAILURE, AND/OR BEFORE fully and properly fitted on the mandrel.
  • Page 19 Page 19 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 4. Fit the protection cap (Fig. 23 ref. 1) in the locknut 7. Fit the cone (Fig. 25 ref. 3) with the narrowest part (Fig. 23 ref. 2) and fasten against the wheel.

  • Page 20: Fitting Of The Wheel (Gp2.124R)

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 20 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 12.2 Fitting of the wheel ( GP2.124R) Open the pneumatic mandrel by pressing “key F4” from the configuration screen play (Fig. 96), or else open by means of the special pedal, see Fig. 26.
  • Page 21 1297-M010-0_R INSTRUCTION, USE AND Page 21 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R Close the pneumatic mandrel by pressing “key F4” from the configuration screen play (Fig. 96), or else close by means of the special pedal. DURING MANDREL OPENING/...

  • Page 22: Display With Keyboard

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 22 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 13.0 DISPLAY WITH KEYBOARD 13.1 Brightness and contrast adjustment The wheel balancers are equipped with a multifunc- From the first page of the program, by keeping the tion led display, equipped with a keyboard to interact/ push button (F3) (Fig.

  • Page 23: Switching The Machine On

    1297-M010-0_R INSTRUCTION, USE AND Page 23 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 14.0 SWITCHING THE MACHINE ON By means of the 6 keys of the operating keyboard (F1-F2-CENTR-F3-B-F4) all the machine functions AND OFF can be used.

  • Page 24: Wheel Balancing

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 24 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 15.0 WHEEL BALANCING Fig. 35 STATIC mode 15.1 Determination of wheel dimensions 15.1.1 Automatic wheel dimension setting (distance and diameter) The wheel balancing machines can be featured with an automatic rod;...
  • Page 25 INSTRUCTION, USE AND Page 25 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R • To measure in ALU-S and STATIC modes: Fig. 37 Pull out the automatic rod and reach the position to be stored (see Fig. 34), maintain this for a few seconds.
  • Page 26 1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 26 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R • To take a measurement in STAT 1 and STAT 2 • To take a measurement in ALU1, ALU2, ALU3 and modes: ALU4 modes: Press “F2 key”...

  • Page 27: Manual Setting Of Wheel Dimensions

    INSTRUCTION, USE AND Page 27 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R To confirm all the entered measurements, press “CEN- 15.1.2 Manual setting of wheel dimensions In case the operator wants to edit and/or manually TR key” again .

  • Page 28: User Control Function

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 28 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R Example of ALU-S mode: 15.2 User control function To select user management, select the following key on Fig. 48 the presentation page. Wheel balancers can be used by 4 different users at the same time, by selecting the above indicated key several times, until the desired user is reached.

  • Page 29: Unbalance Measurement

    1297-M010-0_R INSTRUCTION, USE AND Page 29 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 15.3 Unbalance measurement Fig. 50 15.3.1 Dynamic balancing Dynamic balancing is a procedure that offsets the wheel vibrations using 2 weights on different planes. To perform a dynamic measurement spin: - make sure there are no stones and/or mud on the wheel;...

  • Page 30: Positioning The Correction Weights

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 30 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 15.3.2 Positioning the correction weights on 15.3.3 ALU-S procedure the wheel Make sure there are no stones and/or mud on the wheel. Remove any counterweights.
  • Page 31 1297-M010-0_R INSTRUCTION, USE AND Page 31 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R Fig. 53 Fig. 55 On reaching the 2 fixed ar- rows, fit the adhesive weight The fact that the weight fitting position is no longer at 1 –...

  • Page 32: Static Balancing

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 32 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 15.3.4 Static balancing Fig. 58 Make sure there are no stones and/or mud on the wheel. Remove any counterweights. Fit the wheel and make sure it is properly fastened (see par.

