Sermatec HV5120 User Manual

Lfp storage system

Advertisement

Quick Links

LFP Storage System

HV5120 User Manual

Document No.:
Version:V1.0
1 / 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV5120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sermatec HV5120

  • Page 1: Hv5120 User Manual

    LFP Storage System HV5120 User Manual Document No.: Version:V1.0 1 / 14...
  • Page 2: Table Of Contents

    Contents HV5120 USER MANUAL ......................1 1. SCOPE AND SIGN ........................3 2. PRODUCT COMPONENTS ......................6 2.1.1 PRODUCT MAIN COMPONENTS ..................6 2.1.2 BATTERY SYSTEM PORT ....................7 2.1.3 SYSTEM DIAGRAM ......................7 2.1.4.ANNOUNCEMENTS OF PARALLEL CONNECTION BEFORE START-UP ........9 2.2 DEFINITION OF COMMUNICATION PIN SOCKETS ............10 2.3 PACKAGE ..........................
  • Page 3: Scope And Sign

    1.2 This manual includes important description given below: The installation and usage of HV5120 storage product must follow this manual. The design of the product and the tests are based on the global safety requirements. But same for all the electricals, you must follow some prevention strategies during installation and operation.
  • Page 4 Sign l Be Careful of Electric Shock! Sign Don’t put the system beside inflammables. Sign Don’t connect +/- reversely. Sign Don’t put the system beside fire. Sign Isolate the system from children and pets. Sign Recycle Sign Waste Electrical and Elecctronic Equipment (WEEE) Command Sign (2012/19/EU) Sign...
  • Page 5 12)Direct or indirect damage due to above items, is not included in Sermatec warranty. 13)It is not allowed to insert foreign matter to any part of the battery.
  • Page 6: Product Components

    1)Please firstly check the product and pack list after opening the case. If there is any damage or missing, please contact local dealer. 2)Before installation, please make sure that grid power is cut off, and make sure that the battery is at ‘Off’...
  • Page 7: Battery System Port

    2.1.2 Battery System Port Communication Power Output Power Switch Display, Status Indicator, WiFi indicator, Alarm Indicator 2.1.3 System Diagram 7 / 14...
  • Page 8 Model Type HV5120 Battery Cell Battery Energy(kWh) 20.48 25.60 30.72 35.48 40.96 Battery Voltage(Vdc) 204.8-409.6 Battery Capacity(AH) Module Number(pcs) Module Energy(kWh) 5.12 Module Voltage(Vdc) 51.2 Module Capacity(AH) Cell Number(pcs) Charging Voltage(Vdc) Nominal Charging Current(A) Suggested Charging Current(A) Charging Current(A, Max.@15S) Cut-off Discharging 189.6...
  • Page 9: Announcements Of Parallel Connection Before Start-Up

    1)Controller Dimension (W*D*H, mm) 570*352*183 2)Module Dimension 570*352*182.5 (W*D*H, mm) 590*363*72.5 3)Pedestal Dimension (W*D*H, mm) 2.1.4 Announcements of parallel connection before start-up 1. Install and pile the batteries correctly, and then turn the switch to ‘ON’ position, start up the batteries.
  • Page 10: Definition Of Communication Pin Sockets

    2.2 Definition of communication pin sockets RS485 Baud 500K Default 19200 Default Rate Description CANH RS485A CANL RS485B CAN: Communication Terminal:(RJ45 port) Follow CAN Protocol, used for communication between battery and inverter. RS485: Communication Terminal:(RJ45 port) Follow RS485 Protocol , used for communication between battery and inverter 10 / 14...
  • Page 11: Package

    LV3584 LFP Battery Interface Description Name Label Function Description Grounding Port Used for Battery Grounding Power Switch, while at ‘ON’ status, system started up; While at ‘Off’ Switch status, the system cannot be started up, cannot output power. When switch is at ‘ON’, the RUN RUN Indicator indicator would be ‘ON’.
  • Page 12: Product Electrical Character

    Outer Accessory List Accessory Name Specification Figure + Outer Power Cable Orange/3m/4AWG/SURLOK Connector/25-8 Connector - Outer Power Cable Black/3m/4AWG/SURLOK Connector/25-8 Connector Outer CAN Black/3.0m/STP/Two-Side RJ45 Communication Cable Connector 3. Product Electrical Character 3.1 Module Specification Parameter Specification Remark 3.1.1Nominal Voltage 51.2V Typical:104Ah Charge normally and lay 0.5-1h,...
  • Page 13: Management System (Bms) Function

    4. Management System (BMS) Function BMS has following function: Over-charging protection, over-discharging protection, high-voltage protection, low-voltage protection, charging over-current protection, over-temperature protection, low-temperature protection, short-circuit protection, battery cell balance function. 5. Product exterior Requirement Battery exterior keeps clean, and installer need to firstly clean dusts and scrap iron before installation and power on.
  • Page 14: Regular Maintenance

    Fire Alarm Number. If the destroyed batteriesthe recycling process shall follow the local rules to achieve the recycle of related items. If there is any further question, please contact us. Shanghai Sermatec Energy&Technology Co.,Ltd. Address:1388 Xindian Road, Jiading District, Shanghai, China Phone No.:+86 021-69986891 Product Demand Email:presales@sermatec-ess.com...
