- Page 1 A3 Multi-Function Copier Quick Start Guide Avision Inc.
-
Page 2: Table Of Contents
Table of Contents Removing the Box and Packing Material ......1 Removing the Tapes and Latch ......... 3 Install the Toner Cartridge ..........4 Install the Developing Unit ..........5 Install the Drum Unit ............8 Raise the Paper Stopper ..........10 Releasing the Lock Switch .......... -
Page 3: Removing The Box And Packing Material
Removing the Box and Packing Material Open the carton with a utility knife, and Remove four box supports. then take out all the accessories [including (1)Developing Unit, (2) Power Cord/CD, (3) Drum Unit, (4)Toner Cartridge, as shown in below: 3. Remove all buckles on the sides of the Pull the printer box upward. - Page 4 5. Check all items against the check list. If anything missing, contact your authorized distributor. Item Quantity MFP main unit Drum unit Toner Cartridge Developing unit Power Cord USB Cable DVD-ROM (driver and manual) Warranty Card Quick Installation Guide（This Document) ...
-
Page 5: Removing The Tapes And Latch
Removing the Tapes and Latch Pull the Paper Tray and remove the Pull down the manual tray and remove the tape. tapes on the Tray. Open Side Door and remove the tapes on the fuser. Remove the Latch and its instruction sheet by pressing the bolt with one hand and pulling the latch with the other hand as shown in below. -
Page 6: Install The Toner Cartridge
Install the Toner Cartridge WARNING! Be careful not to inhale toner. To avoid print quality problems, DO NOT touch the toner rollers. If toner gets on your clothing or other fabric, wipe off the toner with a dry cloth. -
Page 7: Install The Developing Unit
Install the Developing Unit Caution! To prevent damage to the Developing Unit, do not expose it to light for more than a few minutes Pull the handle down to open the Side 2. Open the paper guide latch in a Door as shown. - Page 8 Open the handle of the developing unit Remove the tape , protective and hold the handle with both hands, film , and the plugs on both as shown in the figure below. sides. Important：Do not remove the transparent plastic protective cover on the surface of the developing unit as shown in the figure to avoid...
- Page 9 Close the Side Door and then the Pull down the latch of the paper guide Manual Tray as shown counterclockwise to restore the latch of the paper guide to its original status.
-
Page 10: Install The Drum Unit
Install the Drum Unit Remove the plastic bag, tape , and Open the side door by pulling the handle as shown. then press down the Release Arms to pull out the protective film . Pull up the Release Arms on both Holding the handle of the Drum Unit, ends. - Page 11 Close the Side Door and then the Manual Tray as shown.
-
Page 12: Raise The Paper Stopper
Raise the Paper Stopper According to your paper length, raise its paper stopper. Releasing the Lock Switch The product is designed with a lock switch to protect the machine from damage during transportation. As a result, before using the product, please move the lock switch to the [Unlocking position], otherwise the product may not work. -
Page 13: Load Paper Into The Main Tray
Load Paper into the Main Tray Fan your paper first to ensure that the Align the edges of the documents pages do not stick together. by tapping the bottom of the stack against the table top. Rotate the stack 90 degrees and repeat. Pull out the main input tray. - Page 14 Unlock the length guide, squeeze the Load the paper stack face bottom of the [Length guide tab] Note the print side face up inward as shown, and slide the guide single-sided printing. to the correct position for the paper size being loaded. Pull back the main tray.
- Page 15 Load Paper into the Manual Tray: Pull out the manual tray extension Open the manual tray by grasping to meet your paper size. the handle and pull it down. Fan your paper first to ensure that Align the edges of the documents the pages do not stick together.
-
Page 16: Connect To Power
Connect to Power Connect one end of the power cable Press the Power button on the to the power jack of your product. bottom of the Control Panel to Connect the other end to an turn on the machine. appropriate power outlet. Connect to a Wired Network Connect one end of your network Connect the other end to the LAN... -
Page 17: Specify A Static Ip Address
Obtain the Product’s IP Address: Tap [More Settings] on main screen and then choose [Show Machine Status], the IP address can be found. Specify a Static IP Address Tap [More Settings] on main screen Tap the「Tools」tab to prompt the and then choose [Show Machine 「Tools」page. -
Page 18: Install The Printer Driver
Install the Printer Driver Windows System Requirements: Windows 7, Windows 8, Windows 10, Windows 11 Note: The printer driver includes the following programs: the scanner driver, Capture Tool (Scanning Tool), and Printer Status Monitor. After the printer driver has been installed, the scanner driver, Capture Tool and Printer Status Monitor programs are also installed on your computer. - Page 19 Hardware」screen appears, click [Next] to continue. If you have successfully installed the printer’s driver, you will find a printer, 「Avision AMXXXX Printer」, has been added in the 「Printers and Faxes」option from the Control Panel. (xxxx indicates model name) Network Interface Users...
- Page 20 4. When the Finish dialog box appears, choose 「Finish」to complete. If you have successfully installed the printer’s driver, you will find a printer, 「Avision AMXXXX NetWork」, has been added in the 「Printers and Faxes」 option from the Control Panel. (xxxx indicates model name) Uninstalling the Scanner Driver and Printer Driver From the 「Start」menu, select 「All Programs」, 「Avision...
- Page 21 Copyright © 2022 All Rights Reserved. Avision Inc.
