DOL 68 Camera Weighing System
Technical User Guide
English: For other language variants of this document we refer to:
Español: Para otras variantes del idioma de este documento, visite:
Français: Pour les versions dans d'autres langues de ce document veuillez consulter:
http://docs.skov.com/1199
2019.01.10 • 604263
Software version 1.0
Advertisement
Table of Contents
Related Manuals for Skov DOL 68
Summary of Contents for Skov DOL 68
- Page 1 DOL 68 Camera Weighing System Technical User Guide English: For other language variants of this document we refer to: Español: Para otras variantes del idioma de este documento, visite: Français: Pour les versions dans d'autres langues de ce document veuillez consulter: http://docs.skov.com/1199...
- Page 3 • It was released in 2019 Product and Documentation Changes SKOV A/S reserves the right to modify this manual and the product described in it without notice. In case of doubt, please contact SKOV A/S. The date of change appears on the front and back pages.
-
Page 4: Table Of Contents
Mounting examples ....................13 5.3.1 DOL 68 camera kit ....................... 13 5.3.2 Mounting the DOL 68 camera kit on a flat ceiling ............14 5.3.2.1 DOL 68 camera kit straight onto ceiling ....................15 5.3.2.2 DOL 68 camera kit with mounting rails around piping ................16 5.3.3... - Page 5 Camera ..........................32 TABLE FOR ROI SIZES ................. 35 TABLE FOR IP ADDRESSES ................ 35 MAINTENANCE GUIDE ................. 36 11.1 Cleaning ........................36 11.1.1 Camera ..........................36 11.1.2 DOL 68 CWS ........................36 TECHNICAL DATA ..................37 DOL 68 Camera Weighing System...
-
Page 6: Introduction
2 Product description The DOL 68 CWS is used to estimate the gain of weaners or finishers. The system is part of the FarmOnline system for production monitoring of weaners and/or finishers. It requires FarmOnline Explorer version 3.4 or later to be installed on a PC with local internet access to DOL 68. -
Page 7: Product Survey
130446 Mounting rail 15x30.5x2,000 mm, A2 For mounting DOL 68 camera kit on ceiling. Use the number of mounting rails necessary to position the DOL 68 camera kit correctly relative to ceiling height and type of animal. See section with mounting examples 5.3. -
Page 8: General Information
The list below shows the tool(s) recommended for assembling and fitting the CWS computer and cameras. Topic Description Computer Multimeter Screwdriver set Allen key kit Side cutter Needle-nose pliers Knife Laser distance meter Tape measure Water pump (multi-grip) pliers Cordless drill Screwdriver bits DOL 68 Camera Weighing System... - Page 9 Technical User Guide Drill bits, various sizes Spirit level Ladder DOL 68 Camera Weighing System...
-
Page 10: Mounting Guide
The light for the camera must be timer-controllable. This can be done using either the timer in the DOL 635/DOL 639 or an external timer. • The distance from cameras to the DOL 68 CWS and from the DOL 68 CWS to the FarmOnline computer switch must not exceed 100 m. •... -
Page 11: Weaners
It can prevent the camera from getting good pictures and reduce the number of weighings. Figure 3: Siting of two cameras in a section with finishers. DOL 68 Camera Weighing System... -
Page 12: Mounting The Dol 68 Cws
10 cm (B) at the bottom. • 5 cm (C) at the sides. 3) Mount the DOL 68 CWS with Ø5 mm screws according to the distance measurements in the drawing. Figure 3: Mounting the DOL 68 CWS DOL 68 Camera Weighing System... -
Page 13: Mounting Examples
Width X [mm] below the [mm] camera [mm] 1000 1200 1500 1800 1350 2000 2400 1800 Adjust the camera so that it points straight down on the floor. If necessary, use a small spirit level. DOL 68 Camera Weighing System... -
Page 14: Mounting The Dol 68 Camera Kit On A Flat Ceiling
Technical User Guide 5.3.2 Mounting the DOL 68 camera kit on a flat ceiling Mount camera with: 2 x Screw M8x14 cylind. int. hexag. A2 DIN912 2 x M8 threaded plate Mount terminal box with: 2 x Machine screw M4x16 cyl... -
Page 15: Dol 68 Camera Kit Straight Onto Ceiling
Technical User Guide 5.3.2.1 DOL 68 camera kit straight onto ceiling In this example, the following has been used: 1 x 130454 DOL 68 camera kit Screws for mounting rail onto the ceiling are not supplied. Figure 4: Example of mounting straight onto a flat ceiling... -
Page 16: Dol 68 Camera Kit With Mounting Rails Around Piping
Technical User Guide 5.3.2.2 DOL 68 camera kit with mounting rails around piping In this example, the following have been used: 1 x 130454 DOL 68 camera kit 2 x 130447 DOL 68 rail mounting kit 2 x 130445 Mounting rail 15x30.5x1000 mm, A2 Screws for mounting rails onto the ceiling are not supplied. -
Page 17: Mounting The Dol 68 Camera Kit On Sloping Ceiling
Technical User Guide 5.3.3 Mounting the DOL 68 camera kit on sloping ceiling Mount camera with: 1 x Screw M8x14 cylind int 6kt A2 DIN912 1 x Washer ø8,4/ø16x1,6 A2 DIN125A 1 x. Rotary joint for PV24-108 M8 Mount LED light with: 2 stk. -
Page 18: Dol 68 Camera Kit With 1 M Mounting Rail
