OPERATION & SAFETY
INSTRUCTIONS
VORTEC COOLING VEST
AND COOLING TUBE
I M P O R T A N T
Please read all instructions BEFORE attempting to use this product
Pelmar Engineering Ltd.
Tel. (888) 754-6329, (416) 288-1736
E-mail: sales@pelmareng.com
Web site: www.pelmareng.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vest-L and is the answer not in the manual?

Questions and answers

Summary of Contents for Vortec Vest-L

  • Page 1 OPERATION & SAFETY INSTRUCTIONS VORTEC COOLING VEST AND COOLING TUBE I M P O R T A N T Please read all instructions BEFORE attempting to use this product Pelmar Engineering Ltd. Tel. (888) 754-6329, (416) 288-1736 E-mail: sales@pelmareng.com Web site: www.pelmareng.com...
  • Page 2: General Safety Considerations

    5. When using compressed air, wear safety glasses with side shields. Introduction Vortec Cooling Tubes are designed to be used with Vortec Cooling Vests to provide worker comfort in extreme temperature environments. The vortex tube technology utilized in the Cooling Tube uses filtered compressed air to focus chilled air on the user’s torso through the Cooling Vest.
  • Page 3: Maintenance

    (See Table 1). The Cooling Tube can supply chilled air to the Vortec Cooling Vest or to a hood or helmet. When purchased with the vest, the cooling tube is inserted into a sleeve on the vest; when purchased separately, the Cooling Tube is supplied with a belt, with the Cooling Tube in a horizontal orientation on the user’s waist.
  • Page 4 Figure 1: Vortec Cooling Tube with belt installed for horizontal orientation Hot air exhaust Cold air outlet Temperature adjustment knob (3/4” garden hose thread) 1/4” Industrial interchange quick connect nipple Figure 2: Vortec Cooling Tube with belt installed for vertical orientation...
  • Page 5 VEST MODEL NUMBER MATRIX Cooling Vest (L) Cooling Vest (XL) Cooling Vest (2XL) Cooling Tube with Belt Model Number 22825 22835 22835 Replacement Vest Model Number Vest-L Vest-XL Vest-2XL 1500 BTUH 2500 BTUH 2500 BTUH Cooling Capacity (378 kCal/hr) (630 kCal/hr)
