TELGUARD
DIGITAL
TG-11
Residential and Commercial
Cellular Alarm Communicator
Cellular Alarm Transmission System
Using GSM Digital Cellular Technology
MODEL TG11G001
INSTALLATION AND OPERATING INSTRUCTIONS
Technical Support: 800-229-2326
M-F 8:00AM – 8:00PM EST
Saturday 8:00 AM – 5:00 PM EST
COMPANY CONFIDENTIAL
®
For use by TELGUARD
customers only.
Distribution to others strictly prohibited under penalty.
Revised August 20, 2008
®
TELGUARD
is a registered trademark of Telular Corporation. Products are
protected under one or more of the following U.S. patents:
4,658,096
4,737,975
4,775,997
4,868,519
4,922,517
© 2008 Telular Corporation
56039504 08/20/2008
© 2008 Telular Corporation
Advertisement
Table of Contents
Related Manuals for Telguard Digital TG-11
Summary of Contents for Telguard Digital TG-11
- Page 1 ® TELGUARD DIGITAL TG-11 Residential and Commercial Cellular Alarm Communicator Cellular Alarm Transmission System Using GSM Digital Cellular Technology MODEL TG11G001 INSTALLATION AND OPERATING INSTRUCTIONS Technical Support: 800-229-2326 M-F 8:00AM – 8:00PM EST Saturday 8:00 AM – 5:00 PM EST COMPANY CONFIDENTIAL ®...
-
Page 2: Foreword
Digital products for its competitive price and superior features. The Telguard model TG11G001 (TG-11) is UL Listed for Household Fire systems, Household Burglary systems and Commercial Burglary Systems Use. This means that the TG11 may be used in Household Burglary, Household Fire systems or Commercial Burglary as the main or secondary communication line. -
Page 3: Future Testing And Limitations On Use
Do not transport or store flammable gas, liquid or explosives in the area of your Telguard Digital product and accessories. - Page 4 ® TERMS AND CONDITIONS FOR USE OF TELGUARD PRODUCTS (“Product”) These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW.
-
Page 5: Table Of Contents
TABLE OF CONTENTS FOREWORD ............................... I ABOUT THIS MANUAL ..........................I NOTICES ..............................I FUTURE TESTING AND LIMITATIONS ON USE ..................II UL LISTINGS ..........................1 PRE-INSTALLATION CHECKLIST ..................... 1 INSTALLATION STEPS ...................... -
Page 6: Ul Listings
If there is NOT enough room inside the cabinet, then you will need to install the TG-11 externally. To do this, knock out one of the pre-punched holes either on the top of the cabinet (Figure 3. 3 – External Top Mount) or on the right-side (Figure 3. - Page 7 Figure 3. 1 – Internal Mount Figure 3. 2 – External Side Mount 56039504 08/20/2008 © 2008 Telular Corporation...
- Page 8 Figure 3. 3 – External Top Mount STEP 2. Once the TG-11 is secure, a location for the antenna must be chosen. In most cases, the antenna will be directly mounted to the cabinet. To reduce the effects of RF interference, avoid routing the antenna cable over or under the alarm PCB or bundling it with other wires.
- Page 9 4) Relocate the antenna (using external mounting kit) STEP 6. If proper signal has been achieved, the panel can now be programmed for use with the TG-11. Generally speaking, the TG-11 is equivalent to Honeywell’s Long Range Radio (LRR), therefore the same programming steps are necessary.
- Page 10 Note the status of the TG-11, by using LEDs. Use Chart 6. 3 below as reference. Make sure the TG-11 is no longer in the RSSI mode before attempting to read the status information. To toggle between modes, press the RSSI button (this will also update status with the most recent information).
-
Page 11: Power Management
POWER MANAGEMENT The TG-11 derives all of its power via the alarm panel’s Aux power (i.e. ECP bus). It very important to assure that the total current, for the overall alarm installation, does not exceed the panel’s Aux power specifications (refer to alarm panel’s Installation and Setup Guide). -
Page 12: Led Descriptions
6.2 RSSI Mode The RSSI button on the front of the TG-11 is used to toggle RSSI mode. RSSI mode uses the LEDs to indicate received signal strength and the number of detected cellular towers. Slowly move the antenna to achieve maximum signal strength. - Page 13 6.3 Operational Status Registration The LEDs provide registration indications as shown in the following table. Chart 6. 2 System Status LEDs Registration Indications LEDs #1 thru #5 Flashing Failed Registration /Weak Signal LED #1 and #4 Flashing NAK - Registration Error LED #1 On and solid Registration Successful Functionality...
-
Page 14: System Specifications
The Telular TG-11 radio supports GSM/GPRS cellular protocol. It is equipped with an integrated radio transceiver conforming to all the requirements of the GSM Phase 2+ tests specified in GSM 11.10. The TG-11 transceiver is FCC compliant, meeting all of the requirements of Part 24 and SAR testing. It is also compliant to the PTCRB NAPRD03 requirements. -
Page 15: A1 Activation Form
ACTIVATION FORM 56039504 08/20/2008 © 2008 Telular Corporation... -
Page 16: Warranty
Part No. Description Basic Hardware: TG-11 Model TG11G001 Model TG11G001 (TG-11) meets the requirements for Household Burglary, Household Fire, and Commercial Burglary installations. TG11G001 is UL Listed for the following: UL Household Burglary (NBSX) UL Commercial Burglary (APAW: Police Station – Burg and AMCX: Central Station...
