Multitech CommPlete MR9600-100 User Manual

Multi-tech mr9600-100 controllers: user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MR9600-100 Controller
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CommPlete MR9600-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Multitech CommPlete MR9600-100

Summary of Contents for Multitech CommPlete MR9600-100

  • Page 1 MR9600-100 Controller User Guide...
  • Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes.

  • Page 3: Federal Communications Commission Statement

    The battery can maintain the setup information for approximately 10 years with no external power, and longer when the MR9600-100 is turned on and operating normally. This battery is soldered onto the circuit board and cannot be replaced by the user.
  • Page 4 CommPlete Communications Server...

  • Page 5: Table Of Contents

    1 Introduction Introduction ... 2 Product Description ... 2 LED Indicators... 2 Card Status LEDs ... 3 MR9600-100 Ethernet Status LEDs ... 3 Ethernet Switch LEDs ... 4 Connectors... 4 Duplex Mode Jumpers ... 5 MR9600-100 Controller Specifications ... 5 Ethernet Switch Specifications ...
  • Page 6 Parameter Types ...24 Commands Listed by Function...26 Commands Listed by Security Level...30 Command Reference...33 Error Messages...77 5 Solving Problems Introduction ...82 MR9600-100 Diagnostic Tests ...82 Appendix A - Connector Pinouts ... 85 RJ-45 Connectors ...85 Index ... 89 CommPlete Communications Server...
  • Page 7 1 Introduction 82067502...

  • Page 8: Introduction

    100) into a CommPlete Communications Server chassis. This manual also contains a reference guide to the commands that are used to configure and control the MR9600-100. For configuration instructions, refer to the System Installation and Quick Start section of you CommPlete documentation set.

  • Page 9: Card Status Leds

    CC9600 chassis. The slots are numbered 1 through 16 from left to right. The LEDs indicate the state of the device cards installed in the CC9600 chassis. When the MR9600-100 is turned on, the lights go through the following sequence before they act as status indicators for the device cards.

  • Page 10: Ethernet Switch Leds

    MR9600-100 User Guide Ethernet Switch LEDs The upper part of the MR9600-100 front panel contains 10 status indicators for the Ethernet switch. LED Indicator UTILIZATION CC9600 (LINK) LAN (LINK) CC9600 (100 MB) LAN (100 MB) Connectors The MR9600-100 has three connectors that are accessible from the rear of the CC9600 chassis.

  • Page 11: Duplex Mode Jumpers

    Duplex Mode Jumpers The MR9600-100 must be set to the proper duplex mode for all ports. To set the duplex mode, change the Duplex Mode jumpers on the back of the MR9600-100. Note that it is not necessary to turn off the device when changing the duplex mode setting.

  • Page 12: 100Base-Tx Technology Overview

    Cables and Connectors The MR9600-100 supports Category 5 unshielded twisted-pair (UTP) cables. Cat 5 UTP cable uses the same RJ-45 connector used with 10BASE-T, wired in the same configuration. Please note that the punch- down blocks in the wiring closet must also be Category 5 certified.

  • Page 13: Network

    technology such as stackable hubs, coupled with the decreasing cost of switches, bridges, and routers, allow the design of low-cost, efficient Fast Ethernet workgroups and enterprise LANs. The following factors strongly influence the architecture of Fast Ethernet networks: • The EIA/TIA 568 Wiring Standard imposes a 100 meter limit on horizontal runs of twisted-pair cables; that is, connections from the wiring closet to the end-station.

  • Page 14: Benefits Of Switching

    MR9600-100 User Guide The difference between switched Ethernet (10Mbps, 100Mbps, or both) and traditional Ethernet is analogous to the difference between a private phone line and a party line. With switched Ethernet, each workgroup has a “private line” so that transmitted packets don’t have to wait as long to gain access to the network.
  • Page 15 1 Introduction CommPlete Communications Server...

  • Page 17: Installation

    Installation 82067502...

  • Page 18: Introduction

    The MR9600-100 Controller assembly consists of the MR9600-100 Controller card, an integrated Ethernet switch card, and a common front panel. Figure 3 shows the layout of the MR9600-100 card without the switch. The MR9600-100 assembly plugs into bus connectors on the inside of the CC9600 chassis. Three...

