Wicker Sofa Set
sku:VJ-07
1
Thank you for choosing Joivi!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it immediately. Send us an email at
help@joivi.com.
Happy?
Please leave us a review!
You can make others happy too!
Advertisement
Related Manuals for Joivi VJ-07
Summary of Contents for Joivi VJ-07
- Page 1 Wicker Sofa Set sku:VJ-07 Thank you for choosing Joivi! Our goal is to provide high quality outdoor furniture with outstanding customer service-all at an affordable price. Please let us know how we are doing! Problems? (Missing pieces, wrong pieces...) We will fix it immediately. Send us an email at help@joivi.com.
-
Page 2: At The End Of The Season
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Safety For domestic use only. Don't tighten all the bolts before the product is fully assembled. It would be useful to ask someone to help you assemble the product. ... - Page 3 Tips for Cushions In order to compress the package, we put the cushions in the gap of some parts. So there may be crinkle on the fabric. Don’t worry. Just flap every corner of the cushion evenly and it will get back into its original shape soon. - 2 -...
- Page 4 COMPONENT LIST - LEFT CORNER SOFA Item Reference Description Qty. Image Left Armrest Back Side Panel Side Panel Seat Base Seat Cushion Back Cushion M6X35 Head Cap Screws Washer Allen Key - 3 -...
- Page 5 NOTE: Do NOT tighten any screws fully first until you have tightened all the screws. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned, loosen the screws and tighten sequentially. If the Corner sofa is not stable it could lead to damage to the product. Attach the Side Panel (D3) to the Seat Base (D5) by securing with M6*35 Head Cap Screws (D) and Washers (E).
- Page 6 Attach the Seat Base (D5) to the Back (D2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 2 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 5 -...
- Page 7 Attach the Side Panel (D4) to the Seat Base (D5)& Side Panel (D3)& Back (D2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 6 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 6 -...
- Page 8 Attach the Left Armrest (D1) to the Seat Base (D5)& Side Panel (D3) & Back (D2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 6 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 7 -...
- Page 9 Tighten all 16 Screws into place with Allen Key (F). NOTE: IF ANY SCREW HOLES CANNOT BE ALIGNED, LOOSEN ALL THE SCREWS AND GO BACK STEP 1 AND RESTART ASSEMBLY. Place the sofa on a level surface, and put Seat Cushion (D6)& Back Cushion (D7) on the Sofa.
- Page 10 COMPONENT LIST - RIGHT CORNER SOFA Item Reference Description Qty. Image Right Armrest Back Side Panel Side Panel Seat Base Seat Cushion Back Cushion M6X35 Head Cap Screws Washer Allen Key - 9 -...
- Page 11 NOTE: Do NOT tighten any screws fully first until you have tightened all the screws. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned, loosen the screws and tighten sequentially. If the Corner sofa is not stable it could lead to damage to the product. Attach the Side Panel (C3) to the Seat Base (C5) by securing with M6*35 Head Cap Screws (D) and Washers (E).
- Page 12 Attach the Seat Base (C5) to the Back (C2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 2 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 11 -...
- Page 13 Attach the Side Panel (C4) to the Seat Base (C5)& Side Panel (C3) & Back (C2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 6 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 12 -...
- Page 14 Attach the Right Armrest (C1) to the Seat Base (C5)& Side Panel (C3) & Back (C2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 6 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 13 -...
- Page 15 Tighten all 16 Screws into place with Allen Key (F). NOTE: IF ANY SCREW HOLES CANNOT BE ALIGNED, LOOSEN ALL THE SCREWS AND GO BACK STEP 1 AND RESTART ASSEMBLY. Place the sofa on a level surface, and put Seat Cushion (C6)& Back Cushion (C7) on the Sofa.
- Page 16 COMPONENT LIST - TABLE Item Reference Description Qty. Image Side Panel Side Panel Side Panel Side Panel Table Top Suction Cup Glass M6X35 Head Cap Screws Washer Allen Key - 15 -...
- Page 17 NOTE: Do NOT tighten any screws fully first until you have tightened all the screws. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned, loosen the screws and tighten sequentially. If the Table is not stable it could lead to damage to the product. Attach the two Side Panels (G1&G2) to the Table Top (G5) by securing with M6*35 Head Cap Screws (D) and Washers (E).
- Page 18 Attach the two Side Panels (G3&G4) to the Table Top (G5) & Side Panels (G1&G2) by securing with M6*35 Head Cap Screws (D) and Washers (E). Do this in 12 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 17 -...
- Page 19 Tighten all 16 Screws into place with Allen Key (F). NOTE: IF ANY SCREW HOLES CANNOT BE ALIGNED, LOOSEN ALL THE SCREWS AND GO BACK STEP 1 AND RESTART ASSEMBLY. Turn the Table over and place on a flat surface, then place the Scution Cup (G6).
- Page 20 Put the Glass (G7) on the table Top (G5), now your table is ready for us. - 19 -...