  • Page 33: Measuring The Unbalance With Auxiliary Programs

    1297-M010-0_R INSTRUCTION, USE AND Page 33 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 15.4 Measuring the unbalance with auxil- Fig. 60 iary programs The available functions permit selecting the appropri- ate weight positions to be placed in positions different to the standard ones (dynamic unbalance).
  • Page 34 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 34 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R The STATIC 1 function is a procedure that offsets wheel The ALU 2 function balances wheels with light alloy vibrations using a single adhesive weight on a single rims by fitting adhesive weights on the outside and plane positioned exactly at 12 o’...

  • Page 35: Alu 1 Procedure

    INSTRUCTION, USE AND Page 35 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R The PAX function is a procedure that permits balancing 15.4.1 ALU 1 procedure PAX wheels using adhesive weights at pre-set distances Make sure there are no stones and/or mud on the to offset wheel unbalance.
  • Page 36 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 36 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R To fit the adhesive weight on the inner part of the wheel, Fig. 63 turn the wheel in the direction of the arrows until the correct position is reached (the two arrows must be horizontal).

  • Page 37: Pax Mode

    1297-M010-0_R INSTRUCTION, USE AND Page 37 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R Fig. 68 Fit weight on the position where Fig. 67 pliers touches the wheel Check the wheel balancing conditions and make a 1 – Types of wheels trial spin.

  • Page 38: Recalculation Function

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 38 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 15.5 Recalculation Function 15.6 ECO-WEIGHT procedure After making a spin, the wheel automatically stops, After making the wheel spin in ALU-S mode, the moni- and the required weight/s and its/their position is/are tor shows the total of 2 adhesive weights to precisely always indicated.

  • Page 39: Wheel Balancing In Motorbike Mode

    INSTRUCTION, USE AND Page 39 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 16.0 WHEEL BALANCING IN MOTOR- Remove the automatic gauge and fit the adhesive weight in the pliers as shown in Fig. 71, using a weight of pre- BIKE MODE determined value (the example in Fig.

  • Page 40: Split Procedure

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 40 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 17.0 SPLIT PROCEDURE Fig. 75 The Split procedure proves useful when the dynamic unbalance (see Par. 15.3.1) of a wheel is fairly high and the weight to be fitted is not available, for instance a 100 g weight.
  • Page 41 1297-M010-0_R INSTRUCTION, USE AND Page 41 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R TWO SMALLER WEIGHTS (55g) Press the key relating to the SPLIT function USING SPLIT PROCEDURE , the system will display the page in Fig. 78.
  • Page 42 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 42 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R At this point, the system will display the quantity of Fig. 81 the two weights to be fitted on the wheel (see Fig. 80). Arrows to help positioning in correction...

  • Page 43: Weights Hidden Behind Spokes

    1297-M010-0_R INSTRUCTION, USE AND Page 43 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 18.0 WEIGHTS HIDDEN BEHIND Fig. 84 SPOKES MODE Adhesive correction weight positioning may not look at- tractive on some types of rims. In this case, the "weights hidden behind spokes"...
  • Page 44 1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 44 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R Fig. 86 Fig. 88 Exact weight fitting position in- side the spoke Exact position of wheel for fit- 1 – Arrows to help positioning in correction weight...

  • Page 45: Matching Procedure (Rim - Tyre Optimisation)

    INSTRUCTION, USE AND Page 45 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 19.0 MATCHING PROCEDURE (Rim - Make a reference mark, using chalk for instance, of the position of the rim and tyre, remaining in line with Tyre Optimisation)
  • Page 46 INSTRUCTION, USE AND MAINTENANCE MANUAL Page 46 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R Fit the wheel back on the wheel balancer, positioning Cancel the previously made reference marks. the reference mark on the rim in line with the arrow Position the wheel following the arrows on the display on the flange.

  • Page 47: Setup Of Measurement, Resolution, Width Measurement Options And Setting Car/ Motorcycle Mode

    1297-M010-0_R INSTRUCTION, USE AND Page 47 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 20.0 SETUP OF MEASUREMENT, RESO- Fig. 95 LUTION, WIDTH MEASUREMENT OPTIONS AND SETTING CAR/MO- TORCYCLE MODE 20.1 Unit for measuring the weight and width/diameter of the rim The weight determining wheel unbalance can be in- dicated on the display in "gram"...
  • Page 48 1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 48 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R Type in the password F1-F2-CENTR-F3, The program will show the screen page in Fig. 98: Press the “F3 key” to change the width and diameter unit of measurements from inches to millime- Fig.

