  • Page 1 IQAN-G3 Instruction book Publ no HY33-8415-IB/UK Edition 2016-04-22...
  • Page 2: Table Of Contents

    Mounting the IQAN-G3 ........
  • Page 3 Appendix A ........... 22 IQAN-G3 Technical Overview ........22 Absolute Maximum Ratings .
  • Page 4: Introduction

    Safety symbols Introduction Introduction These instructions are to be used as a reference tool for the vehicle manufacturer’s design, production, and service personnel. The user of these instructions should have basic knowledge in the handling of electronic equipment. Safety symbols Sections regarding safety, marked with a symbol in the left margin, must be read and understood by everyone using the system, carrying out service work or making changes to hardware and software.
  • Page 5: Precautions

    If in doubt about potential danger, contact the physician or the manufacturer of the device to verify that the equipment is properly shielded. Pacemaker patients are advised to keep the IQAN-G3 and its antennas away from the pacemaker while it is on. Air traffic Switch off the IQAN-G3 before boarding an aircraft.
  • Page 6: Electronic Equipment

    Therefore, you should never rely solely upon any wireless device for essential communications. Remember, in order to transmit or receive any type of data, the IQAN-G3 must be switched on and in a service area with adequate cellular signal strength.
  • Page 7 • SIM card from your preferred Network operator or activation of pre mounted SIM card. • A subscription to a server solution that is offered by a Parker supplier. Contact your local Parker Sales office for additional information. Instruction book, IQAN- G3...
  • Page 8: Quick Start Guide

    Add IQAN-G3 modem in IQANdesign. 2. Configure the modem. OTICE Configuration of the modem is only necessary if the built in SIM card is not used. • Connect your PC CAN card directly to the IQAN-G3 CAN bus (diagnostic bus). Instruction book, IQAN- G3...
  • Page 9 CAN-L 120 ohm adapter CAN-H Connect to the IQAN-G3 modem for configuring. • Configure the modem using IQANrun. a Click Tools > Configure CAN modem. b Select to not use the built in SIM card. c Enter the settings from your GPRS internet service provider including the SMSC.
  • Page 10 Proemion account. You also need to have the IMEI and Serial number on the modem available to complete the registration. IMEI number and serial number on the IQAN-G3 unit. • Login to https://parker.proemion.com using your Proemion username/password. • Select Service > Activation form to activate your modem.
  • Page 11 What do I need to do to get started with remote diagnostics? Quick start guide Don't forget to click the "Add" button after entering modem data. OTICE Modem activation will take maximum of 24 hours (office time). Forms submitted on Friday may result in modem activation ocurring on Monday. Instruction book, IQAN- G3...
  • Page 12: Markings/Approvals

    What do I need to do to get started with remote diagnostics? Markings/Approvals Markings/Approvals Instruction book, IQAN- G3...
  • Page 13: Compliance With Fcc

    Compliance with FCC Markings/Approvals OTICE The IQAN-G3 is designed to CE/FCC compliance. CE covers the EEA (European Economic Area) Switzerland FCC covers the USA. Contact the manufacturer for use in other countries. Compliance with FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the...
  • Page 14: Product Description

    General The IQAN-G3 is fully compatible with the IQAN-G2. The IQAN-G3 is a modem unit that works with the MD4, MD3, MC3 and MC2 master modules in IQANdesign platform control systems. The IQAN-G3 is designed to transmit remote diagnostic data information about devices that are connected to a CAN network using GSM telecommunication services and IQAN PC software tools.
  • Page 15: Communication

    The communication interfaces are used for uploading/downloading applications or diagnostics and typically communicate with an IQAN master module. The IQAN-G3 has 1 CAN interface. It is located in the M12-5 pin connector C,1 and is used to interface with IQAN master modules (e.g. IQAN-MD4).
  • Page 16: Antenna

    Do not shorten or lengthen the cable of the antenna. OTICE Do not operate the unit GSM without antenna! To avoid damage to the IQAN-G3, connect/disconnect the GSM antenna only if the power supply to the device is switched off. Instruction book, IQAN- G3...
  • Page 17: Mounting

