79201R
Introduction
Thank you and congratulations for purchasing the i-box Max - Performance Portable Bluetooth Sound System.
We designed the i-box Max to not only look great but also provide a wide range of features and audio flexibility.
We pride ourselves on design and quality, which is why we offer a 5 year warranty for all i-box products
(subject to terms and conditions). To obtain your 5 year warranty simply complete and return the warranty
registration form or simply register online at www.iboxstyle.com
Controls and connectivity
top Panel
Fig. 1
1
1. Power on/off
2. Mode selector*
3. Bluetooth connection*
4. Previous Track*
5. Play/Pause/phone answer*
6. Next Track*
back Connections and Control Panel
Fig. 2
9
Max
PERFORMANCE PORtAblE bluEtOOth®
SOuNd SyStEM
USER GUIDE
2
3
4
7. NFC touch point*
8. Volume control wheel
9. DC input
10. phono/RCA Stereo input
11. USB Charge point 1
12. USB Charge point 2
10
11
5
6
12
13 14
7
8
13. Aux 3.5mm Stereo output
14. Aux 3.5mm Stereo input
15. Bass adjust
16. Treble adjust
*Touch sensitive controls,
activated by a light touch
15 16
ENG
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Max and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for i-box Max

  • Page 1 Thank you and congratulations for purchasing the i-box Max - Performance Portable Bluetooth Sound System. We designed the i-box Max to not only look great but also provide a wide range of features and audio flexibility. We pride ourselves on design and quality, which is why we offer a 5 year warranty for all i-box products (subject to terms and conditions).
  • Page 2: Getting Started

    Bluetooth mode and ensure Blue LED is flashing quickly). 4. Hold the Bluetooth device against the NFC logo on the Max for 3-4 seconds (8 in Fig. 1). (On most smartphones the NFC located in the centre of the back of the phone).
  • Page 3: Sound Adjustment

    1. Connect one end of the stereo jack cable supplied to the audio input of your stereo speaker system / PA (Depending on your sound system you may need to use alternative cables or adaptors). 2. Connect the other end of the stereo jack cable to the AUX OUT 3.5mm stereo output on the Max (12. Fig 1). Sound adjustment You can enjoy the powerful sound of the Max just the way you like it by adjusting the bass and treble controls on the rear of the speaker (15,16, Fig 1).
  • Page 4: Troubleshooting

    1.3 Ensure the correct mode has been selected depending on the connection type. 1.4 Ensure the volume wheel on your Max is set to a reasonable level. 1.5 Ensure the volume of the audio source is set to a reasonable level.
  • Page 5 79201R Introduction Nous vous remercions et vous félicitons d’avoir acheté le système audio portable Bluetooth i-box Max Performance. Nous avons conçu l’enceinte i-box Max non seulement pour qu’elle soit belle, mais également pour qu’elle propose un éventail de fonctions et de sons.
  • Page 6: Mise En Route

    Recharge et mise sous tension le système audio Max peut être alimenté à partir d’une prise de courant ou grâce à la batterie intégrée. branchez l’adaptateur c.a. fourni à l’entrée c.c. située à l’arrière de l’enceinte Max (9, Fig 1).
  • Page 7: Réglage Du Son

    CD, etc. 2. Branchez l’autre extrémité du câble jack stéréo à l’entrée stéréo aux. De 3,5 mm de l’enceinte Max (13, Fig. 1). 3. Utilisez le sélecteur de mode pour choisir le mode d’entrée aux. (le témoin du bouton de marche est vert).
  • Page 8: Dépannage

    dépannage 1. Le son est faible ou inexistant. 1.1 S’assurer que votre appareil audio et l’enceinte sont chargés. 1.2 Vérifier que la connexion (Bluetooth ou AUX) est parfaitement fonctionnelle et sécurisée. Si vous utilisez la prise AUX, vérifier que le câble est correctement branché à l’enceinte et à votre appareil audio.
  • Page 9 Einleitung Vielen Dank und herzlichen Glückwunsch, dass Sie sich für den Kauf des hochleistungsfähigen, tragbaren Bluetooth-Soundsystems i-box Max entschieden haben. Das i-box Max besticht nicht nur durch sein großartiges Aussehen, sondern auch durch seine zahlreichen Funktionen und seine Klangflexibilität. Wir sind stolz auf unser Design und die hohe Qualität, daher gewähren wir eine Garantiezeit von 5 Jahren auf alle i-box-Produkte (gemäß...
  • Page 10: Erste Schritte

