INSTRUCTION MANUAL
CABLE REEL
CRL - 2000 SERIES
CRL - 3000 SERIES
・ ・ ・ ・ Read this manual before use.
・ ・ ・ ・ Keep this manual available.
ENDO KOGYO CO., LTD
Supply this manual to the user.
RM-10548b
Issued on Apr 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRL-2000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Endo CRL-2000 Series

Summary of Contents for Endo CRL-2000 Series

  • Page 1 Supply this manual to the user. INSTRUCTION MANUAL CABLE REEL CRL - 2000 SERIES CRL - 3000 SERIES ・ ・ ・ ・ Read this manual before use. ・ ・ ・ ・ Keep this manual available. ENDO KOGYO CO., LTD RM-10548b Issued on Apr 2015...
  • Page 2 Copyright and liabilities The copyright for this manual belongs to Endo Kogyo Co., Ltd. The manual is provided for the limited purpose of supporting the safe and proper use of the product. It cannot be used for other purposes. The customer may not use or make copies of this manual, in whole or in part, outside of this purpose without receiving prior consent from Endo Kogyo Co., Ltd.
  • Page 3 SAFETY ALERT SYMBOL AND ALERT SIGNS Please read this manual carefully and follow its instructions. The SAFETY ALERT SYMBOL ( ), WARNING, CAUTION, and NOTE carry special messages. This SAFETY ALERT SYMBOL is used to call your attention to items or operations that could be dangerous to you or other persons using this equipment.

  • Page 4: Table Of Contents

    Contents Safety instruction ———————————————————————————————————————————————————————— 2. Terminology definitions —————————————————————————————————————————————————————————————————————————————————————————— 3. Product description ———————————————————————————————————————————————————————————————————————————————————————————————— 3-1. Models and specifications 3-2. Names of main parts 4. Installation ———————————————————————————————————————————————————————————————————————————————————————————————————————————— 4-1. Checks before installation 4-2. Installation 4-3. Ground connection work 5. Cable connection ———————————————————————————————————————————————————————————————————————————————————————————————————— 5-1. Calculation of required cable length on winding side 5-2.
  • Page 5 Safety instructions Regarding name plates, warning labels and labels: ・Never remove or deface any name plates, warning labels or labels which are attached to the body. The operator should always observe them. Regarding installation (page 8): ・Never use in ignitable or explosive atmospheres. ・...
  • Page 6 Regarding initial tension setting (page 14): ・ ・ ・ ・ Never let go of the drum during any work. When released, the drum suddenly rotates, possibly causing personal injury. ・ ・ ・ ・ After setting the initial tension, wire connection requires more than 2 people to secure the drum and connect the cable.
  • Page 7 Regarding brush and slip ring replacement (page 20): ・ ・ ・ ・ Electric shock hazard. Turn off the power and verify safety using some kind of electrical test sensor before carrying out replacement. ・ ・ ・ ・ Allow the cable to fully wind onto the drum to give the minimum winding tension before carrying out replacement.

  • Page 8: Terminology Definitions

    2. Terminology definitions The terminology used in this manual will be explained here. If there is any terminology which is unclear or not included in this section, please contact our company. Winding methods: Figure 1 Ｍ ｏ ｖ ｉ ｎ ｇ ｒ ｅ ｅ ｌ Ｆ...

  • Page 9: Product Description

    3. Product Description 3-1. Models and specifications (1) Models Please observe the name plate attached to the main body. Refer to Figure 5 (page 7) for the attached location. Ｍ ｏ ｄ ｅ ｌ Ｓ ｌ ｉ ｐ ｒ ｉ ｎ ｇ ｃ ａ ｐ ａ ｃ ｉ ｔ ｙ Figure 4 MODEL: The product model is shown.
  • Page 10 (2) Specifications Table 1 Maximum Calculated Total Reference spring maximum number of Spring mass Model torque spring spring structure N・m tension turns { kgf・m } N { kgf } CRL-2205 CRL-2205-R { 0.5 } { 5.0 } CRL-2305 CRL-2305-R { 0.5 } { 5.0 } CRL-2A210 CRL-2A210-R...

  • Page 11: Names Of Main Parts

    3-2. Name s of main parts Ｄ ｒ ｕ ｍ Figure 5 Ｃ ｏ ｎ ｎ ｅ ｃ ｔ ｏ ｒ Ｄ ｒ ｕ ｍ ｃ ｏ ｖ ｅ ｒ Ｄ ｕ ｓ ｔ ｐ ｒ ｏ ｏ ｆ ｓ ｐ ａ ｃ ｅ ｒ Ｂ...

