- Page 1 FM TRANSMITTER TXF Series 2000-5000W OPERATION MANUAL Revision 2.5...
-
Page 2: Table Of Contents
Contents INTRODUCTION ........................1 GENERAL SAFEGUARDS ......................2 2.1..........................2 AFETY AND IRST 2.2..........................3 PERATING AFEGUARDS TERMS OF SALE ........................4 WARRANTY ..........................7 PRINCIPLE OF OPERATION ....................8 INSTALLATION ......................... 9 6.1........................9 NPACKING AND NSPECTION 6.2..........................10 ANEL ONNECTIONS 6.3. - Page 3 MAINTENANCE ........................45 TROUBLESHOOTING ......................46 No part of this manual may be re-produced in any form without prior written permission from Technalogix Ltd. The information and specifications contained in this document is subject to change at any time without notice.
-
Page 4: Introduction
1. Introduction Please take a few minutes to read the manual and familiarize yourself with your new Technalogix FM power amplifier or transmitter. This user manual, the Final Inspection Report, and of course our equipment, should be everything you need to get on the air with a superb audio signal. We understand that a capable and confident user will get the most out of our product and we have made every attempt to educate readers of all technical levels. -
Page 5: General Safeguards
2. General Safeguards This section is written as a general guide for safe operation of the equipment and is intended for those having previous knowledge and experience with these kinds of equipment. It is not intended to contain a complete statement of all safety precautions, which should be observed by personnel using this or other electronic equipment. -
Page 6: Operating Safeguards
Operating Safeguards Load Impedance Technalogix FM equipment functions with a 50-ohm load impedances. It is imperative you maintain 50- ohm impedances throughout your system for your equipment to provide maximum power transfer to the antenna and decreased reflected power heading back towards the amplifier pallets. Failure to provide a 50-ohm path throughout the system may result in damage to your equipment. -
Page 7: Terms Of Sale
3. Terms of Sale Sales by Technalogix Ltd. (“Seller”) are made only on terms which are contained in this policy. Seller hereby gives notice of its objection to any different/additional terms and conditions. All sales are expressly conditional upon Buyers’ assent to the terms and conditions set forth below. These terms and conditions may be modified/ supplemented only by written document signed by authorized representative of the Seller. - Page 8 Changes and Cancellation Purchase orders that have been accepted by Seller may not be changed/ cancelled, in whole or part, without written Seller consent. All changes must be included in change order reflecting purchase order and submitted to the Seller. All other changes will not be accepted/acknowledged. Changes may affect delivery dates.
- Page 9 Installation Seller assumes no obligation to install any product sold to place any products in working order at Buyer’s premises and not responsible for freight damage. Validity of Separate Clauses If any provisions of this agreement shall be held invalid, illegal, or unenforceable, the validity, legality or enforceability of the remaining provisions shall not be affected or impaired thereby.
-
Page 10: Warranty
4. Warranty Technalogix products have been completely tested and found to meet specifications and be in proper operating condition. Technalogix-manufactured products are warranted to be free from defects in materials and workmanship for a period of two years from the date of shipment. Products sold through, but not directly manufactured by Technalogix, carry the original manufacturer’s warranty. -
Page 11: Principle Of Operation
Power Amplifiers (IPAs) and/or final stage pallets. If multiple final pallets are required, then a splitter and combiner are also required before and after the final stages. Technalogix manufactures FM amplifiers and transmission systems suitable for 87.5 to 108.0 MHz. Custom frequencies are available upon request if you require carriers outside this range, including audio for VHF applications and other unique requirements. -
Page 12: Installation
If the equipment is damaged, a claim should be filed with the carrier once the extent of the damage is assessed. Technalogix cannot stress too strongly the importance of immediate careful inspection of the equipment and subsequent immediate filing of the necessary claims against the carrier if necessary. If possible, inspect the equipment in the presence of the delivery person. -
Page 13: Panel Connections
6.2. Panel Connections AC IN: Single phase AC input to feed internal AC/DC switching power supplies. Check with factory as not all power supplies are universal 110/220V. RF OUT: FM modulated RF carrier output (N female or 7-16 DIN female) RBDS/RDS Configuration and control of RBDS/RDS encoder in transmitter accomplished (USB):... -
Page 14: Initial Hook Up
6.3. Initial Hook Up 1. Ensure that the antenna has been swept and, ideally, has a return loss of greater than 20dB (VSWR = 1.2:1). This should be done before connecting the antenna cable to the system’s output. The power amplifier’s control system allows the user to change the VSWR trip point up to a maximum level of 1.8:1, unless a custom VSWR protection system has been requested. -
Page 15: Operating Procedure
7. Operating Procedure Assuming the previous installation instructions have been completed and cautions noted, and the power amplifier is ready to receive a properly modulated RF signal, proceed with the following steps to place the system in operation. The power amplifier has been factory aligned for a specific frequency (per system specification), signal levels and optimum performance. - Page 16 At this time, Technalogix recommends that you document your measurements to use as a reference over time. The measurements can be made either from the front display, or remotely via the Remote Port (DB25), Ethernet (lower RJ45), or SNMP (lower RJ45), whose operation is explained in the Monitor and Control System sections.
