Liberty Furniture 846-BR13 Assembly Instruction

ITEM # : 846-BR13
: 846-BR14
: 846-BR90
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts which may have
come loose inside the carton during shipment. Identify and count all parts and compare with the parts list below:
846-BR13: Component List
Descriptions
NO.
1 Arch Panel Headboard
Left Headboard Leg
2
3 Right Headboard Leg
846-BR14 : Component List
Descriptions
NO.
4 Footboard
5
Slats
Slat Support
6
846-BR90 : Component List
Descriptions
NO.
7 Side Rails
*
Assembly Tool
Not Included
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.
WARNING!
1. Don't attempt to repair or modify parts that are broken or defective.Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
LIBERTY FURNITURE
ASSEMBLY INSTRUCTION
DESCRIPTION : QUEEN ARCH PANEL HEADBOARD
: QUEEN PANEL FOOTBOARD
: PANEL BED RAILS
Qty.
1
NO.
A
1
B
C
1
D
E
F
Qty.
G
1
H
I
5
5
Qty.
2
8
846-BR13
Assembly Hardware Pack
Descriptions
JCBC Bolt M6 x 40mm
Spring Washer M6
Flat Washer M6
Allen Key M4
Screw P/H Rattan 8 x 1 1/4
Allen Key M5
JCBC Bolt M8 X 25MM
Spring Washer M8
Flat Washer M8
Qty.
6
6
6
1
10
1
8
8
8
PAGE 1 OF 2