  • Page 49: Setting Preview Result Of Static And Eco-Weight

    1297-M010-0_R INSTRUCTION, USE AND Page 49 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 20.2 Setting preview result of static and 20.3 Width measurement options setting eco-weight To enable the “automatic rim width measurement”, optional devices, from the opening presentation page During the ECO-WEIGHT procedure (see Par.

  • Page 50: Lower Weight Limit

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 50 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R When the device is enabled, this is shown by a “mark 20.4 Lower weight limit off”, see example below: Correction weight below a certain limit is normally shown equal to zero.

  • Page 51: Setting Adhesive Weight Dimensions And Static Threshold Percentage

    1297-M010-0_R INSTRUCTION, USE AND Page 51 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R Move the selection line under the option to be changed 20.5 Setting adhesive weight dimensions and static threshold percentage by means of the “F2 key”...

  • Page 52: Calibration

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 52 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 21.0 CALIBRATION Move the selection line under the option to be changed From program presentation screen page (see Fig. 33) using “key F2” . Set the adhesive weight di- press “F1 key”;...

  • Page 53: Weight Measurement Sensors Calibration

    1297-M010-0_R INSTRUCTION, USE AND Page 53 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 21.1 Weight measurement sensors calibra- As shown in Fig. 108, press the “F4 key” to perform a wheel spin without adding weights. tion After making the spin, the program will show Fig. 109: Fit a wheel of medium size, possibly balanced (Ø...

  • Page 54: Zero Chucking-Table" Setting Without Anything

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 54 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R The calibration operation is now over. The program Fig. 113 will show Fig. 105. Press the "CENTRE key" to return to the first program page.
  • Page 55 INSTRUCTION, USE AND Page 55 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R Press “CENTRE” to confirm the measurement Fig. 114 Fit a wheel with ø 15” and set the correct internal diameter in mm by selecting the Fig. 116 “PLUS” or “MINUS”...

  • Page 56: Automatic Rim Width Measuring Device Calibration (Optional)

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 56 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R Turn the gauge ferrule (Fig. 117 ref. 1) on the inner IF THE AUTOMATIC RIM WIDTH edge of the wheel UPWARDS and press “F4”. MEASURING DEVICE IS ENABLED, THE CALIBRATION PAGE WILL Fig.
  • Page 57 1297-M010-0_R INSTRUCTION, USE AND Page 57 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R Fig. 120B SCREW CHUCK Fig. 120A GAR304 1 – Exit from the width measurement calibration procedure and return to calibration menu page (RED) (F1) 2 – Confirm storing of width measuring device posi- tion on "end of shaft"...
  • Page 58 1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 58 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R Fig. 122B Fig. 122A GAR306 1 – Return to previous screen page (RED) (F1) 2 – Confirms width measuring device on "external flange surface” (CENTRAL) Press “CENTRE”...

  • Page 59: Error Signals

    Page 59 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 22.0 ERROR SIGNALS During wheel balancer operation, if wrong commands are given by the operator or device faults occur, an error code or symbol may appear on the display screen. Press key F1/ to return to the previous program phase after remedying the fault.

  • Page 60: Routine Maintenance

    INSTRUCTION, USE AND MAINTENANCE MANUAL Page 60 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 23.0 ROUTINE MAINTENANCE To guarantee the efficiency and correct functioning of the machine, it is essential to carry out daily or BEFORE CARRYING OUT ANY ROU-...

  • Page 61: Technical Data

    1297-M010-0_R INSTRUCTION, USE AND Page 61 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 24.0 TECHNICAL DATA G2.124R GP2.124R Wheel max. weight (Kg) Max. absorbed voltage (W) Power supply 230V 50/60 Hz 1 ph Balancing precision (g) ± 1 Balancing speed (rpm) <...