    (Benutzen Sie die Auswahltaste für den Modus, um den Bluetooth-Modus auszuwählen und stellen Sie sicher, dass die blaue LED schnell blinkt.) 4. Halten Sie das Bluetooth-Gerät 3–4 Sekunden lang gegen das NFC-Logo auf dem Max (8, Abb. 1). (Bei den meisten Smartphones befindet sich das NFC-Symbol mittig auf der Rückseite.) 5.
  • Page 11: Laden Über Usb

    1. Schließen Sie ein Ende des mitgelieferten Cinchkabels an den Audio-Ausgang Ihres Soundsystems an. 2. Schließen Sie das andere Ende des Cinchkabels an den Eingängen des Max-Soundsystems (10, Abb. 1) an. 3. Nutzen Sie die Auswahltaste für den Modus, um den Modus für den Cinch-Eingang auszuwählen (Ein-/Aus- Knopf leuchtet weiß).
  • Page 12: Fehlersuche

    Fehlersuche 1. Der Ton ist sehr leise oder gar nicht hörbar. 1.1 Prüfen Sie, ob Ihr Audiogerät und der Lautsprecher aufgeladen sind. 1.2 Prüfen Sie, ob die Verbindung (entweder Bluetooth oder AUX) voll funktionsfähig und stabil ist. Falls Sie den AUX-Steckanschluss verwenden prüfen Sie, ob das Kabel richtig an den Lautsprecher und an Ihr Audiogerät angeschlossen ist.
  • Page 13 Siamo egualmente orgogliosi del suo design e della qualità che rappresenta, ed è per questo che offriamo una garanzia di 5 anni su tutti i prodotti i-box (soggetta a termini e condizioni). Per ottenere la garanzia di 5 anni, è...
  • Page 14: Per Iniziare

    “Selezionatore modalità” per selezionare la modalità Bluetooth e assicurati che la spia LED blu stia lampeggiando rapidamente) 4. Appoggia il dispositivo Bluetooth sul logo NFC riportato sul Max per 3-4 secondi (8 nella Fig. 1). Sulla maggior parte degli smartphone l’NFC si trova al centro del retro del cellulare.
  • Page 15: Regolazione Del Suono

    Max (12. Fig. 1). Regolazione del suono Puoi goderti il potente suono del Max e regolarlo come meglio credi, grazie ai comandi per controllare i bassi e gli alti, sul retro dell’altoparlante (15,16, Fig. 1). Se usi un dispositivo Bluetooth dotato di tecnologia aptX godrai di una qualità del suono a livello di Compact Disc.
  • Page 16: Risoluzione Di Problemi

    Risoluzione di problemi 1. Il suono è troppo debole o del tutto assente. 1.1 Accertarsi che il dispositivo audio e l’altoparlante siano entrambi carichi. 1.2 Accertarsi che la connessione (Bluetooth o AUX) sia del tutto attiva e sicura. Se si utilizza la porta AUX, verificare che il cavo sia correttamente inserito sia nell’altoparlante sia nel dispositivo audio.
  • Page 17 Introducción Muchas gracias y enhorabuena por adquirir nuestro Sistema de Sonido Portátil con Bluetooth i-box Max Performance. El i-box Max tiene un diseño muy atractivo y dispone además de una gran variedad de funciones y flexibilidad de audio. Confiamos en el diseño y la calidad de nuestros productos, por eso ofrecemos una garantía de 5 años en todos los productos i-box (ver condiciones generales).
  • Page 18: Para Empezar

    El sistema de sonido Max funciona conectándolo a la red eléctrica o mediante su batería interna. Conecta el adaptador AC a la entrada de corriente de la parte trasera del Max (9, Fig. 1) Es posible utilizar el Max mientras está conectado a la corriente y cargándose.
  • Page 19: Ajuste De Sonido

    1. Conecta un extremo del jack estéreo incluido a la entrada de audio de tu sistema de altavoces (según el sistema de sonido que utilices, puede que necesites cables o adaptadores diferentes) 2. Conecta el otro extremo del jack estéreo a la salida AUX OUT de 3,5 mm del Max (12, Fig. 1). Ajuste de sonido Puedes disfrutar del potente sonido del Max a tu manera ajustando los bajos y agudos con los botones de la parte trasera del altavoz (15, 16, Fig.
  • Page 20: Especificaciones

    troubleshooting 1. El sonido es muy bajo o inexistente 1.1 Asegúrate de que tanto tu dispositivo de audio como el altavoz tengan carga. 1.2 Asegúrate de que la conexión (ya sea por Bluetooth o AUX) se ha realizado correctamente y es segura. Si utilizas el puerto de AUX, comprueba que el cable se haya introducido correctamente tanto en el altavoz como en el dispositivo de audio.
