- Page 1 ThermoCamera Connect COLOUR TFT...
-
Page 2: Function / Application
– The measuring device complies with electromagnetic compatibility and wireless radiation regulations and limits in accordance with the RED 2014/53/EU. – Umarex GmbH & Co. KG hereby declares that the ThermoCamera Connect radio equipment complies with the essential requirements and other provisions of the European Radio Equipment Directive 2014/53/EU (RED). - Page 3 ThermoCamera Connect 3,2“ TFT colour display ON/OFF Control menu (cancel) Hot keys Menu navigation Menu navigation / select digital image, Lens cover Menu navigation / overlay infrared / digital select digital image, Camera image and infrared image overlay infrared / digital...
- Page 4 Main menu 13 Open media gallery 14 Change color palette 15 Set emissivity coefficient 16 Settings Images Color palette Emissivity Settings Main menu settings Settings 17 Auto shutdown Auto shutdown 18 Display brightness Intensity 19 Menu language 20 Time format Language 21 Time settings Time format...
-
Page 5: Charging The Li-Ion Battery
ThermoCamera Connect Charging the li-ion battery Removing / inserting li-ion battery pack To charge the Li-ion battery pack, plug Open battery compart- the supplied USB cable ment (7) and remove/ into the charging insert the Li-ion battery socket „i“ and pack. - Page 6 Settings: Auto shutdown The device switches off automatically after a set period of inactivity. Settings Auto shutdown Auto shutdown Intensity Confirmation Language 5 min Time format 20 min Set time Cancel Spot WLAN Exit menu Image correction Version Settings: Display brightness Settings Auto shutdown Intensity...
- Page 7 ThermoCamera Connect Settings: Time format Settings Auto shutdown Intensity Confirmation Language Time format Time format Set time 24 hour Cancel Spot AM/PM WLAN Exit menu Image correction Version Settings: Set time Settings Auto shutdown Intensity Language Time format Set time...
- Page 8 Settings: WLAN connection To evaluate the data, the ThermoCamera Connect can be connected via WLAN to a terminal device (desktop PC or mobile phone) with WLAN capabilities. For this purpose first select the required WLAN SSID on the device (MAC:MMMMMM). MMMMMM corresponds to the MAC address.
- Page 9 ThermoCamera Connect Settings: Version Settings Auto shutdown Intensity Language Time format Set time Spot WLAN Image correction Version Version V 2.3.7 Emissivity Before each use, check the settings for infrared measurement and adjust them to the respective measuring situation to ensure accurate measurements. Pay particular attention to the general parameters for the emissivity coefficient.
- Page 10 Emissivity table (reference values with tolerances) Metals Alloy A3003 Iron Steel Oxidised 0.20 Oxidised 0.75 Alloy (8% nickel, Roughened 0.20 With rust 0.60 18% chromium) 0.35 Galvanised 0.28 Aluminium Iron, cast Oxidised 0.80 Oxidised 0.30 Non-oxidised 0.20 Heavily oxidised 0.88 Polished 0.05 Molten mass...
-
Page 11: Image Modes
ThermoCamera Connect Color palette Confirmation Spectrum Iron Cancel Cool Images White Color palette Black Exit menu Emissivity Settings Image modes There are 5 image modes to choose from. A. IR image (IR) B. Digital image (Visible) C. Digital image with IR image overlay (MIX), level 1 D. - Page 12 This device complies with all necessary standards for the free movement of goods within the EU. This product is an electric device and must be collected separately for disposal according to the European Directive on waste electrical and electronic equipment. Further safety and supplementary notices at: http://laserliner.com/info?an=AGR...
-
Page 13: Technical Data
ThermoCamera Connect Technical data Subject to technical changes without notice. 19W05 IR sensor Resolution: 220 x 160 pixels, uncooled microbolometer, 9 Hz, 8-14 μm IR optics High-quality IR-lens, 27° x 35° (FOV), fixed focus, working area: 0.5 m ... 20 m Thermal sensitivity 0.07°C @ 30°C... - Page 15 ThermoCamera Connect...