  • Page 62: Dimensions

    1297-M010-0_R INSTRUCTION, USE AND MAINTENANCE MANUAL Page 62 of 64 RAVAGLIOLI S.p.A. G2.124R - GP2.124R 24.1 Dimensions Fig. 123 1161 920* 1175 1126 1285* * Optional...

  • Page 63: Storing

    1297-M010-0_R INSTRUCTION, USE AND Page 63 of 64 MAINTENANCE MANUAL RAVAGLIOLI S.p.A. G2.124R - GP2.124R 25.0 STORING 27.0 REGISTRATION PLATE DATA If storing for long periods disconnect the main power supply and take measures to protect the machine from dust build-up. Lubricate parts that could be damaged from drying out.

  • Page 64: Connection Diagram

    10 – Pneumatic mandrel control pedal microswitch (only 20 – Width Measurement Potentiometer for GP2.124R) 21 – Functional keyboard 11 – Motor in d.c. G2.124R - GP2.124R 1297-M010-0_R ELECTRICAL AND PNEUMATIC CONNECTION DIAGRAM Page 64 of 64 Table N°A - Rev. 0...
  • Page 65 Technical services: RAVAGLIOLI S.p.A. - Via 1° Maggio, 3 - 40037 Pontecchio Marconi - Bologna Italy Phone (+39) 051 6781511 - Telex 510697 RAV I - Fax (+39) 051 846349 - e-mail: aftersales@ravaglioli.com 1297-R010-0_R - Rev. n. 0 (07/2014)
  • Page 66 LISTA DEI COMPONENTI Pag. 2 di 22 LIST OF COMPONENTS TEILELISTE LISTE DES PIECES DETACHEES G2.124R - GP2.124R RAVAGLIOLI S.p.A. LISTA DE PIEZAS 1297-R010-0_R SOMMARIO - SUMMARY - INHALT SOMMAIRE - SUMARIO Tavola N°1 - Rev. 0 ____ ....... 3 Tavola N°9A - Rev.
  • Page 67 LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE ASSIEME GENERALE Pag. 3 di 22 LISTE DES PIECES DETACHEES - LISTA DE PIEZAS MAIN ASSEMBLY GENERALSATZ ASSEMBLAGE GENERAL Tavola N°1 - Rev. 0 G2.124R - GP2.124R JUNTO GENERAL RAVAGLIOLI S.p.A. 1297-R010-0_R...
  • Page 68 LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE ASSIEME GENERALE MAIN ASSEMBLY LISTE DES PIECES DETACHEES - LISTA DE PIEZAS GENERALSATZ ASSEMBLAGE GENERAL Tavola N°1 - Rev. 0 G2.124R - GP2.124R RAVAGLIOLI S.p.A. JUNTO GENERAL Tav. Cod. Pos. G2.124R GP2.124R...
  • Page 69 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO MOTORE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS MOTOR UNIT Pag. 5 di 22 MOTORSATZ GROUPE MOTEUR Tavola N°2 - Rev. 0 129690073 GRUPO MOTOR RAVAGLIOLI S.p.A.
  • Page 70 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO ROTANTE COMPLETO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS COMPLETE ROTARY UNIT Pag. 6 di 22 KOMPLETTER ROTIERENDER SATZ GROUPE ROTATIF COMPLET Tavola N°3A - Rev. 0...
  • Page 71 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO ROTANTE COMPLETO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS COMPLETE ROTARY UNIT Pag. 7 di 22 KOMPLETTER ROTIERENDER SATZ GROUPE ROTATIF COMPLET Tavola N°3B - Rev. 0...
  • Page 72 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO FRENO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BRAKE UNIT Pag. 8 di 22 BREMSATZ GROUPE FREIN Tavola N°4 - Rev. 0 129690292 GRUPO FRENO RAVAGLIOLI S.p.A.
  • Page 73 10 17 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO TELAIO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS FRAME UNIT Pag. 9 di 22 RAHMENSATZ GROUPE CHASSIS Tavola N°5 - Rev. 0 129793150 GRUPO ESTRUCTURA RAVAGLIOLI S.p.A.