  • Page 12: Installation

    4. Installation 4-1. Checks before installation ・ Please check whether the items ordered were received. (Check the name plate.) ・ Check there is no damage to the product caused during transportation. 4-2. Installation Figure 6 ・ ・ ・ ・ Never use in ignitable or explosive atmospheres. ・...

  • Page 13: Ground Connection Work

    4-3. Ground connection work ・ ・ ・ ・ Electric shock hazard. Do the ground connection work. ・ ・ ・ ・ Never connect the earth line to the following: Gas pipes, etc. : Danger of ignition or an explosion. Phone lines / lightning rods : Danger of being struck by lightning. Along plastic water pipes : Does not act as an earth.

  • Page 14: Cable Connection

    5-2. Cable connection ・ ・ ・ ・ Electric shock hazard. Turn off the power before carrying out any work. ・ ・ ・ ・ Do not install cable to drum more than 2-3 times round. (2-3 times means winding length & initial spring turns) Make free space in drum, otherwise cable could spill out from drum cover.
  • Page 15 ■ Winding side cable (See figure 13) (1) Loosen the cross recessed head screws Figure 12 Ｓ ｌ ｅ ｅ ｖ ｅ and remove the dust proof cover and Ｗ ａ ｓ ｈ ｅ ｒ Ｃ ｏ ｎ ｎ ｅ ｃ ｔ ｏ ｒ ｎ ｕ ｔ dust proof spacer.
  • Page 16 Figure 14 Figure 15 Ｓ ａ ｄ ｄ ｌ ｅ Ｃ ａ ｂ ｌ ｅ Ｏ ｂ ｌ ｏ ｎ ｇ ｈ ｏ ｌ ｅ Ｃ ｏ ｎ ｎ ｅ ｃ ｔ ｏ ｒ Ｓ ｌ ｅ ｅ ｖ ｅ Ｗ...

  • Page 17: Spring Tension Adjustment

    6. Spring tension adjustment 6-1. Relationship between winding torque and drum turns Figure 17 Ｍ Ａ Ｘ Ｗ ｉ ｎ ｄ ｉ ｎ ｇ ｔ ｏ ｒ ｑ ｕ ｅ Ｍ Ａ Ｘ Ｎ ｕ ｍ ｂ ｅ ｒ Ｎ ｕ ｍ ｂ ｅ ｒ ｏ...

  • Page 18: Initial Tension Setting

    Example) Model CRL-2A205W, for the case of 20 drum turns According to table 1, total number of spring turns = 39. According to table 2, standard value of initial spring turns = 2 - 6, Number of spare spring turns = 3 or more. Upper limit of initial spring turns = 39 - (20 + 3) = 16.

  • Page 19: Adjustments

    7-2. Adjustments (1) Initial tension modification Increase the number of initial spring turns one by one without exceeding the upper limit. If there is no improvement, set the initial tension back to the first value. (2) X axis modification Tilt the X axis at a small angle by inserting a spacer under the bracket. Figure 18 Ｓ...

  • Page 20: Special Accessories

    9. Special accessories Ｓ ｔ ｏ ｐ ｐ ｅ ｒ Ａ ｒ ｍ ｔ ｙ ｐ ｅ ｇ ｕ ｉ ｄ ｅ ｒ ｏ ｌ ｌ ｅ ｒ Figure 20 Ｒ ａ ｃ ｈ ｅ ｔ ｄ ｅ ｖ ｉ ｓ ｅ Ｔ...

  • Page 21: Periodic Inspections

    (5) Ratchet device (Drawer dedicated manual) This is used when the winding operation stops and the cable is still paid out. To stop the drum, pull out the cable slightly then let it return. If the drum does not stop, pull out the cable a different length and try again. To release the drum, pull out the cable so as to rotate the drum by 1/2 turns.

  • Page 22: Slip Ring Inspections

    10-2. Slip ring inspections ・ ・ ・ ・ Electric shock hazard. Turn off the power before removing the dust proof cover. ・ ・ ・ ・ Verify safety using some kind of electrical test sensor before carrying out inspections. ・ ・ ・ ・ Take care as the slip ring assembly can still be very hot even if the power is cut. (1) Dust proof cover and dust proof spacer Figure 24 Ｃ...

  • Page 23: Troubleshooting

    (4) Slip rings ・ Are carbon powders adhering to the brush holders? Wipe off with a cloth or the like if adhering. ・ Are the slip ring surfaces rough or discolored? If there are any scratches or burns on the surface, polish with # 240 or finer sand paper. (5) Bolts and screws ・...

  • Page 24: Brush And Slip Ring Replacement

    12. Brush and slip ring replacement ・ ・ ・ ・ Electric shock hazard. Turn off the power and verify safety using some kind of electrical test sensor before carrying out replacement. ・ ・ ・ ・ Allow the cable to fully wind onto the drum to give the minimum winding tension before carrying out replacement.

