ARPEGE SECURITY AS 5500 Technical Manual

Banknote counter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TECH. MANUAL
AS 5500
BANKNOTE COUNTER
TECH. MANUAL
2022.09 Version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS 5500 and is the answer not in the manual?

Questions and answers

Related Manuals for ARPEGE SECURITY AS 5500

Summary of Contents for ARPEGE SECURITY AS 5500

  • Page 1 TECH. MANUAL AS 5500 BANKNOTE COUNTER TECH. MANUAL 2022.09 Version...

  • Page 2: Table Of Contents

    § HOW TO USE THE FEATURE OF UV-DETECTION ......9 § PRECAUTIONS .................. 11 § REGULAR MAINTENANCE ............... 11 §TROUBLE SHOOTING ................ 12 § TECHNICAL DRAWING ..............17 § PARTS LIST ..................27 ARPEGE SECURITY 359 rue Vanderkindere,1180Bruxelles,Belgique Email: info@arpege-security.com www .arpege-security.com § SPECIFICATIONS OF THE BANKNOTE COUNTER MODEL TC-5500 (Desktop) / TC-5500S (Floor Stand) ※...

  • Page 3: Function Of The Banknote Counter

    TECH. MANUAL 6) UV-Detection(Optional) : Detect & Select Out the Counterfeit Banknote ※Specification TC-5500 TC-5500S (Desktop) (Floor Stand) 1) Dimensions(mm) WxDxH 374 x 374 x 260 374 x 374 x 830 2) Net Weight (kg) 3) Power Supply 110V,AC10% 60Hz or 220V,AC10% 50Hz 4) Power Consumption 330W 5) Temperature Limits in Use...
  • Page 4 TECH. MANUAL ※ The Display Number  The counting result will show on the LED screen. The lowers part was the accumulated number, it will show counting result when the user selecting this ACC function ※ The Check Function Key ...
  • Page 5 TECH. MANUAL Preset ※ The Function Key  This function is designed to fix the number of banknote which be counted. It will count the correct piece as you set. The preset number will be showed at the display screen of the control panel. ※...

  • Page 6: How To Operate The Banknote Counter

    TECH. MANUAL § HOW TO OPERATE THE BANKNOTE COUNTER Check ※ The Function:  Step 1: Turn on the power switch and the machine will come into the status of Check Mode automatically. The buzzer will alarm and open the banknote holder. The LED display will show the number of “0”...
  • Page 7 TECH. MANUAL  Step 3: Putting the banknotes into the banknote holder and forwarding the banknote to touch the starting sensor.  Step 4: The machine will count automatically. The counting result should be correct as user preset on the LED display. ...
  • Page 8 TECH. MANUAL ※ The Self-Diagnosis Test Function : Function: This function is designed for checking the system's: 1) Vacuum Pressure, 2) LED display, 3) Spindle Sets, 4) Counter Sets, 5) Motors banknote counting and feeding process.  Step 1: User need to block the holes of Spindle Sets by adhesive plastic tape. And selecting the function key of 0 after power on.

  • Page 9: The Optional Feature

    TECH. MANUAL § THE OPTIONAL FEATURE ※ The Stamping Function : Function: This function is designed for checking the batched banknote of 100 pieces. It will punch a stamping mark (OK) on first banknote if the number of banknote is exactly 100 pieces. ...

  • Page 10: How To Use The Feature Of Uv-Detection

    TECH. MANUAL § How to Use the Feature of UV-Detection The vast majority of the world’s bank notes are printed a high quality, linen-based paper, which has low fluorescence characteristics. Because the majority if counterfeit notes are printed on normal quality papers, which have been bleached and therefore fluoresce, UV detection is normally the most useful method of helping to find forged bills at the speed at which a currency counter operate.
  • Page 11 TECH. MANUAL  Step 3: If the perfectly band, for example band 1 can count genuine note and catch the counterfeit note perfectly then you can use this band for this particular note. Otherwise you must change the band to 2 … 8. (That means the user has eight bands to find the best suitable band for each particular note.) Note: Following information was for Technicians Only.

  • Page 12: Precautions

    TECH. MANUAL § PRECAUTIONS (1) Please check your AC Voltage; it should be the same as the Voltage specification showed on the back sticker of our Banknote Counting Machine. (2) Disconnect the AC cord and inform the qualified engineers for repairing our banknote counter if there is any technical trouble or damage on our machine.

  • Page 13: Trouble Shooting

    TECH. MANUAL §TROUBLE SHOOTING 1. No power enter into the machine (1) Power supply (B041) was damaged.  Check power supply (B041) and plug. (2) Fuse was damaged (Fuse is hidden in the 2-in-1 Power Switch D026).  Replace a new fuse. (3) The cable between pump and power supply was damaged.
  • Page 14 TECH. MANUAL (7) Pump (E001) stuck.  Turn off the machine, and use screw driver to troll the pump’s fan.  If it still stuck, take off the pump’s cup and swirl the pump’s fan by tools. 4. Pump does not run or lack of pressure. (1) Pump (E001) stuck.
  • Page 15 TECH. MANUAL 7. Inaccuracy in counting process (1) Counter Set (A035) didn’t in a perfect adjustment condition.  Micro adjustment: adjust counter set screw in counter clock wise (CCW) for lower sensitivity to resolve “more counting” problem or clock wise for higher sensitivity to resolve “miss counting”.
  • Page 16 TECH. MANUAL d. Check the air blow pipe position should between its second hole and the banknote holder. e. Check the banknote flipping plate position. To keep away from the main roller spindle set holes be vertically lined up. (7) The incorrect air blowing direction. ...
  • Page 17 TECH. MANUAL 8. Banknote holder does not open after turn on power. (1) Micro switch (C028) was damaged.  Adjust it or replace a new one. (2) Main control board (D031) was damaged.  Check or replace the board. (3) Extension spring (C007) was loosed. ...