-
Page 17: Control Interface
In the event of a fault condition the unit will try to fold back to a safe level, sound an audible alarm and display the event on the screen. This message will replace the Technalogix logo. Possible messages are OVERDRIVE, HIGH VSWR and HIGH TEMP... -
Page 18: Rf Info Screen
8.2. RF Info Screen The RF Info Screen summarizes key parameters for the RF carrier of the FM signal, as illustrated in the sample screen below: DEVIATION The maximum frequency deviation from the carrier centre frequency is illustrated on this level bar. Typical maximum deviation, required by Industry Canada or FCC, is 75 kHz to avoid bleeding into adjacent channels. -
Page 19: Fm Info Screen
8.3. FM Info Screen The FM Info Screen summarizes key parameters for the audio that resides on the RF carrier of the FM signal, as illustrated in the sample screen below: DEVIATION: The maximum frequency deviation from the carrier centre frequency is illustrated on this level bar. -
Page 20: Currents Screen
8.4. Currents Screen This screen allows the user to view voltage and current readings. A sample Power Supplies Screen is displayed below: Currents shown are total current or spIit current and the cooling fan current. Split current can be for multiple amplifier pallets or multiple devices on one pallet. -
Page 21: Version Screen
8.5. Version Screen Model: Shows the model number of the unit Serial: Shows the units unique serial number Shows the IP address that can be used to connect to the unit via Ethernet or SNMP once it connects to your network or computer PCB: Shows the version for the exciter PCB and firmware Controls from Version Screen... -
Page 22: Contact Screen
8.6. Contact Screen The Contact Screen provides information for the user to get in touch with Technalogix for anything - whether that’s a technical or installation question or product improvement ideas, Technalogix welcomes questions, feedback, and contact. If you are in the area, please feel free to stop by to tour the facility, test drive some state of the art products, or get a refresher on some training. -
Page 23: Fm Settings
8.7. FM Settings Frequency: With the exciter being agile, the user can change frequency from 87.5MHz to 108.0 MHz in 0.1Mhz increments. The step size is 100 kHz. At the lower and upper frequency limits of the FM band, the frequency will wrap back around. -
Page 24: Audio Levels
8.8. Audio Levels Attenuation can be added to the Audio inputs on this screen. Only the audio inputs currently active are shown and can be changed. Right and left level apply to all the digital inputs as well as analog. Controls from Audio Levels Screen ... -
Page 25: Units
8.10. Units Temperature: Can set the displayed temperature to Celsius or Faherenheit. Power: Can set the displayed power to Watts or percent of full scale. Controls from Units Screen Goes to SCA Levels screen Goes to Date & Time screen Next/Enter: Enters selection mode to change options above Back:... -
Page 26: Event History
8.12. Event History Displays various events and errors and the date and time they occurred. Can scoll down to see the last 32 events. Controls from Event History Screen Goes to Date & Time screen Goes to Event Reset screen Next/Enter: Enters scroll mode Back:... -
Page 27: Web Interface
9. Web Interface The following pages outline the steps required to access the Technalogix Adrenaline Web Interface. Descriptions specific to the user’s computer, router, or network setup are limited due to the differences in the multitude of networking equipment. 1. Connect Power Amplifier/Transmitter to your Network/PC Connect an Ethernet cable from the RJ45 port (labelled ETHERNET) on the back panel of the power amplifier or transmitter to your network’s Ethernet connection. - Page 28 2.2. Main Page Description After entering the login information, the main page is then shown on the browser, as illustrated below for either single amplifier systems or multiple amplifier systems that are combined: The model number and serial number of the unit are displayed in the top left of the browser screen.
- Page 29 • Pre-Emphasis, selectable between 0, 25, 50, or 75 us The Control section of the web interface screen allows the user to control functions inside the equipment, including: • Turn Carrier On/Off - Turn the Carrier on/off • AGC - Increase the Carrier by removing attenuation (steps of 1 or 10 dB) VSWR ↑↓...
- Page 30 3.1. Network Configuration The Network Configuration page allows the administrator to optimize the network settings to best suit their application. 3.1.1. Host Name The Host Name shows the current webpage name (default is ADRENALINE). Enter a new name here if you wish to change this. For example, entering YourCompany will make the web address: http://yourcompany/index.htm...
- Page 31 3.1.2. HTTP Port The HTTP Port shows the current port used for internet access, 80 or 81. Port 80 is the default and is the accepted standard. Port 81 is available because some internet providers block access to port 80 unless you pay more. Be very careful changing HTTP ports as it can be difficult to go back to an original port.