  • Page 19: Serial Cabling

    Network Connections If any port on the MR9600-100 is set for full duplex operation, the device (or LAN) connected to that port must also be set for full duplex operation. Refer to the following sections on 10M bps and 100M bps ports for specific requirements.

  • Page 20: Setting The Duplex Mode (Jp1-Jp5)

    Refer to the figures below for 10M bps Half-duplex/Full-duplex mode jumper locations and settings. Note that it is not necessary to turn off power to the MR9600-100 when changing the duplex mode setting. JP1 JP2 JP3 JP4 Figure 4.
  • Page 21 2 Hardware Installation In the figure above, port #1 (“P1”) is set to full-duplex operation by placing the shorting plug over the top two pins of jumper JP5. Port #5 (“P1”) is set to full-duplex operation by placing the shorting plug over the bottom two pins of JP1. CommPlete Communications Server...
  • Page 22 MR9600-100 User Guide CommPlete Communications Server...

  • Page 23: Operation

    3 Operation 82067502...

  • Page 24: Introduction

    HH is the hour, and YY is the last two digits of the year. When the drive fills up, the oldest .HR file is deleted. The number of events your MR9600-100 will hold depends on the number of calls you receive in a day.

  • Page 25: Snmp Interface

    The command line prompt is the current directory followed by a # character. You can switch between the MR9600-100’s two drives, A and B, by using the cd command or by typing A: or B:. A standard set of DOS and UNIX file system commands are available, though in limited fashion (no wildcards are supported, etc.).

  • Page 26: Telnet Interface

    Telnet is a standard Internet protocol that allows a remote connection between two systems connected to a TCP/IP network such as the Internet. The MR9600-100 can be managed remotely by using Telnet. Telnet can give the user access to all management functions through the command line interface.

  • Page 27: Logging In

    Logging In Whenever you access the MR9600-100 for the first time during a browser session, you will be prompted for a user ID and password. You must log in as someone of security level operator or higher to get access to the Web interface.

  • Page 29: Commands

    4 Commands 82067502...

  • Page 30: Parameter Types

    MR9600-100 User Guide Parameter Types Many MR9600-100 commands require a parameter to complete the command. Most of the required parameters fall into one of the four following types. Pathname Description: A DOS-style path and/or file name. A partial path assumes the current directory.
  • Page 31 4 Commands IP Address Mask Description: An IP address string consisting of four decimal numbers separated by periods, in which only the decimal numbers 255 and 0 are permitted. It is used to select a set or range of IP addresses. The standard Class A mask is 255.0.0.0, the standard Class B mask is 255.255.0.0, and the standard Class C mask is 255.255.255.0.

  • Page 32: Commands Listed By Function

    MR9600-100 User Guide Commands Listed by Function This section lists the MR9600’s commands alphabetically by the following functions: Display, Environment, File, Modem Control, and Security. For an expanded description of each command, see “Command Reference” on page 33. Display Command Name...
  • Page 33 setgateway setip setpollingoff setpollingon setrasostype setreadcommunity setsendtrap setsubnet settrap setwritecommunity t1cfg t1debug t1setup t1status time update uptime version, ver File Command Name cd, chdir copy, cp del, delete download md, mkdir online CommPlete Communications Server IP Address Configure the gateway address IP Address Configure the IP address Device...
  • Page 34 MR9600-100 User Guide rd, remdir ren, rename rendir sync type upload Modem Control Command Name cfg, configure getfkey1–getfkey4 oc, oosclear online oosset, os reset, rs setconfig setfkey1–setfkey4 test usage Security Command Name lo, logout passwd, password security userid whoami Pathname...
  • Page 35 System Command Name abort boot exit format history quit mount readme unmount CommPlete Communications Server Parameters Description None Changes the drive the user is to work with None Changes the drive the user is to work with None Cancels update procedure of modem and T1 cards None Reboot MR9600 None...

  • Page 36: Commands Listed By Security Level

    MR9600-100 User Guide Commands Listed by Security Level This section lists the MR9600’s commands by security level. The security levels are Guest, Operator, and Supervisor. For an expanded description of each command, see “Command Reference” on page 33. Guest Command Name...
  • Page 37 Operator Command Name abort cfg, configure copy, cp date, d getcalls getfaults getfkey1–getfkey4 getmodems getrack getslots oc, oosclear online oosset, os pristatus prisetup readme reset, rs se, setenviron setconfig setfkey1–setfkey4 setrasostype sync t1cfg test time update uptime CommPlete Communications Server Parameters Description None...
  • Page 38 MR9600-100 User Guide usage Supervisor Command Name boot bpstatus del, delete download format getreadcommunity getwritecommunity md, mkdir mount rd, remdir ren, rename rendir setgateway setip setpollingoff setpollingon setreadcommunity setsendtrap setsubnet settrap setwritecommunity t1debug t1setup unmount upload userid Specifier Displays how many modems: received or made calls,...

