Note: We highly recommend reading the manual in full before testing and installing your business security
system. Test all connections are working before permanently installing DVR and cameras. Position
the DVR in a central location where all 8 cameras will reach. If you are wanting to use your DVR via
mobile and/or PC, install near your router and refer to the user manual for further instructions on
installation and operation.
1.
Connect each of the camera extension cables to the video and power connectors.
2.
Connect the other end of the extension cables to the ports marked "VIDEO IN" on the back of the
DVR.
3.
Connect the 8-way power splitter to each of the extension cable power plugs.
8CH 1080P SECURITY
CAMERA SYSTEM
Quick Start Guide
HE210303 02/2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cocoon HE210303
Summary of Contents for Cocoon HE210303
- Page 1 8CH 1080P SECURITY CAMERA SYSTEM Quick Start Guide HE210303 02/2022 Note: We highly recommend reading the manual in full before testing and installing your business security system. Test all connections are working before permanently installing DVR and cameras. Position the DVR in a central location where all 8 cameras will reach. If you are wanting to use your DVR via mobile and/or PC, install near your router and refer to the user manual for further instructions on installation and operation.
- Page 2 8CH 1080P SECURITY CAMERA SYSTEM Quick Start Guide HE210303 02/2022 Connect the included HDMI cable to the back of the DVR and connect the other end of the HDMI cable to your monitor or TV (not a computer or laptop).
