Summary of Contents for Wasp B2000
- Page 1 B2000 Installation Guide...
- Page 2 Wasp Barcode Technologies reserves the right to make changes to any software or product to improve reliability, function, or design. Wasp Barcode Technologies does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
-
Page 3: Table Of Contents
B2000 Installation Guide Table of Contents Installation Notice........................ 1 Chapter 1: Device Overview....................2 1.1 System Configuration ....................2 1.2 Device Interface ....................... 3 Chapter 2 – Device Installation and Wiring ................ 6 2.1 Wall Mounting ......................6 2.2 Communication Connection ..................6 2.4 Power Connection .................... -
Page 5: Installation Notice
Any damage caused by using a different power source is not covered under warranty. 9. Improper wiring may cause the B2000’s main circuit board and fingerprint sensor to burn out. Resulting damage from improper wiring is not covered under manufacturer’s warranty. -
Page 6: Chapter 1: Device Overview
B2000 Installation Guide Chapter 1: Device Overview 1.1 System Configuration This device supports RS232 and TCP/IP connections to the PC. -
Page 7: Device Interface
B2000 Installation Guide 1.2 Device Interface Front View: Speaker Screen Fingerprint Scanner Keyboard Power Button • Led Indicator: Status Indicator Blinking Green Normal State Solid Green (three seconds) Verification Successful Solid Red (three seconds) Verification Failed • Speaker: Plays the beep sound and voice prompts. - Page 8 B2000 Installation Guide Back View: • Power Supply: Use to connect to the power supply. • Ethernet Port: Connect the device to the Internet or connect directly to the PC. • Wiring Terminals: Use to connect with RS232 communication (or connect with the printer).
- Page 9 B2000 Installation Guide Side View: Reset Button USB Port • USB Port – You can use the U disk to download or upload user information and verification records. • Reset Function – If the device is not working properly, you can use the Reset function to restart it. To reset,...
-
Page 10: Chapter 2 - Device Installation And Wiring
Chapter 2 – Device Installation and Wiring 2.1 Wall Mounting 1. Separate the mounting plate from the B2000 by removing the screw at the bottom edge of the clock. A special screwdriver is supplied. 2. Determine the position of the mounting plate on the wall. The B2000 should be mounted on the external wall of the door approximately 4 to 5 feet from the ground. -
Page 11: Power Connection
5. After the test is complete, press ESC to return to the Main Menu. Highlight User Mng and press the M key. 6. Enroll a new user and card (see the B2000 User Manual for details). Test the device by swiping the card. -
Page 12: Chapter 3 - Date/Time
B2000 Installation Guide Chapter 3 - Date/Time This screen allows you to manually set the date and time. 1. On the Main menu, highlight the Date/Time icon and press the M key. The DateTime screen appears: 2. Use the up and down arrow keys to put your cursor in the desired field. - Page 13 B2000 Installation Guide a. Date Mode – Use the left and right arrow keys to select how you want the date to display. Options are MM-DD hh:mm or MM-WS-WK hh:mm. b. Enter Start and End times. The allowed range for number of weeks (WS) is 1-6. The allowed range for day of the wk (WK) is 0-6.
-
Page 14: Appendix I - Troubleshooting
B2000 Installation Guide Appendix I – Troubleshooting Trouble Cause & Measure Cause: Power LED is off No power or lack of voltage. Solution : Check and examine the connection of power supply. Measure the supply voltage, ensure that it is 12VDC. -
Page 15: Appendix Ii - Wifi Function
B2000 Installation Guide Appendix II – WiFi Function This device has included WiFi functionality. WiFi modules can be built-in to the device. WiFi is a type of WLAN (wireless local area network) that uses the 802.11b specification. The biggest advantage of WiFi is the high speed of wireless transmission, which is up to 11 Mbps. -
Page 16: Appendix Iii - Environmental-Friendly Use Description
B2000 Installation Guide Appendix III – Environmental-Friendly Use Description The Environment Friendly Use Period (EFUP) marked on this product refers to the safety period of time in which the product is used under the conditions specified in the product instructions without leakage of noxious and harmful substances.
