- Page 1 Washing Machine USER MANUAL RW-A814SF (For Household Use Only) Read This Manual Use all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use.
-
Page 2: Table Of Contents
CONTENTS Safety Instructions Safety Instructions ..........Installation Product Description ..........Installation ............Operations Quick Start ............. Before Each Washing ..........Detergent Dispenser ..........Control Panel ............Option..............Other Functions ............. Programmes ............Washing Programmes Table ........Maintenances Cleaning And Care ..........Trouble Shooting ............ -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. This appliance is intended to be used in household and similar applications such as: staff kitchen area in shops, offices and other working environments;... - Page 4 SAFETY INSTRUCTIONS • The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. • Before any maintenance the device, unplug the appliance from the mains. • Always unplug the machine and turn off the water supply after use.
- Page 5 SAFETY INSTRUCTIONS • Glass door may be very hot during the operation. Keep kids and pets far away from the machine during the operation in very wet rooms as well as in the rooms with explosive or caustic gas. • Remove all packages and transport bolts before using the appliance.
- Page 6 SAFETY INSTRUCTIONS • Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result. Risk of damaging appliance! • Your product is only for home use and is only designed for the textiles suitable for machine washing. •...
- Page 7 SAFETY INSTRUCTIONS • Make sure that all pockets are emptied. Sharp and rigid items such as coin,brooch,nail,screw or stone etc. may cause serious damages to this machine. • Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.
-
Page 9: Installation
INSTALLATION Installation Installation area ！ WARNING! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. W> 20mm Before installing the machine, the location characterized follows shall be selected: 1.Rigid, dry, and level surface 2.Avoid direct sunlight 3.Sufficient ventilation... - Page 10 INSTALLATION Levelling the washing machine WARNING! ！ • The lock nuts on all four feet must be screwed tightly against the housing. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts. 2.Loosen the lock nut turn the feet until it closely contacts with the floor.
- Page 11 INSTALLATION Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise. water supply hose water Inlet valve Drain Hose ！ ！ WARNING! • Do not kink or protract the drain hose. •...
-
Page 12: Operations
OPERATIONS Quick Start CAUTION! • Before washing, please make sure it’s installed properly. • Before washing at first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follows. 1. Before Washing Main wash Softener... -
Page 13: Before Each Washing
OPERATIONS Before Each Washing • The working condition of the washer should be(0-40)℃.If used under 0℃,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0℃or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use. -
Page 14: Detergent Dispenser
OPERATIONS Detergent Dispenser Pre wash detergent Main wash detergent Softener Dam-board Dam-board Liquid detergent Powder detergent Pull out the dispenser CAUTION! • Detergent only need to be added in "case I “after selecting pre-washing for machines with this function. Programme Programme Cotton Eco Self Clean... -
Page 15: Control Panel
日常60分鐘 混合 手洗 脫水及脫水 羊毛 脫水 按3秒 潔桶 RW-A814SF Note! • The chart is for reference only, Please refer to real product as standard. Start/Pause Press the button to start or pause the Product is switched off. washing cycle. Programmes Option Available according to the laundry type. - Page 16 OPERATIONS Option Pre Wash Pre Wash The Prewash function can get an extra wash before main wash,it is suitable for washing the dust rises to surface of the clothes;You need to put detergent into the Case (I) when select it. Extra Rinse Extra Rinse The laundry will undergo extra rinse once after you select it.
-
Page 17: Other Functions
OPERATIONS Other functions Temp. ℃, Press the button to regulate the temperature(Cold,20 30℃, 40℃,60℃,90℃) Speed Press the button to change the speed. 1400: 0-400-600-800-1000-1200-1400 Programme Programme Default Speed(rpm) Default Speed(rpm) 1400 1400 Cotton Eco Self Clean Cotton Wool 1200 Delicate Quick15' Rapid45' 1000... - Page 18 OPERATIONS Child Lock To avoid mis operation by children. Delay Speed Choose the Programme Press [Delay] and [Speed] Start 3 sec. till buzzer beep. CAUTION! • Press the two button 3sec. also to be released the function. • The “Child Lock” will lock all buttons except Power button. •...
-
Page 19: Programmes
OPERATIONS Programmes Programmes are available according to the laundry type. Programmes Hard-wearing textiles, heat-resistant textiles made of cotton or Cotton linen. Wash synthetic articles, for example: shirts, coats, blending. Synthetic While washing the knitting textiles, detergent quantity shall be reduced due to its loose string construction and easily forming bubbles. -
Page 20: Washing Programmes Table
OPERATIONS Washing Programmes Table Programme Load(kg) Temp. Default Time °C Default (SLIM) Cotton Eco 0:58 Cotton — Quick15' 0:15 Cold Rapid 45' 0:45 Daily Wash (60') 1:00 Rinse & Spin 0:31 Spin Only 0:12 Self Clean 1:21 Wool 1:06 Delicate 1:00 1:13 Jeans... -
Page 21: Maintenances
MAINTENANCES Cleaning And Care ！ WARNING! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. - Page 22 MAINTENANCES Cleaning The Inlet Filter Note! • Inlet filter must be cleaned if there is less water. Washing the filter in the tap 1.Close the tap. 2.Remove the water supply hose from the tap. 3.clean the filter. 4.Reconnect the water supply hose Washing the filter in washing machine: Screw off the inlet pipe from the backside of the machine.
-
Page 23: Trouble Shooting
MAINTENANCES Trouble Shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact Shun Hing Electric Service Centre Ltd. Description Reason Solution Washing machine Restart after the door is closed Door is not closed properly cannot start up Check if the clothes is stuck... -
Page 24: Technical Specifications
MAINTENANCES Technical Specifications Power Supply 220-240V~,50Hz MAX.Current Standard Water Pressure 0.05MPa~1MPa Model Rated Power Dimension Net Weight Washing Capacity (W*D*Hmm) RW-A814SF 8.0kg 1950W 595*475*850 63kg 10 24 10 23... - Page 25 MAINTENANCES Note! • The actual parameters will depend on how the applicance is used,and maybe different with the parameters in above mentioned table. • The household washing machine is equipped with power management system.The duration of the left-on mode time is less than 10 minute.
- Page 26 Special Avowal 1. The information above has been checked; our company reserves the hermeneutic power to any print errors or misunderstanding on the content. 2. Any technology improvement will add into new instruction without any prior notices. The product appearance and color refer to the practical washing machine.
- Page 27 RW/M/0922...
