Summary of Contents for Parker IQAN-G2
- Page 1 IQAN-G2 Instruction book Publ no HY33-8407-IB/UK Edition 2014-05-19...
-
Page 2: Table Of Contents
Mounting the IQAN-G2 ........ - Page 3 Appendix A ........... 19 IQAN-G2 Technical Overview ........19 Absolute Maximum Ratings .
-
Page 4: Introduction
Part 15 of the FCC-rules (Class B digital devices) Contact the manufacturer if there is anything you are not sure about or if you have any questions regarding the product and its handling or maintenance. The term "manufacturer" refers to Parker Hannifin Corporation. Instruction book, IQAN- G2... -
Page 5: Precautions
If in doubt about potential danger, contact the physician or the manufacturer of the device to verify that the equipment is properly shielded. Pacemaker patients are advised to keep the IQAN-G2 and its antennas away from the pacemaker while it is on. Air traffic Switch off the IQAN-G2 before boarding an aircraft. -
Page 6: Electronic Equipment
Therefore, you should never rely solely upon any wireless device for essential communications. Remember, in order to transmit or receive any type of data, the IQAN-G2 must be switched on and in a service area with adequate cellular signal strength. - Page 7 The IQAN-G2 functionality requires the following: • a SIM card from your preferred Network operator. • A subscription to a server solution that is offered by a Parker supplier. Contact your local Parker Sales office for additional information. Instruction book, IQAN- G2...
-
Page 8: Quick Start Guide
(required for G2 modem, also allows CAN bus-to-PC diagnostics). Add IQAN-G2 modem in IQANdesign. 2. Configure the modem. • Connect your PC CAN card directly to the IQAN-G2 CAN bus (diagnostic bus). IQAN-G2 CAN-L 120 ohm... - Page 9 If this happens a PUK (PIN Unlock Key) code is required to unlock the SIM card. 3. Create Proemion Account (first time only) Before activating your first modem you need to create a Proemion account at https://parker.proemion.com. Create a new account (one time) with user name and password. Instruction book, IQAN- G2...
- Page 10 Proemion account. You also need to have the IMEI and Serial number on the modem available to complete the registration. IMEI number and serial number on the IQAN-G2 unit. • Login to https://parker.proemion.com using your Proemion username/password. • Select Service > Activation form to activate your modem.
-
Page 11: Product Description
Product description Product description General The IQAN-G2 is a modem unit that works with the MDL2, MD3, and MC2 master modules in IQANdesign (2.60 or later) platform control systems. The IQAN-G2 is designed to transmit remote diagnostic data information about devices that are connected to a CAN network using GSM telecommunication services and IQAN PC software tools. -
Page 12: Communication
For more information about the status and error messages, see Appendix B, on page 21. SIM Card The SIM card is required (it is not included in the IQAN-G2) to establish a link to your GSM network provider. In order to use GPRS internationally, use a SIM card that has this type of service enabled. - Page 13 Do not shorten or lengthen the cable of the antenna. OTICE Do not operate the unit GSM without antenna! To avoid damage to the IQAN-G2, connect/disconnect the GSM antenna only if the power supply to the device is switched off. Instruction book, IQAN- G2...
-
Page 14: Mounting
Mounting Mounting Mounting the IQAN-G2 The IQAN-G2 does not have to be mounted in any specific orientation. 2 fastening methods, of end mounting with 2 bolts, or flat mounting with 4 screws is acceptable. OTICE The IQAN-G2 module should be mounted according to the following instructions: •... -
Page 15: Installation
Use ESD precautions and equipment when opening the enclosure to install the GSM SIM card. In the IQAN-G2, the card holder is placed inside the housing. The housing has to be opened to access it. The card holder is mounted to the PCB. -
Page 16: Opening The Enclosure
Installing the SIM card Installation Opening the enclosure To open the IQAN-G2 enclosure, remove the 4 screws holding the enclosure halves together (2 on label surface, 2 on the opposite side). Carefully pull the enclosure apart. remove Opening the enclosure. -
Page 17: Supply Voltage
Do not use the chassis as the negative terminal. Polarity reversal The IQAN-G2 module is protected against power supply polarity reversal, provided an external fuse, max 1 A (Fast) is being used. If this fuse is not used, polarity reversal can damage the unit. -
Page 18: Communication
Installation Communication CAN connection The IQAN-G2 has a CAN interface in connector C1 to communicate with IQAN master modules to provide them with remote diagnostic capabilities. The signals on the CAN connection terminals CAN-Low and CAN-High must match the signals on the CAN terminals of the connected devices. -
Page 19: Activate The Modem
After registration, you will be able to log in to the web portal. Activate the modem To be able to operate the IQAN-G2, you will need to activate the modem on the web portal. To register (activate ) the modem, use the activation form. -
Page 20: Web Portal Support
Web portal for activation and modem management Installation Web portal support For support and additional answers to questions about the web portal, please contact: PROEMION GMBH Donaustr. 14 36043 Fulda, Germany Contact Germany Phone: +49 661 9490-600 Fax: +49 661 9490-666 E-mail: info@proemion.com PROEMION CORP. -
Page 21: Start-Up
Start-up procedures Start-up Start-up Start-up procedures This chapter contains instructions for action to be taken in connection with the initial start. ARNING Risk of injury! If the control system is not fitted properly, the machine could move uncontrollably. The machine’s engine shall not be started before the control system is completely fitted and its signals are verified. -
Page 22: Iqan-G2 Technical Overview
IQAN-G2 Technical Overview Appendix A Appendix A IQAN-G2 Technical Overview Absolute Maximum Ratings Limit values Parameter Unit Remark min. typ. max. Ambient temperature, T – 30 °C Storage temperature, T – 40 °C Voltage supply on +BAT Reverse polarity protected with 1A fuse. -
Page 23: Recommended Operating Conditions
Once the normal operating conditions are exceed- ed, the performance of the device may suffer. Also, the operating temperature for the manufactures´s SIM card may differ from the IQAN-G2 rat- ings. Consult the service provider to determine the temperature rating for the SIM card. -
Page 24: Led Messages And Actions
If an error is detected, a message will be presented on the LEDs. ARNING An error message could indicate that a hazardous situation exists. If precautions are not taken, this could result in death, serious injury or major property damage. LED indicators showing different IQAN-G2 modes LED /color Condition Description... -
Page 25: Dimensioning Of The Iqan-G2 Module
Dimensioning of the IQAN-G2 module Appendix C Appendix C Dimensioning of the IQAN-G2 module Unit = mm Instruction book, IQAN-G2... - Page 26 For latest information visit our website www.iqan.com Information in this instructionbook is subject to change without notice Publ no HY33-8407-IB/UK Edition 2014-05-19 Parker Hannifin Parker Hannifin Electronic Controls Division Electronic Controls Division SE-435 35 Mölnlycke 1651 N. Main Street Sweden...
