XOPIZZACART1
MANGIARE!
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the XOPIZZACART1 and is the answer not in the manual?

Questions and answers

Related Manuals for Xo XOPIZZACART1

Summary of Contents for Xo XOPIZZACART1

  • Page 1 XOPIZZACART1 MANGIARE! ASSEMBLY INSTRUCTIONS...
  • Page 2 dimensions 34 1/4” 870mm 5 1/8” 130mm 19 3/32” 485mm 10” 255mm 25 7/16” 646mm 24” 610mm 30 5/16” 39 3/8” 770mm 1000mm IMPORTANT: THE FINAL ASSEMBLED OVEN AND CART HAVE A COMBINED WEIGHT OF 462lbs...
  • Page 4 (4) M4 x 10 Phillips Head Counter Sunk Screws (4) M4.2 x 15 Phillips Head Self Tapping Screws USE THE PACKING MATERIAL YOUR XOPIZZACART1 ARRIVED IN TO PAD AND CUSHION THE PARTS DURING ASSEMBLY AND PREVENT SCRATCHES TO THE FINISH!
  • Page 5 building the cart Use two people to support the cart during assembly. 1. ATTACH THE FOUR (4) CASTERS TO THE BASE. Locate the base and (2) wheel supports. Align the bolt holes on the wheel supports with the bolt holes on the base. Using the M6 x 15 Phillips head screws supplied, insert (4) screws in the first corner of the base, through a wheel support - then through one of the casters.
  • Page 6 building the cart Use two people to support the cart during assembly. 2. ATTACH THE LEFT SIDE PANEL. (side with the sliding shelf opening) Locate the left side panel, it has a rectangular slot for the shelf. Being careful not to scratch the finish, align the bottom of the left side with the wheeled base. While one person supports it, attach the side panel to the base using (4) M5 x 10 screws.
  • Page 7 building the cart Use two people to support the cart during assembly. 4. ATTACH THE RIGHT HAND SIDE Locate the right hand side, while supporting the middle shelf to avoid scratches - align the cut outs on the right side and attach to the middle shelf and base using (8) M5 x 10 screws.
  • Page 8 building the cart Use two people to support the cart during assembly. 6. INSTALL THE SLIDING SHELF Extend the telescoping shelf supports attached to the top rails through the square slot to expose the screw holes for attachment. Remove the protective plastic sheet from the stainless steel shelf. Align the screw holes in the telescoping shelf supports with the holes in the side of the shelf.

  • Page 9: Setting The Oven

    setting the oven THE OVEN IS VERY HEAVY! TEAM LIFT TO AVOID INJURY OR DAMAGE! 7. SETTING THE OVEN WARNING - Be aware of pinch points and make place the oven safely. Remove the door and place safely out of the way before lifting.
  • Page 10 setting the oven THE OVEN IS VERY HEAVY! TEAM LIFT TO AVOID INJURY OR DAMAGE! 9. FIT THE CHIMNEY CAP The Chimney Cap simply slips into place - AND YOU ARE READY TO FIRE UP!
  • Page 11 The Optional Tool Holder is supplied with the XOPIZZATOOL3 Set JUST TWO BRACKETS TO ATTACH The convenient tool holder is designed to screw directly to your XOPIZZACART1 and keep your large peel, small peel and brush close at hand. It even has a built-in bottle opener.

  • Page 12: Optional Accessories

    (1) Metal Brush for clearing ash and debris from the fire away from the cooking area. (1) Handy Tool Holder Brackets designed to mount directly to the XOPIZZACART1. Your XOPIZZA4 comes with a Stainless Steel Door but there is an optional GLASS DOOR (XOPIZZA4GD) which allows you to keep an eye on the fire...