  • Page 18: Technical Drawing

    TECH. MANUAL § TECHNICAL DRAWING...
  • Page 19 TECH. MANUAL...
  • Page 20 TECH. MANUAL...
  • Page 21 TECH. MANUAL...
  • Page 22 TECH. MANUAL...
  • Page 23 TECH. MANUAL...
  • Page 24 TECH. MANUAL...
  • Page 25 TECH. MANUAL...
  • Page 26 TECH. MANUAL...
  • Page 27 TECH. MANUAL...

  • Page 28: Parts List

    TECH. MANUAL § PARTS LIST Part No. Part Name 孔塞 A001 TCG0102215-1 Spindle plug 白鐵濾網 A002.1 TCG0101114 Spindle filter mesh 偏心軸(兩截式白色橢圓) A003.6 TCG0102245 Eccentric shaft 防塵片 (小) A004 TCG0102212 Dust sheet 圓盤 A005 TCG0102211 Disc flat 培林 6002 (大) A006 TCG0102218 Bearing 6002 培林...
  • Page 29 TECH. MANUAL Part No. Part Name DC 後馬達固定板(有刷)(無惰 A045 TCG0101117 Back motor fixed plate 輪) Part No. Part Name 5500 上底板 B001 TCG0100301-06 Upper plate Membrane keypad - gray in 薄膜按鍵(中文 灰 ) B003.1 TCG0101402 Chinese Membrane keypad - gray in 薄膜按鍵(英文...
  • Page 30 TECH. MANUAL Part No. Part Name 黑紙卡-軋方形簍空 P038(含刀 TCG0102604 Black paper B025 模)9.2x7.8 簍空 6.6x2.8 配線線組 TQU-32-01 B026.1 WA254TQU32-02 Cable accessory TQU-32-01 配線線組 TQU-33-01 B027 WA254TQU33-01 Cable accessory TQU-33-01 外接盒外蓋 B034 TCG0102226 Front case of external display 外接盒本體 B035 TCG0102227 Rear case of external display 外接盒配重片...
  • Page 31 TECH. MANUAL Part No. Part Name 微動開關 1P 固定座 C026-1 TCG0102501 1P micro-switch fixed plate 33x76x3mm(鍍鋅) BMN2-0505D 250V/5A 12mm C028 MS01250026 Micro-switch 0505D (100g) 100gf 電晶體墊片 C029 TW-1 Transistor washer 打印組電磁閥固定座 C030-2 TCG0103507 Solenoid valve bracket 夾鈔板組(調白細銀織紋) C034 TCG0010022 Banknote gripper set 夾鈔桿打印組...
  • Page 32 TECH. MANUAL Part No. Part Name BFS-MFG-15A(PF) 保險絲 5*20mm 快斷 UL,CSA D015.3 Fuse (15A) 保險絲 5*20mm7A 快斷 D015.4 BFS-MFG-7A(PF) Fuse (7A) 塑膠外殼檔片方型 D016 TCG0101551-01 Blocker of power socket (square) Blocker of power socket 長方形檔片 D017 TCG0101553 (rectangle) 上蓋附件 D018 TCG0150100 Cover for power socket 電路控制板支架...
  • Page 33 TECH. MANUAL Part No. Part Name 塑膠外殼 370x370x260mm F004 TCG0101502 Plastic cover TC-5500 方轉輪 F006 LP-50TPR Wheel Part No. Part Name G001 SC18000308 PTS-1 3x8NI Screw PTS-1 M3x8NI G002 SC13000306 TMS M3x6NI Screw TMS M3x6NI G003 PIN2500018 PIN 2.5X18 PIN 2.5x18 G004 SC12000800 E-Ring M8BK...
  • Page 34 TECH. MANUAL Part No. Part Name SPW 8∮x13∮x1.5Z G037 SC11081315 Spring washer 8x13x1.5Z G038 SC10822215 PW 8.2x22x1.5Z Washer 8.2x22x1.5Z G039 SC06000215 PMS M2x15NI Screw PMS M2x15NI 螺母 NUT M2NI G040 SC07000200 Nut M2x4NI G041 SC12000900 E-RING M9NI E-ring M9NI G042 SC05000315 ISO/W M3x15NI Screw ISO W M3x15NI...
  • Page 35 TECH. MANUAL Part No. Part Name P/N:RESET 3M 背膠 H061 P0251 Sticker (reset) 壓克力面板(茶色透明) H082 TCG0103004 Acrylic panel 管束 H091 A0003 Hose clamp 104 電容 H098 P0226 104 Capacitor...