    Mounting Mounting Mounting the IQAN-G3 The IQAN-G3 does not have to be mounted in any specific orientation. 2 fastening methods, end mounting with 2 bolts, or flat mounting with 4 screws is acceptable. OTICE The IQAN-G3 module should be mounted according to the following instructions: •...
  • Page 18: Installation

    Installing your own SIM card OTICE The correct PIN code must be set in the IQAN-G3 (using IQANrun) before mounting the SIM card. Otherwise, the SIM card could be locked. A PIN Unlock Key, PUK code is required for unlock.
  • Page 19: Opening The Enclosure

    Use ESD precautions and equipment when opening the enclosure to install the GSM SIM card. In the IQAN-G3, the card holder is placed inside the housing. The housing has to be opened to access it. The card holder is mounted to the PCB.
  • Page 20: Supply Voltage

    Do not use the chassis as the negative terminal. Polarity reversal The IQAN-G3 module is protected against power supply polarity reversal, provided an external fuse, max 1 A (Fast) is being used. If this fuse is not used, polarity reversal can damage the unit.
  • Page 21: Communication

    Installation Communication CAN connection The IQAN-G3 has a CAN interface in connector C1 to communicate with IQAN master modules to provide them with remote diagnostic capabilities. The signals on the CAN connection terminals CAN-Low and CAN-High must match the signals on the CAN terminals of the connected devices.
  • Page 22: Activate The Modem

    After registration, you will be able to log in to the web portal. Activate the modem To be able to operate the IQAN-G3, you will need to activate the modem on the web portal. To register (activate ) the modem, use the activation form.
  • Page 23: Web Portal Support

    Web portal for activation and modem management Installation Web portal support For support and additional answers to questions about the web portal, please contact: PROEMION GMBH Donaustr. 14 36043 Fulda, Germany Contact Germany Phone: +49 661 9490-600 Fax: +49 661 9490-666 E-mail: info@proemion.com PROEMION CORP.
  • Page 24: Start-Up

    Start-up procedures Start-up Start-up Start-up procedures This chapter contains instructions for action to be taken in connection with the initial start. ARNING Risk of injury! If the control system is not fitted properly, the machine could move uncontrollably. The machine’s engine shall not be started before the control system is completely fitted and its signals are verified.
  • Page 25: Iqan-G3 Technical Overview

    IQAN-G3 Technical Overview Appendix A Appendix A IQAN-G3 Technical Overview Absolute Maximum Ratings Limit values Parameter Unit Remark min. typ. max. Ambient temperature, T – 30 °C Storage temperature, T – 40 °C Voltage supply on +BAT Reverse polarity protected with 1A fuse.
  • Page 26: Recommended Operating Conditions

    Once the normal operating conditions are exceed- ed, the performance of the device may suffer. Also, the operating temperature for the manufactures´s SIM card may differ from the IQAN-G3 rat- ings. Consult the service provider to determine the temperature rating for the SIM card.
  • Page 27: Led Messages And Actions

    If an error is detected, a message will be presented on the LEDs. ARNING An error message could indicate that a hazardous situation exists. If precautions are not taken, this could result in death, serious injury or major property damage. LED indicators showing different IQAN-G3 modes LED /color Condition Description GPS /green GPS is not active.
  • Page 28: Dimensioning Of The Iqan-G3 Module

    Dimensioning of the IQAN-G3 module Appendix C Appendix C Dimensioning of the IQAN-G3 module  8,5 counterbore (4x)  5 assembly hole (4x) Unit = mm Instruction book, IQAN-G3...
  • Page 29 For latest information visit our website www.iqan.com Information in this instructionbook is subject to change without notice Publ no HY33-8415-IB/UK Edition 2016-04-22 Parker Hannifin Parker Hannifin Electronic Controls Division Electronic Controls Division SE-435 35 Mölnlycke 1651 N. Main Street Sweden...