  • Page 39: Command Reference

    Command Reference This section describes the MR9600’s commands in alphabetic order. For a description of the parameters, see “Parameter Types” on page 24. Parameter: None Description: Displays an alphabetic list of the available commands. Security: Guest Parameter: None Description: Changes the drive the user is to work with. Security: Guest Example: [01] B:\# A:...
  • Page 40 MR9600-100 User Guide Parameter: Command history index. Description: Repeats the command whose index is indicated by the parameter. The command index is the number shown in the prompt when the command is executed. The command that is executed is then placed into the history buffer at the current command index.
  • Page 41 4 Commands abort Parameter: None Description: Cancels update procedure of modem and T1 cards Security: Operator Example: [03] B:\MMM # Update hd8-100d.hex 3a Update started [04] B:\MMM # Abort Are you sure you wish to abort the update? (y/n) y Aborting ...
  • Page 42 MR9600-100 User Guide bpstatus Parameter: None Description: Displays the rack’s back plane polling activity between the controller and each powered device. Each correctly operating device responds to three specific polls; “Busy”, “No Response”, and “No Acknowledgement”. If the device does not respond the counter/s will increment. The example below shows all devices in a fully loaded CC9600 are responding correctly.
  • Page 43 4 Commands Parameter: Pathname Description: Displays the contents of the ASCII text file referred to by Pathname . Security: Guest Limitations: The cat command is more similar to the DOS type command than it is to the UNIX cat command. Example: [0] A:\MMM # cat mr9600.ini [SecurityFile]...
  • Page 44 MR9600-100 User Guide cl, clock Parameter: None Description: Displays current date and time (24 hour clock). Security: Guest Limitations: The time does not change automatically with daylight savings time. Example: [0] A:\MMM # cl 4/15/97 1:20pm [1] A:\MMM # configure See cfg.
  • Page 45 Description: Deletes the file specified by Pathname . The file is permanently destroyed, and cannot be recovered. Security: Supervisor Example: [0] A:\MMM # del mr9600.old [1] A:\MMM # dir, ls Parameter: Pathname or none Description: The dir and ls commands display the contents of the current directory by file name, file size, and date;...
  • Page 46 MR9600-100 User Guide download Parameter: Pathname Description: Downloads the file specified by pathname from the MR9600 to a computer connected to the MR9600 controller’s serial port connector on the back of the CC9600 chassis. The files are downloaded as hexadecimal values in ASCII text format.
  • Page 47 getcalls Parameter: Device or none Description: Displays call traffic for the modems listed in device . If there is no parameter, call traffic is listed for every installed modem. Security: Supervisor Example: [0] A:\ # [1] A:\ # getcalls Modem DateTime 1A No Calls 1B No Calls...
  • Page 48 MR9600-100 User Guide getfkey1, getfkey2, getfkey3, getfkey4 Parameter: None Description: Displays the current configuration for the specified online function key. These function keys can be used when one is online with a modem. See online . Security: Operator Example: [0] A:\ # getfkey1...