Technical User Guide 5.3.3.1 DOL 68 camera kit with 1 m mounting rail In this example, the following have been used: 1 x 130454 DOL 68 camera kit 3 x 130447 DOL 68 rail mounting 5 x 130445 Mounting rail 15x30.5x1000 mm, A2... -
Page 19: Dol 68 Camera Kit With 2 M Mounting Rail
Technical User Guide 5.3.3.2 DOL 68 camera kit with 2 m mounting rail In this example, the following have been used: 1 x 130454 DOL 68 camera kit 3 x 130447 DOL 68 rail mounting 2 x 130445 Mounting rail 15x30.5x1000 mm, A2... -
Page 20: Installation Guide
The LAN cables between switch, DOL 68 CWS and cameras must be CAT5e or CAT6 STP LAN cable. Max. cable length 100 m for CAT5e and CAT6 cables. -
Page 21: Connection To Dol 68 Cws
Technical User Guide 6.1.3 Connection to DOL 68 CWS Figure 9: Connection to DOL 68 A) 230 V supply. B) LAN cable from switch. C) LAN cables to cameras. DOL 68 Camera Weighing System... -
Page 22: Connection In Terminal Box
B) LAN cable to camera. To make the screwed connection close tightly around the thin cables and to be able to put the LAN cable through the screwed connection, you have to cut the rubber gasket. DOL 68 Camera Weighing System... -
Page 23: User Guide
ENTER. This starts a ”Command prompt”. To be sure that no other device uses the IP address 192.168.1.64, you have to ping this IP address now to verify the availability. Reconfigure the device, if another device uses the IP address. DOL 68 Camera Weighing System... -
Page 24: Camera
IP configuration of the cameras is set using the ”SKOV Camera Configuration”. This can be found on the SKOV Support Portal. http://www.skov.com/support/Pages/Software.aspx Go to the Software/Software Download page where you find DOL 68 CWS. Here is a download link to the ”SKOV Camera Configuration Download the file and un-zip it. Start the programme. -
Page 25: Dol 68 Cws
DOL 68 CWS DOL 68 CWS konfigureres via FarmOnline Explorer. FarmOnline Explorer version 3.4 must be installed on a PC with local network access to DOL 68 (on the same IP subnet). Only connect one DOL 68 CWS at a time. -
Page 26: Dol 68 Cws Setup
Technical User Guide DOL 68 CWS Setup Enter DOL 68 CWS IP address in an Internet browser. Type default cwsadmin User Name: cws1234 Password: Overview of Menus Main: Main menu. Setup: Setting up camera weighing system. Maintenance: Maintenance. 7.3.1 Main - Overview: Overview of cameras. -
Page 27: Cameras
Technical User Guide 7.3.2.1 Cameras Make sure to complete setup and adjustment on all the cameras connected to the DOL 68 CWS. Settings do not take effect until you press start in the main menu. Type IP Address Click Select opposite camera. - Page 28 20 x 20 for weaners. 40 x 20 for finishers. moves the Hotspot % small square horizontally. 80 x 50 for weaners. 70 x 20 for finishers. DOL 68 Camera Weighing System...
- Page 29 Technical User Guide the height Camera Height measured from the lowest point on the camera to the floor. Press Done Press Start Now you see live pictures from a camera and three pictures from approved weighings. DOL 68 Camera Weighing System...
-
Page 30: Calibration
- Logs: Log and error display. - Reset log: Reset the automatic logs. 7.3.3.1 Version Contains version numbers for all modules in software setup. 7.3.3.2 Logs Contains Results Log, Application Log and System Log. DOL 68 Camera Weighing System... -
Page 31: Troubleshooting Guide
ROI edge by approximately 45%: is set correctly here. **Difference Threshold Dot on the pig is completely white with no small black dots. Dot next to is the pig is completely black. DOL 68 Camera Weighing System... -
Page 32: Camera
Be sure to configure all the cameras. Only connect one camera at a time. When the camera is configurated the next camera can be connected. Insert CD Press Next Select Language Press Next Select folder for SADPTool Press Next DOL 68 Camera Weighing System... - Page 33 Technical User Guide Press Install Select Create Desktop Shortcut Press Next Press Finish DOL 68 Camera Weighing System...
- Page 34 IP address Subnet Mask IPv4 Gateway See section, 10 Table for Type password cwsT3st16 Press Save The change has now been saved; after about 6 sec. the new IP address will be displayed under IPv4 Address. DOL 68 Camera Weighing System...
- Page 35 Table 2: ROI sizes 10 Table for IP addresses Use the table when assigning the IP addresses. Product name Location IP address FarmOnline DOL 68 CWS Camera 1 Camera 2 Camera 3 Camera 4 Table 3: IP addresses DOL 68 Camera Weighing System...
-
Page 36: Maintenance Guide
• solvents • corrosive/caustic agents Figure 10: Cleaning camera 11.1.2 DOL 68 CWS Clean the DOL 68 CWS with a cloth that has been wrung out almost dry in water and without using: • high-pressure cleaner • solvents •... -
Page 37: Technical Data
Shipment Dimensions H x W x D [mm] 381 x 568 x 170 Dimensions packed H x W x D [mm] 421 x 608 x 230 Weight [g] Shipping weight [g] Table 4: Technical data DOL 68 Camera Weighing System... - Page 40 SKOV A/S • Hedelund 4 • Glyngøre • DK-7870 Roslev Tel. +45 72 17 55 55 • Fax +45 72 17 59 59 • www.skov.com • E-mail: skov@skov.dk...