  • Page 25: Brush Holder Replacement

    12-2. Brush holder replacement (See figures 27 (page 20) and 29) Ｂ ｒ ｕ ｓ ｈ ｈ ｏ ｌ ｄ ｅ ｒ Figure 29 Figure 30 Ｐ ｌ ａ ｔ ｅ Ｈ ｅ ｘ ａ ｇ ｏ ｎ ｎ ｕ ｔ Ｆ...

  • Page 26: Slip Ring Replacement

    12-3. Slip ring replacement (See figure 29 (page 21)) (1) Remove the terminal plate, plate and brush holders in the same manner as section 12-2. " Brush holder replacement". Figure 32 NOTE: When replacing the slip rings alone, the slip rings can be removed without removing the brush holders.

  • Page 27: Disassembly Of Slip Ring Assembly And Bracket

    13-1. Disassembly of slip ring assembly and bracket (Common method for all spring structures) (1) Turn off the power and allow the cable to fully wind onto the drum to give minimum winding tension, then dismantle the mating equipment side wiring. Allow the dismantled cable to wind around the drum, slowly turning the drum until the winding tension in the drum is released.
  • Page 28 ■ For spring structure A (1 spring) Figure 34 Ｂ ｕ ｓ ｈ （ Ｗ ｉ ｔ ｈ ｎ ｏ ｎ － ｃ ｉ ｒ ｃ ｕ ｌ ａ ｒ ｈ ｏ ｌ ｅ ） (1) Weld steel plates to the spring Ｗ...
  • Page 29 (6) Install the spring into the drum. 1) Before installation, check the assembling direction which depends on the winding direction of the reel. See figure 37. 2) Slightly move the band upward in order to make the removal Figur e 36 easy.
  • Page 30 ■ For spring structure B (1 spring and an empty spring case) Figure 39 (1) Remove the bush and the empty spring case Ｂ ｕ ｓ ｈ （ Ｗ ｉ ｔ ｈ ｎ ｏ ｎ － ｃ ｉ ｒ ｃ ｕ ｌ ａ ｒ ｈ ｏ ｌ ｅ ） from the drum.
  • Page 31 3) Place the spring into the drum. Fit the center edge of the spring into the slit of the bush by hammering. Put a steel plate or the like to protect the spring when hammering. 4) Place the outer edge of the spring on the spring fixing portion of the drum. See figure 37 (page 25).
  • Page 32 (5) Before reassembly, clean and inspect all the disassembled parts. Replace worn, cracked, damaged or deformed parts. (6) Lightly lubricate the bush attaching portion of the spindle and the inside surface of the bush with grease (IDEMITHU, DAPHNE EPONEX GREASE EP-1 or equivalents). Attach the bush with the circular hole to the spindle.
  • Page 33 (9) Stand the drum with the spindle being horizontal. Secure the drum by some means not to allow falling or moving. (10) Place the notch key and notch springs into the slot of the spindle. Take care as the assembling direction of the notch key depends on the winding direction of the reel.
  • Page 34 ■ For spring structure D (2 springs, double-torque) Figure 43 (1) Weld steel plates to the spring in Ｂ ｕ ｓ ｈ Ｗ ｅ ｌ ｄ ｂ ｏ ｔ ｈ order to prevent the spring from （ Ｗ ｉ ｔ ｈ ｎ ｏ ｎ － ｃ ｉ ｒ ｃ ｕ ｌ ａ ｒ ｈ ｏ ｌ ｅ ） ｓ...

  • Page 35: Common Reassembly Method

    4) Place the outer edge of the spring on the spring fixing portion of the drum. See figure 37 (page 25). 5) Insert a screw driver into the space between the band and the spring as shown in figure 38 (page 25), then remove the band. Take care not to catch your finger in the spring since the spring will expand explosively when the band is removed.