  • Page 49 getmodems Parameter: Device or none Description: Displays the current status for the modems specified by device . If there is no parameter, current status is displayed for every installed modem. Security: Operator Example: [0] A:\ # getmodems Modem Current State Inventory 1A Idle default.cfg...
  • Page 50 MR9600-100 User Guide Chan 21: Ready Chan 23: Ready Chan 25: Ready Chan 27: Ready Chan 29: Ready Modem Channels (card 1) Chan 01 (3A): Idle Chan 03 (3C): Idle Chan 05 (3E): Idle Chan 07 (3G): Idle Chan 09 (3I): Idle...
  • Page 51 4 Commands getrack Parameter: None Description: Displays the current Rack Type. Security: Supervisor Example: getrack Chassis Type: CC2400 single segment chassis [2] A:\ # getreadcommunity Parameter: None Description: Displays the Read community settings. Security: Supervisor Example: [0] A:\MMM # getreadcommunity Read community = public Enter SETREADCOMMUNITY <community-string>...
  • Page 52 MR9600-100 User Guide getslots Parameter: None Description: Displays hardware type and location within the rack. This command also displays the number of devices in each slot. Security: Operator Example: [0] A:\ # getslots MTRAS96-T1A MT5634HD8 MT5634HD8 MT5634HD8 getsubnet Parameter: None Description: Displays the subnet mask for the MR9600.
  • Page 53 [0] A:\MMM # getwritecommunity Write community = public Enter SETWRITECOMMUNITY <community-string> to change it. [1] A:\MMM # history Parameter: None Description: Displays the command history buffer. Security: Guest Example: [4] A:\ # history 0 VER 1 CLOCK 2 VER 3 CLOCK 4 HISTORY [5] A:\ # lo, logout...
  • Page 54 MR9600-100 User Guide md, mkdir Parameter: Pathname Description: Make directory. The md command creates a directory with the path and file name assigned by the pathname parameter. Security: Supervisor Example: [0] A:\MMM # md mr.log [1] A:\MMM # cd mr.log [2] A:\MMM\MR.LOG #...
  • Page 55 oc, oosclear, oosclr Parameter: Device Description: Puts the specified devices in service by clearing the Out Of Service flag. Security: Operator Limitations: There is no effect if the Out Of Service flag is not set for the modems. Example: [0] A:\MMM # oc 1a [1] A:\MMM # online Parameter: Device...
  • Page 56 MR9600-100 User Guide <esc>n ==== Current device is: Slot 6 Device B ==== atl5 B1 E1 M1 Q0 R0 V1 X4 &E1 &E4 &E6 &E8 &E10 &E13 &E15 %C0 #C1 *C0 &C1 *H0 $MB28800 $SB57600 $BA0 &W1 <esc>n ==== At end of list: Slot 6 Device C ==== atl5 B1 E1 M1 Q0 R0 V1 X4 &E1 &E4 &E6 &E8 &E10 &E13 &E15 %C0 #C1 *C0...
  • Page 57 passwd, password Parameter: None Description: The passwd command allows you to change your password by prompting you for the current password and a new password. Security: Guest Example: [0] A:\MMM # passwd Current password: ***** New password: ***** Repeat new password: ***** Security information updated [1] A:\MMM # priosbchannels...
  • Page 58 MR9600-100 User Guide Chan 05 (4E): Idle Chan 07 (4G): Idle Chan 09 (4I): Idle Chan 11 (4K): Idle Chan 13 (4M): Idle Chan 15 (4O): Idle [05] A:\# priocbchannels Parameter: < device>.<channel> Description: Sets the specified channel in service...
  • Page 59 4 Commands prisetup Parameter: Specifier Description: Set Configuration parameters for a PRI card. Security: Operator Example: [01] A:\# prisetup 2a pristatus Parameter: Specifier Description: Retrieve the current status of the specified PRI card Security: Operator Example: [01] A:\# pristatus 2a quit Parameter: None Description: Logs the User off of the system.

