QUICK MANUAL FOR USE AND INSTALLATION
The Quick Manual will guide you through a quick installation of the product, but in no case could it replace the full operating manual. A
complete operating manual is available on our website www.xvent.cz or can be downloaded using a QR code.
Before starting all installation work, make sure that the mains power outlet you want to use for unit connection is equipped
with a protective contact (pin) and meets the requirements for unit power supply (production plate).
Use the smart device (mobile
phone, tablet, etc.) equipped
with this technology to read
the QR code.
Use of the unit
-
The Miracleair unit is designed for indoor covered and dry areas with an ambient temperatures from 5 °C to +40 °C and with a maximum
relative humidity of 70% - non-condensing, without too high a dust load in the surrounding air.
-
The aerosol extraction unit MiracleAir 300-A is designed to extract the aerosol-fume that may occur in medical operations related to the
treatment of the patient, e.g. dental treatment, anaesthetic treatment.
-
Air purifier–the MiracleAir 400-B unit–is designed to filter air in the internal environment, e.g.: medical facilities, waiting rooms, cosmetic
facilities, offices
-
The unit is designed for the extraction and filtering of particles larger than 0,1 μm (filtering efficiency 99,95 per cent).
-
Neither the manufacturer nor the supplier is liable for damage caused by improper use of the units. The risk is borne solely by the user.
Technical parameters
Regulation of the unit
all control elements located on the body of the unit that are designed for user control are energized by 10VDC (safe voltage)
Main control panel
The indicator light of the
filter box clogging: it lights
up when the filter box is
clogged. Like this, it also
informs the user about the
necessity to change the
filter box.
Verze 001-GBR (19.05.2021)
MiracleAir 300-A; MiracleAir 400-B
Stránka 1 z 2
53009 Pardubice-Trnová
Miracleair unit shall not be used:
-
for suction of burning or glowing
substances
-
for exhausting readily flammable or
explosive gases.
-
to exhaust aggressive media
-
to exhaust liquids of any kinds in an
environment with increased risk
-
of explosion, flammable substances
and increased dust.
-
Neither the manufacturer nor the
supplier is liable for damage caused by
improper use of the units.
Signal diode
It is signalling the operation of the entire unit. If
the diode is lit, the unit is on. If the diode is not
on, the unit is switched off.
The main control element (dial), allows
continuous adjustment of the power of the unit
in any position from the minimum to maximum
power according to user requirements. The
"OFF" position allows the entire regulator to be
switched off.
Xvent s.r.o.
Poděbradská 289
D-502-0174