  • Page 36: Spring Disposal1

    13-4. Spring disposal The spring is dangerous due to remaining tension even if it is broken. Weld steel plates to the spring even if the spring is in the spring case in order to prevent the spring from expansion before disposal. Never use gas welding, only use arc welding.
  • Page 37 ■ＣＲＬ－２２０５・２３０５・２Ａ２０５Ｗ・２Ａ３０５Ｗ　MAIN BODY ■ＣＲＬ－２２０５・２３０５・２Ａ２０５Ｗ・２Ａ３０５Ｗ　MAIN BODY ■ＣＲＬ－２２０５・２３０５・２Ａ２０５Ｗ・２Ａ３０５Ｗ　MAIN BODY ■ＣＲＬ－２２０５・２３０５・２Ａ２０５Ｗ・２Ａ３０５Ｗ　MAIN BODY Ｓｅｅ ｓ ａｄｌｅ Ｓ ｅｅ ｃ ｏｎｎｅｃ ｔｏｒ ■ＣＲＬ－２Ａ２１０　MAIN BODY ■ＣＲＬ－２Ａ２１０　MAIN BODY ■ＣＲＬ－２Ａ２１０　MAIN BODY ■ＣＲＬ－２Ａ２１０　MAIN BODY Ｓ ｅｅ ｓａ ｄｄ ｌｅ Ｓｅ ｅ ｃ ｏｎ ｎｅ ｃｔｏ ｒ - 33 -...
  • Page 38 Quantity List No. or Description part No. ２２０５ ２３０５ ２Ａ２１０ ２Ａ２０５Ｗ ２Ａ３０５Ｗ １ Bracket １ － １ １ － ＬＲＰ００１１３７ １ Bracket － １ － － １ ＬＲＰ００１１３９ － Spindle assembly １ １ － － － ＬＲＰ００３７９４ － Spindle assembly －...
  • Page 39 ■ＣＲＬ－２２０５－１～２Ａ３０５Ｗ－１　MAIN BODY ■ＣＲＬ－２２０５－１～２Ａ３０５Ｗ－１　MAIN BODY ■ＣＲＬ－２２０５－１～２Ａ３０５Ｗ－１　MAIN BODY ■ＣＲＬ－２２０５－１～２Ａ３０５Ｗ－１　MAIN BODY (In case of reverse seating, replace corresponding parts with these parts) Quantity List No. or Description part No. ２２０５ ２３０５ ２Ａ２１０ ２Ａ２０５Ｗ ２Ａ３０５Ｗ １ Bracket １ － １ １ － ＬＲＰ００１１３７ １ Bracket －...
  • Page 40 ■ＣＲＬ－３３１６～３Ａ４０９Ｗ　MAIN BODY ■ＣＲＬ－３３１６～３Ａ４０９Ｗ　MAIN BODY ■ＣＲＬ－３３１６～３Ａ４０９Ｗ　MAIN BODY ■ＣＲＬ－３３１６～３Ａ４０９Ｗ　MAIN BODY Ｓ ｅ ｅ ｓ ａ ｄ ｄ ｌ ｅ Ｓ ｅ ｅ ｃ ｏ ｎ ｎ ｅ ｃ ｔ ｏ ｒ - 36 -...
  • Page 41 Quantity List No. or Description part No. ３３１６ ３Ａ３１６Ｗ ３Ａ３０９Ｗ ３４１６ ３４０９ ３Ａ４１６Ｗ ３Ａ４０９Ｗ １ Bracket １ １ － － － － － ＬＲＰ００１１４５ １ Bracket － － １ － － － － ＬＲＰ００１１３９ １ Bracket － － － １ －...
  • Page 42 Quantity List No. or Description part No. ３３１６ ３Ａ３１６Ｗ ３Ａ３０９Ｗ ３４１６ ３４０９ ３Ａ４１６Ｗ ３Ａ４０９Ｗ １３ Metal １ １ １ １ １ １ １ Ｐ１Ｒ４１１５９２ １４ Washer １ １ １ １ １ １ １ Ｐ１Ｒ４００１５０ １８ Masine screw １２ １２ １２ １２...
  • Page 43 ■３０Ａ Slip ring ■３０Ａ Slip ring ■３０Ａ Slip ring ■３０Ａ Slip ring Ｓ ｅｅ ｃ ｏ ｎ ｎ ｃ ｔ ｏ ｒ Ｓ ｅｅ ｓ ａ ｄ ｄ ｌ ｅ Quantity List No. or Description Part No. ３Ｐ ４Ｐ ６Ｐ ８Ｐ...
  • Page 44 Quantity List No. or Description Part No. ３Ｐ ４Ｐ ６Ｐ ８Ｐ １０Ｐ １２Ｐ １４Ｐ １６Ｐ ２０ ＬＲＰ００３３１２ - Ring bolt － ４ － － － － － － ２０ ＬＲＰ００３３１４ - Ring bolt － － ４ － － － － －...
  • Page 45 Quantity List No. or Description Part No. ３Ｐ ４Ｐ ６Ｐ ８Ｐ １０Ｐ １２Ｐ １４Ｐ １６Ｐ ３７ Ｐ２Ｈ４００１７７ Hex. cap screw ６ ６ ６ ６ ６ ６ ６ ６ ３８ ＫＡ１０５３０５１６ Cross recessed head screw ６ ６ － － － － －...