  • Page 60: Ren, Rename

    MR9600-100 User Guide rd, remdir Parameter: Pathname Description: Remove directory. The rd command deletes the directory specified by pathname . Security: Supervisor Limitations: The directory must be empty before rd can delete it. The rd command cannot delete a directory’s subdirectories.
  • Page 61 4 Commands See del. See reset. CommPlete Communications Server...
  • Page 62 MR9600-100 User Guide se, setenviron Parameter: None Description: Allows you to check or change the environment values for the MR9600. The IP address, default trap IP, gateway IP, subnet mask, and community strings may all be changed. Security: Supervisor Example:...
  • Page 63 Enter Selection (<1>,2,3,4,5,6, q, -): Frame Type 1. TYPE_II 2. SNAP Enter Selection (<1>,2, q, -): Address Method 1. via DHCP server 2. Address pool 3. Per port config 4. RADIUS Enter Selection (1,2,<3>,4, q, -): Wan Port IPCP 1. Disabled 2.
  • Page 64 MR9600-100 User Guide 1. Binary 8 Zero Substitution (B8ZS) 2. Alternate Mark Inversion (AMI) 3. ZBTSI Enter Selection (<1>,2,3, q, -): FXS Signaling Options 1. E&M Wink Start 2. E&M Immediate Start 3. Ground Start 4. Loop Start Enter Selection (<1>,2,3,4, q, -): Transmit Level 1.
  • Page 65 1. Controller Setup 2. Ras Setup 3. T1 Setup Enter Selection (1,<2>,3, q, -): Configure a Ras Card (1A, <->): 1a Operating System:Ras Express 5.2 (or later) Operating System 1. Ras Express pre(5.2) 2. SCO Unix 3. Windows NT 4. Novell Netware 5.
  • Page 66 MR9600-100 User Guide Start 2nd Exclusion:0.0.0.0 End 2nd Exclusion:0.0.0.0 Address Pool Start (<192.168.90.10>, q, -): Address Pool End (<192.168.90.33>, q, -): Start 1st Exclusion (<0.0.0.0>, q, -): End 1st Exclusion (<0.0.0.0>, q, -): Start 2nd Exclusion (<0.0.0.0>, q, -): End 2nd Exclusion (<0.0.0.0>, q, -): Default Gateway:192.168.90.1...
  • Page 67 Enter Selection (<1>,2,3,4, q, -): Transmit Level 1. - 0.0dB 2. - 7.5dB 3. -15.0dB 4. -22.5dB Enter Selection (<1>,2,3,4, q, -): FXS Signaling Options:E&M Wink Start Save changes and config the T1? (<y>, n): n Settings have not been changed Configure a T1 Card (1B, <->): [1] A:\ # security...
  • Page 68 MR9600-100 User Guide setconfig Parameter: Pathname Device Description: Associates a configuration file with a particular modem or modems . Security: Operator Example: [0] A:\ # getmodems 2A Idle default.cfg 2B Idle default.cfg 2C Idle default.cfg 4A Idle default.cfg 4B Idle default.cfg...
  • Page 69 4 Commands setfkey1, setfkey2, setfkey3, setfkey4 Parameter: Command String Description: Creates command macros for the online function keys. These function keys are available for use when one is online with a modem. See online . Security: Operator Example: [0] A:\ # getfkey1 Function Key 1: “ATL5”...
  • Page 70 MR9600-100 User Guide Description: Disables controller generated polling to specified device. The example below starts with displaying the status of the back plane by using the bpstatus command. Security: Supervisor Example: [1] A:\ # bpstatus Backplane Status: -:no polling 0:count of 0...
  • Page 71 setpollingon Parameter: Device Description: Re-enables polling bewtween controller and specified device. The example below starts with displaying the status of the back plane by using the bpstatus command. Security: Supervisor Example: [4] A:\ # bpstatus Backplane Status: -:no polling 0:count of 0 Slot A --- 000 000 000 000 000 000 000 000 000...
  • Page 72 MR9600-100 User Guide setrasostype Parameter: Device Description: Lets the controller know what operating system is loaded on each segment. Security: Operator Limitations: CC9600 Only Example: [01] A:\ # setrasostype 1a Operating System:Ras Express 5.2 (or later) Operating System 1. Ras Express pre(5.2) 2.
  • Page 73 4 Commands setsubnet Parameter: IP Address Mask Description: Changes the subnet mask to the mask specified in the parameter. See se . Security: Supervisor Example: [0] A:\ # setsubnet 255.255.255.0 Subnet mask 255.255.255.0 stored [1] A:\ # settrap Parameter: IP Address Description: Changes the default trap IP address to the one specified in the parameter.
  • Page 74 MR9600-100 User Guide sync Parameter: None Description: Writes oustanding events (events that normally get written every hour) to the B:\#MMM\MR.log directory. The file will be named the current date and hour with an hour extension. Security: Operator Example: [01] A:\ # sync...
  • Page 75 t1debug Parameter: Device Description: Displays the status of AB Signalling bits for both the transmit and receive directions of each DSO channel for the specified T1 device within the CommPlete. TX = from CommPlete T1 card to central office. RX = from central office to CommPlete T1 card. Security: Supervisor Limitation: CC9600 only Example:...
  • Page 76 MR9600-100 User Guide t1setup Parameter: Device Description: Sets the T1 configuration information associated with a T1 device. This information is stored in a nonvolatile area of memory so that the device can be properly reconfigured on power-up or reset. The specified device must be a T1 device.
  • Page 77 Enter Selection (1,<2>,3,4, q, -): Acknowledgement Wink 1. Disabled 2. Enabled Enter Selection (<1>,2, q, -): T1 Card Status: LED Information: None FXS Signaling Options: E&M Immediate Start Dial-in Address: DNIS Acknowledgement Wink: Disabled Transmit Level: - 7.5dB Receive Level: - 0.0dB Firmware Version: N/A Save Changes? (<y>, n): n T1 Settings have not been changed...
  • Page 78 MR9600-100 User Guide t1status Parameter: Device Description: Interrogates the status of the specified T1 device. The specified device must a T1 device. T1 devices can exist only at 1b, 1c, 5b, 5c, 9b, 9c, 13b, and 13c. Security: Guest Example:...
  • Page 79 4 Commands update Parameter: Pathname Device Description: Updates the firmware of the controller, of a T1 device, or of up to eight modems. Pathname is the path of the file used to update the firmware. The file name extension determines which device is updated: .HXC updates the controller;...
  • Page 80 . Before uploading, binary files must be converted to ASCII data on the source computer using a utility supplied by Multi-Tech. The format for the data is one or more lines of hexadecimal data up to 80 characters in length, where each hexadecimal value is bracketed by square brackets (e.g., [2b][3c]...[1c]).

