- Page 1 GE552Y053 868 MHz Wireless M-Bus Repeater User Manual 06/2021 This manual refers to the 1.15 Firmware version...
-
Page 2: Table Of Contents
Purpose of the document ........................3 Content of the package ........................3 GE552Y053 TECHNICAL SPECIFICATIONS ....................4 ASPECT OF THE GE552Y053 ........................5 Description of the GE552Y053 ......................5 GE552Y053 device ..........................7 WALL MOUNTING AND PASSING OF CABLES .................... 8 USB CONNECTION TO THE PC AND CONNECTION VIA RADIO TO THE GE552Y058 ........ -
Page 3: Introduction
This document is a complete guide for installation, configuration and commissioning of the wireless repeaters/receiver for meters with wireless M-Bus protocol (EN13757-4) Code GE552Y053 hereon called GE552Y053. It is aimed at technical staff with average knowledge of electronics, computers and basic networking principles on TCP/IP and M-bus systems. -
Page 4: Ge552Y053 Technical Specifications
2. GE552Y053 TECHNICAL SPECIFICATIONS GE552Y053 is a repeater and receiver for wireless M-Bus devices. The device’s main technical specifications are given below: Operating Temperature: [ -20..+85°C] • Storage Temperature: [-25..+85°C] • Protection rating: IP40 (EN60529) • Category of Installation: II •... -
Page 5: Aspect Of The Ge552Y053
Along with this functionality it is also possible to add the introduction of a list of wireless M-BUS devices into the GE552Y053 ,which represent a white-list. In this way, if installation takes place in an area where more than 500 wireless M-BUS devices are received, the antenna will only consider the devices under its own competence. - Page 6 Below find the summary of the main operational features, which will be described in this document: Receiver and repeater for wireless M-Bus devices (EN13757-4) • Exceptional radio coverage thanks to multi-hop network architecture (MESH) • Handles up to 500 meters •...
-
Page 7: Ge552Y053 Device
GE552Y053 device Below find an image of the GE552Y053 device with indications regarding its operational parts: A. Cables compartment lid B. LED Figure2–View of GE552Y053 Figure3 – Connections/buttons/LEDs 1. 100..240Vac power supply input (screw clamps) 2. Scan-mode button 3. Button not used 4. -
Page 8: Wall Mounting And Passing Of Cables
4. WALL MOUNTING AND PASSING OF CABLES Before making any connection, remove the power supply, complete the wiring, close the lid of the device and the power the Repeater. 1. Hole for upper fixing screw 2. Pre-hole for lower fixing screw 3. -
Page 9: Usb Connection To The Pc And Connection Via Radio To The Ge552Y058
5. USB CONNECTION TO THE PC AND CONNECTION VIA RADIO TO THE GE552Y058 Figure5 - Connections GE552Y053 repeater devices are supplied with MESH id=1 and channel 13;make sure that all repeaters and/or GE552Y058 have the same MESH id and radio channel through the GE552Y056 software. -
Page 10: Configuration Of The Repeaters Network
1. Power GE552Y058, wait for start-up, connect to the WEB interface and start scanning antennas and devices following the product manual. 2. Power the first GE552Y053 device to be installed and move to a minimum distance of 5 m from the GE552Y058 3. -
Page 11: Troubleshooting
• the radio signal is not too attenuated by reinforced concrete/metal walls Check that the devices not reached are in the list loaded into the GE552Y053 or that the list of • the MBUS wireless devices that can be received by the GE552Y053 is not blocked Attention: some WMBUS devices also transmit with intervals of several hours •... - Page 12 Fax. +39 0322 923255 consulenza.prodotti@giacomini.com This document provides only general indications. Giacomini S.p.A. may change at any time, without notice and for technical or commercial reasons, the items included herewith. The information included in this technical sheet do not exempt the user from strictly complying with the rules and good practice standards in force.
