Summary of Contents for SAINT-GOBAIN VISION-LITE
- Page 1 VISION-LITE® / VISION-LITE II® PROCESSING GUIDELINES VISION-LITE® / VISION-LITE II® PROCESSING GUIDELINES MAY 2022...
- Page 2 VISION-LITE® / VISION-LITE II® PROCESSING GUIDELINES DATE DOCUMENT CODE 05/2022 SGG-QD-C-GUI-0013-B MAY 2022...
-
Page 3: Table Of Contents
2.4. Handling ............... . 11 3. Processing of VISION-LITE® RANGE ....... 12 3.1. - Page 4 VISION-LITE® / VISION-LITE II® PROCESSING GUIDELINES 3.10. Handling of heat-treated glass ........... . . 17 3.11.
-
Page 5: General
1. General 1.1. PRODUCT DESCRIPTION VISION-LITE® is a coated glass with very low reflectance (1%). According to the product reference, it is available in annealed monolithic with coating on one or two sides or laminated with coatings on both sides (see below). VISION-LITE® is produced on DIAMANT® base glass for architectural applications. -
Page 6: Thickness Recommendations
Relevant national and local regulations should be complied with. 1.3. CE-MARKING VISION-LITE® range complies with EN 1096-4 harmonised European standard for coated glass. The Declaration of Performances (DoP) of the products are available on the CE-marking section of Saint-Gobain Glass web sites and at www.saint-gobain-glass.com/ce. -
Page 7: Position Of The Coating And Identification Of The Coated Face
• Monolithic glass / laminated glass VISION-LITE® is a class A coated glass product (as per EN 1096-1 definition). The antireflective coating must always be positioned on face 1 of the glazing and for maximizing antireflective effect it must be also present on face 2 of the pane. - Page 8 The association of Semi VISION-LITE® with other low emissivity coatings must be assessed case by case, please contact your sales representative. For VISION-LITE® II dual coating (tempered version), the inner side of the inner panel can be coated with PLANITHERM® UN II.
-
Page 9: Identification Of The Coated Face
(laminated or monolithic). In case of • VISION-LITE® II, two protective sheets (clear glass 4 mm) are used on each side of the pack; • The pack and its contents must be protected from water. -
Page 10: Receipt Of The Delivery
Therefore, glass processor should ensure that the process is adapted for coated glass and that the quality control is relevant to detect any quality problem as soon as possible. In case of claim, samples will be required and a visit from a Saint-Gobain Glass representative may be requested. MAY 2022... -
Page 11: Storage
“rainbow” or milky white haze on the surface of the glass, or corrosion pitting on the coated side. VISION-LITE® range glass sheets must be stored, as float glass, vertically (at 3 to 7 degrees) under the following conditions: •... -
Page 12: Processing Of Vision-Lite® Range
In fact, the very low reflectance of the VISION-LITE® range glass may not be detected by the sensor and therefore it may not send the information to the equipment. This could generate inappropriate situation and by anticipation sensor adjustment may be required and should be checked. -
Page 13: Edge Deletion
3210×6000 mm² PLF, the usable surface is 3170×5960 mm². 3.3. EDGE DELETION VISION-LITE® range does not need to be edge deleted whatever the configuration of use. It could be used with polysulphide, polyurethane or silicone IGU sealants in respect of plant control plan. -
Page 14: Manual Edge Working
The glass must be clean immediately after edge working (whatever the process uses) to avoid polluted drying marks to remain on the coating. In case VISION-LITE® range is submitted to several processing steps (edge working + drilling +…) each of them followed by washing, it is recommended to pass the cut sizes in the same direction for each washing phase (to avoid possible generation of multiple crossed scratches). -
Page 15: Tempering / Heat-Strengthening
For interim stacking of washed panes, use cork pads near the edge of the sheets. • In case, in a further step, for VISION-LITE® or VISION-LITE® II, it is of the highest importance that no residues or marks are left on the coating surface after the exit of the pre-processing washing machine. -
Page 16: Heat-Soak Testin
The tin side and the air side of the VISION-LITE® II can be identified on the cutting table by looking for the cutting line on the edge of the jumbo which is coming from the cutting wheel of the float line (air side). -
Page 17: Enamelling
It is processor responsibility to validate enamel material compatibility with the layer and its adherence must be previously checked. It is recommended that any offer for the possible supply of enameled VISION-LITE® II be subject to previous acceptance by the client of samples produced in the operation concerned. -
Page 18: Processing Quality Checks
VISION-LITE® / VISION-LITE II® PROCESSING GUIDELINES conditions are described in § 3.6. • As for other processing steps, no roller blocked should mark the coating face against rollers. • Any traces of sealant remaining on the coating after application must be removed immediately before they harden. -
Page 19: Environment / Waste Glass / Health Issues
6. Protection, cleaning and maintenance of the end products 6.1. PROTECTION OF THE GLAZING DURING BUILDING WORKS As for other glass products, it is important with VISION-LITE® range glass products to respect the following: • In order to avoid damaging the glass with aggressive contaminants from site-works (e.g. paint, plaster, mortar…), it is recommended that glazings are installed after all other work on site has... -
Page 20: Cleaning And Maintenance
However, SAINT-GOBAIN GLASS keeps the right to modify or add any information without previous notice. SAINT-GOBAIN GLASS is not liable for the possible lack of information on VISION-LITE® (II) products that would not be contained in the present document. - Page 21 VISION-LITE® / VISION-LITE II® PROCESSING GUIDELINES SAINT-GOBAIN INNOVATIVE MATERIALS POLSKA SP. Z O.O. ODDZIAŁ GLASS ul. Szklanych Domów 1 42-530 Dąbrowa Górnicza www.saint-gobain-glass.pl bgp@saint-gobain.com MAY 2022...