  • Page 81: User Id

    usage Parameter: Specifier Description: Displays how many modems fit the following parameters: received inbound calls, made outbound calls, were Out Of Service (OOS), were not respnding and were free per specified time intervals since the controller was last started (24 clock and specifier is in minutes). The example below shows the controller came up at 1:00 PM, has been running for 20 minutes and has taken 4 inbound calls.

  • Page 82: Ver, Version

    MR9600-100 User Guide ver, version Parameter: None Description: Displays the current version of the MR9600’s firmware. Security: Guest Example: [0] A:\ # ver Version 2.10 (Jan 09 1998 18:06:37) [1] A:\ # whoami Parameter: None Description: Displays the user ID of the user who is logged on, and the user’s security level.

  • Page 83: Error Messages

    Error Messages This section lists the MR9600-100’s error messages and their possible causes. Many error messages are caused by human error. When you receive an error message when executing a command, ask the following questions first: • Did you spell the command correctly? •...
  • Page 84 ERROR: Unknown error An error of unknown origin occurred while the MR9600-100 was attempting to parse a command line. ERROR: Bad or missing configuration file The specified configuration file is not present on the system. It is possible that the file name is incorrectly spelled.
  • Page 85 4 Commands CommPlete Communications Server...

  • Page 87: Solving Problems

    5 Solving Problems 82067502...

  • Page 88: Introduction

    MR9600-100’s hardware capabilities. 1. Refer to Figure 3 on page 12 to locate the test jumper on the MR9600-100 Controller card. Put the test jumper into the loopback position, so the two pins are shorted together. Reinstall the MR9600- 100 assembly into the CC9600 chassis.
  • Page 89 Test c Clears segment 1 modems OOS. Test d Resets segment 1 modems. CommPlete Communications Server 5 Solving Problems...
  • Page 90 MR9600-100 User Guide CommPlete Communications Server...

  • Page 91: Appendix A - Connector Pinouts

    Appendix A - Connector Pinouts This appendix describes the RJ-45 connector pinouts, and discusses categories of Ethernet cabling.. RJ-45 Connectors Figure A-1 RJ-45 Connector The above figure shows the arrangements of the pins, while Table A-1 lists the pinouts. Table BA-1: RJ-45 Connector Pinouts A schematic for crossover cables is shown in the following figure.

  • Page 92: Appendix B - Categories Of Ethernet Performance

    MR9600-100 User Guide Appendix B - Categories of Ethernet Performance The telecommunications industry has defined cable and cable component standards in terms of performance “categories”. The standards cover cable thickness, outer jacket material and thickness, etc. The categories specify the tests which the cable and components must pass to meet the standards. The two categories of test standards currently in use are Category 3 and Category 5.
  • Page 93 However, Cat 5 has some installation requirements that must be met: • Never use staples to mount or fix Cat 5 wiring. • Velcro is recommended in place of tie wraps. Wrap cable in bundles very loosely if you use tie wraps. •...
  • Page 94 MR9600-100 User Guide CommPlete Communications Server...

  • Page 95: Index