- Page 32 3.2. SNMP Configuration 3.2.1. SNMP Communities The SNMP Configuration page allows you to set the SNMP communities. Set these to limit access to the system via SNMP. Default communities are: READ: Public Read WRITE: Private Write Public...
- Page 33 3.2.2. SNMP Management Information Base (MIB) The Technalogix.mib file allows access to the following data via the SNMP protocol: Read Only Pallet Supply Voltage - voltage level (Vdc) Temperature - temperature in (°C) Total Current - current on high voltage bus (Adc)
- Page 34 3.2.3. SNMP Traps To enable the SNMP traps, within the MIB browser that you choose: Set enable traps to 1 (or yes, depending on MIB browser). Set the IP address to that of the receiving computer. Set the community to one of the read communities set above.
- Page 35 Make sure that your receiver’s port is set to 162 The system will generate a general trap on any error flag and send an 8-bit value indicating the type of error, as follows: Bit 0(LSB) Overdrive Bit 1 High VSWR Bit 2 High Temperature Bit 3...
- Page 36 3.3. Password Configuration This page allows the setting of the web browser’s User or Admin password, as illustrated below. The User account allows access only to the main page. The Admin account allows access to the main and all the configuration pages. Passwords are to be a maximum of 7 characters long.
-
Page 37: Remote Control (Via Db25)
9.1. Remote Control (via DB25) An additional option for remote control of the power amplifier/transmitter is through the DB25 connector found on the back panel of the power amplifier/transmitter The overall functions of each pin on the Remote Port are indicated in the following DB25 pinout: Pin Number Description Ground... -
Page 38: Rbds And Rds
Radio Broadcast Data System (RBDS) is commonly used for FM broadcast in North America, while the Radio Data System (RDS) is implemented in Europe. In 1998, the two standards were largely unified. Both systems are implemented as standard features on Technalogix FM transmitters, including the control, generator, and interface. -
Page 39: Monitor And Control System
Monitor and Control System 10.1. Control System Overview The control system is used for a variety of functions, the most important of which is ensuring that the amplifier or transmitter continues to operate in a safe manner. The control system also allows the user to monitor and control the amplifier or transmitter from both the front panel and remotely through the parallel port, Ethernet, or SNMP access port. -
Page 40: Fm Interface Board Block Diagram
10.2. FM Interface Board Block Diagram RF Amplifier VCO Out RF Matching RF Matching Predriver 23dB Power Coupler +12V Regulation Power Pre-driver Pre-driver Pre-driver power filter power On Board Micro Micro Temp Sensor Off Board Temp Sensor Connection Forward Micro Power Coupler Detection... -
Page 41: Hardware Components
The exact bias and drain current of your system are found in the Final Inspection Report supplied in the shipping package. Output power levels are absolute maximum levels. Technalogix operates the pallet at reduced levels to improve performance and increase reliability. -
Page 42: Splitter
11.3. Splitter The splitter is used to provide the drive signal to the two 1200W pallets. Frequency Range 10 - 250 MHz Input Power (max) 25 W Isolation Up to 25dB Insertion Loss above 3dB (max) 0.5 dB Insertion Loss above 3dB (typ) 0.25 dB Phase unbalance (max) 2 degrees... -
Page 45: Facility Recommendations
You are apt to get better overall support if you cultivate business relationships with local suppliers Technalogix recommends that proper AC line conditioning and surge suppression be provided on the primary AC input to the power amplifier or transmitter. If DC is used as a source, a DC-DC converter is recommended to provide isolation between the supply and the load. -
Page 46: Shelter Security
The selection, routing, and length of coaxial cable are extremely important in the installation. If there is a 3 dB line loss in the cable between your unit’s output and the transmitting antenna, the unit will only deliver half power. Buy the best cable you can obtain, route it via the shortest way to the antenna, and keep it straight. -
Page 47: Heating And Cooling Requirements
The environment’s temperature will contribute greatly to the length of the power amplifier’s or transmitter’s life. Technalogix recommends that the building’s filtered air intake must have capacity for all air-flow in the building plus an additional 20%. Keep the intake below the roofline to avoid intake of solar heated air. -
Page 48: Maintenance
Maintenance If your unit employs a filter on the air inlet for the fans, the filter should be cleaned every 30 days. If the equipment is operated in a severe dust environment, the filters on the inlet fan may need to be cleaned more regularly. -
Page 49: Troubleshooting
Troubleshooting The first and most important aspect of troubleshooting anything is to be systematic. Note where you have looked and what you found. Look first for the obvious. • Make a physical inspection of the entire facility. Are all necessary connections properly made? Do you see any signs of obvious damage within the equipment? Is the AC power ‘ON’... - Page 50 Thank you for choosing Technalogix Ltd. If there is anything we can do to help in your success, please do not hesitate to contact us. We also welcome suggestions for product improvements or feature enhancements.
