Following the display of Fig. 6-12-1, Press the 1 key or bring the cursor to the line of 1
and press the
ENT./RESET key. The LCD display will turn to be as shown in Fig. 6-12-2.
The timer slave station No. set up first is displayed. When changing, input the address
(number) to change, and then press the
ENT./RESET key is pressed. Press the FUN. key in the case where it does not change.
(2) Confirm / change the data rate
Following the display of Fig. 6-12-1, Press the 2 key or bring the cursor to the line of 2
and press the
ENT./RESET key. The LCD display will turn to be as shown in Fig. 6-12-3.
The data rate set up first is displayed. When changing, input the number to change, and
then press the
ENT./RESET key. It is changed when the ENT./RESET key is pressed.
A setup is performed in the number from 0 to 4.
0 : 156kbps
1 : 625kbps
2 : 2.5Mbps
3 : 5Mbps
4 : 10Mbps
Press the FUN. key in the case where it does not change.
The welding controller which is not a CC Link communication correspondence type can also
perform a setup of a CC Link.
The LCD display will turn to be as shown in Fig. 6-11-4 at the time of setting change of CC
Link. If a FUN. key is pressed, it will return to previous display.

6-13. Ether Net Setting

To change the mode to the Ether Net Setting mode, use the following key strokes.
1. FUN.
2. ↑ ↓ : Bring the cursor to "x=ETHER NET SETTING"
3. ENT./RESET : Execute the mode change.
Fig. 6-12-2
ENT./RESET
Fig. 6-12-3
key. It is changed when the
