- Page 1 ® MT-700.1 MT SERIES MT-1000.1 MT-1500.1 MONOBLOCK AMPLIFIERS MT-2000.1 Installation Guide Specifications...
-
Page 2: Power Connections
Power Connections An external fuse must be added to the Positive (+) wire. Refer to the Specs for the correct size fuse. Remote Turn-On from head unit or line output converter (LOC) Signal Connections Adjust bass level remotely from the driver’s seat. - Page 3 Amplifier Controls 1. Protect LED [PRT] 6. Low Pass Filter [LPF] Red when amplifier is A low pass crossover for the powering up or in Protection subwoofer output. Variable Mode. See Troubleshooting from 40Hz to 180Hz.Generally for more information. set around 80Hz. Power LED [PWR] Blue when amplifier is ON.
- Page 4 MT-2000.1 Specs RMS Power Ratings listed at less than 1% THD @ 14.4v 1Ω 2000W X 1 2Ω 1500W X 1 800W X 1 4Ω Bridged RMS Rating / 2Ω Minimum 3800W x 1 Signal to Noise (@ CEA Standard) -93dB Input Sensitivity 0.2-6v...
- Page 5 MT-1500.1 Specs RMS Power Ratings listed at less than 1% THD @ 14.4v 1Ω 1500W X 1 2Ω 1000W X 1 550W X 1 4Ω Bridged RMS Rating / 2Ω Minimum 2800W x 1 Signal to Noise (@ CEA Standard) -93dB Input Sensitivity 0.2-6v...
- Page 6 MT-1000.1 Specs RMS Power Ratings listed at less than 1% THD @ 14.4v 1Ω 1000W X 1 2Ω 700W X 1 4Ω 400W X 1 Bridged RMS Rating / 2Ω Minimum 1800W x 1 Signal to Noise (@ CEA Standard) -93dB Input Sensitivity 0.2-6v...
- Page 7 MT-700.1 Specs RMS Power Ratings listed at less than 1% THD @ 14.4v 1Ω 700W X 1 2Ω 500W X 1 4Ω 300W X 1 Bridged RMS Rating / 2Ω Minimum 1200W x 1 Signal to Noise (@ CEA Standard) -93dB Input Sensitivity 0.2-6v...
- Page 8 LIMITED WARRANTY Stinger warrants this product to be free of defects in materials and workmanship for a period of one (1) years from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Stinger dealer in the United States of America only.
