- Page 1 ® CallFinder Cellular Gateway CF100FX2-G Quick Start Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes. Check Multi-Tech’s web site for current versions of our product documentation.
-
Page 3: Safety Warnings
Introduction The CallFinder Cellular Gateway connects to a PBX trunk line, PBX extension line, or to a single PSTN (POTS) line and routes incoming and outgoing calls through the wireless network. This Quick Start Guide will detail the physical connections needed for the CallFinder as well as a few basic setup examples and usage precautions. - Page 4 Maximum ambient temperature is 50 degrees Celsius. • This device should be installed by qualified personnel. • Only connect like circuits; e.g., connect SELV (Secondary Extra Low Voltage) circuits to SELV circuits and TN (Telecommunications Network) circuits to TN circuits. Multi-Tech Systems, Inc.
-
Page 5: Safety Warnings Telecom
• Do not connect the FXS port to an outside line (PSTN). • Connect this product only to an indoor antenna. • This product is not intended for use on a cable distribution system. Multi-Tech Systems, Inc. -
Page 6: Rf Interference Issues
• Operation of your Wireless CallFinder close to other electronic equipment may also cause interference if the equipment is inadequately protected. Observe any warning signs and manufacturers’ recommendations. Multi-Tech Systems, Inc. -
Page 7: Ship Kit Contents
OFF HOOK - This LED lights up when a telephony interface port (either FXO or FXS) is active. Signal SIGNAL STRENGTH - Three LEDs. If at least one LED is lit, there is enough signal to maintain the wireless connection. Multi-Tech Systems, Inc. - Page 8 The Voice/Data switch present on the CallFinder unit is for future expandability. For the GSM CallFinder, it should always be left in the “Voice” position. Power Supply Remove the protection frame and attach the provided blade piece to the power unit as shown. Multi-Tech Systems, Inc.
- Page 9 You will need to insert the SIM into your CallFinder. Setup for Wireless CallFinders Wireless CallFinder Applications. There are four common setups for the CF100FX2-G unit, as shown in the table below. CallFinder connects to... Situation 1 an analog...
-
Page 10: General Setup
4. Attach the antenna to the CallFinder. 5. Be sure that the “VOICE/DATA” switch is in the VOICE position. 6. Connect power to the CallFinder. 7. Connect the RJ-11 cable to the appropriate receptacle on the rear of the CallFinder. Multi-Tech Systems, Inc. - Page 11 8. If you intend to mount the CF100 on a flat surface, dimensions are provided in the drawing below. Multi-Tech Systems, Inc.
- Page 12 82100193L...
