- Page 1 User Manual 1071 Capacitance Decade Box Version 1.2 10-22 Time Electronics Ltd Unit 5, TON Business Park, 2-8 Morley Road, Tonbridge, Kent, TN9 1RA, United Kingdom. T: +44 (0) 1732 355993 | F: +44 (0) 1732 350198 mail@timeelectronics.co.uk | www.timeelectronics.com...
- Page 2 All rights reserved. Nothing from this manual may be multiplied, or made public in any form or manner, either electronically or hard copy, without prior written consent from Time Electronics Ltd. This also applies to any schematics, drawings and diagrams contained herein.
-
Page 3: Table Of Contents
Time Electronics 1071 Capacitance Decade Box User Manual Contents Introduction ............................ 2 Specifications ..........................3 Operation ............................4 Safety Precautions ..........................4 Front Panel Controls and Connections ....................4 Operating Instructions ........................... 5 Capacitance Setting Table ........................7 Warranty and Servicing ......................... 8... -
Page 4: Introduction
High accuracy and wide range makes the 1071 capacitance decade box suitable for applications in industry and education. It is both compact and robust, housed in a metal case that provides complete screening, with a protective rubber cover to guard the 1071 against everyday wear and tear. -
Page 5: Specifications
Weight ............ 0.6 kg (1.0 kg including protective cover). Options ..........Calibration certificates, carry case. Country of Origin ........United Kingdom. Ordering Information 1071 ............Capacitance Decade Box 9026 ............Carry case (replaces protective cover) C161 ............Traceable calibration certificate (Factory) C114 ............Accredited calibration certificate (ISO 17025) -
Page 6: Operation
Time Electronics 1071 Capacitance Decade Box User Manual Operation Safety Precautions Observe proper safety operational guidelines when working with high voltages. To minimize shock hazard connect the case terminal to an electrical ground. Always take precautions to avoid and prevent contact with live components. -
Page 7: Operating Instructions
Time Electronics 1071 Capacitance Decade Box User Manual Operating Instructions 3.3.1 Connections Connection to the decade box is via 4 mm safety terminal posts, using 4 mm shrouded or standard plugs. Alternatively, crocodile clips or stripped wire connections can be used. - Page 8 • Set 0 on the unused decades. For a quick reference to the setting values of the 1071, please see the Capacitance Setting Table on the following page. Note: All capacitance boxes have a residual capacitance, i.e. even when the dials are set to zero there is still a capacitance value across the output.
-
Page 9: Capacitance Setting Table
Time Electronics 1071 Capacitance Decade Box User Manual Capacitance Setting Table The below table shows the settings of each capacitance decade using the switches. 100 ηF 10 ηF 1 ηF 100 ρF 10 ρF 10 µF 1 µF Decade Decade... -
Page 10: Warranty And Servicing
Time Electronics’ total liability is limited to repair or replacement of the product. Note that if Time Electronics determine that the fault on a returned product has been caused by the user, we will contact the customer before proceeding with any repair. - Page 11 User Manual Returning Instruments Prior to returning your product please contact Time Electronics. We will issue a return merchandise authorization (RMA) number that is to accompany the goods returning. Further instructions will also be issued prior to shipment. When returning instruments, please ensure that they have been adequately packed, preferably in the original packing supplied.