  • Page 74 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PLANCIA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BOARD UNIT Pag. 10 di 22 BRETTSATZ GROUPE PLANCHE Tavola N°6 - Rev. 0 129793160 GRUPO TABLERO RAVAGLIOLI S.p.A.
  • Page 75 18 20 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO CALIBRO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS TESTER UNIT Pag. 11 di 22 KALIBERSATZ GROUPE CALIBRE Tavola N°7A - Rev. 0 129690331 GRUPO CALIBRE RAVAGLIOLI S.p.A.
  • Page 76 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO CALIBRO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS TESTER UNIT Pag. 12 di 22 KALIBERSATZ GROUPE CALIBRE Tavola N°7B - Rev. 0 129690380 GRUPO CALIBRE RAVAGLIOLI S.p.A.
  • Page 77 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO AZIONAMENTO FRENO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BRAKE OPERATION GROUP Pag. 13 di 22 SATZ FÜR BREMSBETÄTIGUNG GROUPE ACTIONNEMENT FREIN Tavola N°8 - Rev. 0...
  • Page 78 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PEDALE FRENO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BRAKE PEDAL UNIT Pag. 14 di 22 BREMSE PEDALSATZ GROUPE PÉDAL FREIN Tavola N°9A - Rev. 0...
  • Page 79 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PEDALE FRENO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS BRAKE PEDAL UNIT Pag. 15 di 22 BREMSE PEDALSATZ GROUPE PÉDAL FREIN Tavola N°9B - Rev. 0...
  • Page 80 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO IMPIANTO ELETTRICO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS ELECTRICAL SYSTEM UNIT Pag. 16 di 22 SATZ VON ELEKTROANLAGE GROUPE INSTALLATION ÉLECTRIQUE Tavola N°10 - Rev. 0 129690341 GRUPO INSTALACIÓN ELÉCTRICA...
  • Page 81 5 4 7 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE GRUPPO PROTEZIONE RUOTA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS WHEEL PROTECTION UNIT Pag. 17 di 22 SATZ FÜR RADSCHUTZ GROUPE PROTECTION ROUE Tavola N°11 - Rev.
  • Page 82 G2.124R GP2.124R   LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE IMPIANTO SERRAGGIO PNUEMATICO LISTE DES PIECES DETACHEES - LISTA DE PIEZAS PNEUMATIC TIGHTENING SYSTEM Pag. 18 di 22 ANLAGE FÜR PNEUMATISCHE AUFSPANNUNG SYSTÈME SERRAGE PNEUMATIQUE Tavola N°12 - Rev. 0 129390311 SISTEMA APRIETE NEUMÁTICO...
  • Page 83 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DOTAZIONE A LISTE DES PIECES DETACHEES - LISTA DE PIEZAS A EQUIPMENT Pag. 19 di 22 AUSSTATTUNG A DOTATION A Tavola N°13A - Rev. 0 DOTACION A RAVAGLIOLI S.p.A.
  • Page 84 G2.124R GP2.124R  LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE DOTAZIONE B LISTE DES PIECES DETACHEES - LISTA DE PIEZAS B EQUIPMENT Pag. 20 di 22 AUSSTATTUNG B DOTATION B Tavola N°13B - Rev. 0 DOTACION B RAVAGLIOLI S.p.A.
  • Page 85 59 60 G2.124R GP2.124R LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE CALIBRO LARGHEZZA PROFESSIONALE LISTE DES PIECES DETACHEES - LISTA DE PIEZAS PROFESSIONAL EXTERNAL DATA GAUGE Pag. 21 di 22 BERUFLICHE BREITENLEHRE CALIBRE LARGEUR PROFESSIONEL Tavola N°14 - Rev. 0...
  • Page 86 G2.124R GP2.124R LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE CALIBRO LARGHEZZA LISTE DES PIECES DETACHEES - LISTA DE PIEZAS WIDTH CALIPER Pag. 22 di 22 KALIBER FÜR BREITE CALIBRE LARGEUR Tavola N°15 - Rev. 0 129590710 CALIBRE ANCHO RAVAGLIOLI S.p.A.
