LFP Storage System

LV3584 User Manual

Document No.:
Version:V1.0
1 / 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LV3584 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sermatec LV3584

  • Page 1: Lv3584 User Manual

    LFP Storage System LV3584 User Manual Document No.: Version:V1.0 1 / 16...
  • Page 2: Table Of Contents

    Contents LV3584 USER MANUAL ..........................1 1. SCOPE AND SIGN ............................3 2. PRODUCT COMPONENTS ........................7 2.1 PRODUCT MAIN COMPONENTS ......................7 2.2 BATTERY SYSTEM PORT ........................7 2.3 SYSTEM DIAGRAM ..........................8 2.4 ANNOUNCEMENTS OF PARALLEL CONNECTION BEFORE START-UP ........10 2.5 BATTERY SYSTEM PORT ........................11 2.6 PACKAGE .............................
  • Page 3: Scope And Sign

    1. Scope and Sign This User Manual is to describe the technical indexes of LV3584 Battery Module produced by Shanghai Sermatec Energy & Technology Co.,Ltd.And would be used as the basis of product inspection by Sermatec Quality Department and Client.
  • Page 4 Sign Danger! Careful! Sign l Be Careful of Electric Shock! Sign Don’t put the system beside inflammables. Sign Don’t connect +/- reversely. Sign Don’t put the system beside fire. Sign Isolate the system from children and pets. Sign Recycle Sign 4 / 16...
  • Page 5 Warning: When operate on the batteries, please wear proper Personal Protective Equipment (PPE), e.g. rubber gloves, rubber boots, goggles. Warning: LV3584 system working temperature range: 0℃~50℃; Proper temperature: 18℃~ 28℃. If it exceeds the range, the battery life-cycle might be decreased or even cause battery system over/low temperature warning or protection.
  • Page 6 12)Direct or indirect damage due to above items, is not included in Sermatec warranty. 13)It is not allowed to insert foreign matter to any part of the battery.
  • Page 7: Product Components

    2. Product Components 2.1Product main components Component Specification Figure Battery Box 70Ah 1P16S Low Voltage BMS Maximum Current 125A Pedestal Width 352mm Depth 570mm Height 60mm Orange and Black 1xAWG3,Surlok Power Cables Connector Communication CAN, RS485 communication cable Cable Battery Output Surlok Port 2.2 Battery System Port Communication...
  • Page 8: System Diagram

    2.3 System Diagram Model Type LV3584 Battery Cell Battery Energy(kWh) 7.16 10.75 14.33 17.92 21.5 25.08 28.67 Battery Voltage(Vdc) 51.2 Battery Capacity(AH) Module Number(pcs) Module Energy(kWh) 3.584 Module Voltage(Vdc) 51.2 Module Capacity(AH) Cell Number(pcs) Charging Voltage(Vdc) Nominal Charging Current(A) Suggested Charging...
  • Page 9 Cut-off Discharging 47.4 Voltage(Vdc) Nominal Discharging Current(A) Suggested Discharging Current(A) Maximum Discharging Current(A) Efficiency(%, ≤0.5C-rate) Depth of Discharge%) 570*352* 570*352* 570*352* 570*352* 570*352* 570*352* 570*352* Dimension(W*D*H,mm) 1005 1161 1317 1473 Communication RS485\CAN Protection Level IP55 Weight (kg) Life Cycle(Years) Working Temperature(℃) 0~50 Storage Temperature(℃) -20~60...
  • Page 10: Announcements Of Parallel Connection Before Start-Up

    2.4 Announcements of parallel connection before start-up 1. Install and pile the batteries correctly, and then turn the switch to ‘ON’ position, start up the batteries. When the batteries are installed wrongly, it would lead to startup error. After starting up the system normally, the batteries would distribute the address automatically.
  • Page 11: Battery System Port

    2.5 Definition of communication pin sockets RS485 Baud 500K Default 19200 Default Rate Description CANH RS485A CANL RS485B CAN: Communication Terminal:(RJ45 port) Follow CAN Protocol, used communication between battery and inverter. RS485: Communication Terminal:(RJ45 port) Follow RS485 Protocol , used for communication between battery and inverter.
  • Page 12: Package

    Used for communication - Input/Output Port “-“ Battery Input/Output - Port + Input/Output Port “+“ Battery Input/Output + Port 2.6 Package LV3584 Box, Inner Dimension: 650mm*430mm*260mm; Outer Dimension: 670mm*445mm*280mm LV3584 Accessory Box,Outer Dimension:600mm*100mm*40mm Battery Dimension:570mm*352mm*156m Accessory List Accessory Name Specification Figure Yellow-Green/1...
  • Page 13: Product Electrical Character

    Accessory Name Specification Figure + Outer Power Cable Orange/3m/4AWG/SURLOK Connector/25-8 Connector - Outer Power Cable Black/3m/4AWG/SURLOK Connector/25-8 Connector Outer Black/3.0m/STP/Two-Side RJ45 Communication Cable Connector 3. Product Electrical Character 3.1 Module Specification Parameter Specification Remark 3.1.1Nominal Voltage 51.2V Charge normally and lay 0.5-1h, Typical:70Ah 3.1.2Nominal Capacity 0.1C...
  • Page 14: Battery Management System (Bms) Function

    4. Management System (BMS) Function BMS has following function: Over-charging protection, over-discharging protection, high-voltage protection, low-voltage protection, charging over-current protection, over-temperature protection, low-temperature protection, short-circuit protection, battery cell balance function. 5. Product exterior Requirement Battery exterior keeps clean, and installer need to firstly clean dusts and scrap iron before installation and power on.
  • Page 15: Regular Maintenance

    8. Regular Maintenance Check the Battery Voltage through Monitoring. Check whether the system voltage is normal or not. For example: Cell voltage is abnormally high/low. 8.1 SOC Check: Use Monitoring system to check Battery System SOC status, and check the battery SOC is normal or not.
  • Page 16 If there is any further question, please contact us. Shanghai Sermatec Energy&Technology Co.,Ltd. Address : 1388 Xindian Road, Jiading District, Shanghai, China Phone No.:+86 021-69986891 Product Demand Email:presales@sermatec-ess.com Technical Support Email: support@sermatec-ess.com 16 / 16...
