  • Page 1 Owner’s Manual MN312R Replacement Mirror Navigation System v1.12.11...

  • Page 3: Table Of Contents

    Contents Contents Welcome Statement & Warnings What’s in the Box Product Overview Installation Rydeen GPS Configurations Operating modes ........................15 Startup screen: The Navigation Menu..................16 Navigating to an address ......................17 Navigating to a POI ........................19 Map screen ...........................21 Device System Settings Language Settings ……………………………………………………………………………………..23...

  • Page 4: Welcome Statement & Warnings

    Before making any maneuvers (for example, a U-turn or a left turn) suggested by the MN312R system, please be sure that such a maneuver can be completed legally and safely. Do not follow route suggestions that could put you or your vehicle in a potentially unsafe or illegal circumstance.
  • Page 5 ONLY WHEN VEHICLE IS COMPLETELY STOPPED AND IT IS SAFE to do so. Be sure the MN312R unit is securely attached to the windshield of your vehicle  with the supplied bracket.

  • Page 6: What's In The Box

    What’s in the Box 2. What’s in the Box Your MN312R system comes complete with everything you need to get set up and get going. Please take a moment to review the contents of your system. MN312R Main Cable (Connector A)
  • Page 7 What’s in the Box VSM-AD VSM-DN Most Honda CR-V, Odyssey, Most Hyundai & Kia Dodge Challenger, Charger VSM-F VSM-G VW - PASSAT / JETTA / GOLF, Chrysler AUDI - A6 / A4 VSM-H VSM-HS MN-Adapter Smart Sprinter MN-Mount Adaptor...

  • Page 8: Product Overview

    Product Overview 3. Product Overview MN312R...
  • Page 9 Description Mirror Reflective Area for Rear Viewing Opening for Photo Sensor for Auto-dimming IR Sensor / Bluetooth Function (not available for MN312R) and Microphone Microphone for Bluetooth Function SHORT PRESS – Mute Sound Mute/Audio Button LONG PRESS – Open Volume / Music Control Main Screen SHORT PRESS –...
  • Page 10 Product Overview BACK Description SPEAKER 2.5W Built-in Speaker BRACKET CHASSIS Attaches to Vehicle Specific Bracket Here Connector A Main Connector Connector B Second Connector for Audio Connection Dimming Photo Sensor For the model with auto-dim function only (Optional) CABLE Description Connector A BATTERY(YELLOW) 12V+ Constant power supply...
  • Page 11 Product Overview...
  • Page 12 Bare Green Temp sensor Send Connector Black Temp sensor Receive Connector Wireless Remote Controller: *Optional item (sold separately) Contact Rydeen (Toll-Free 1-877-777-8811) for more details. Description Operation Function Number Long Press Power On / Off Screen On / Off Camera (Video Input) Screen >> Previous Power Screen >>...

  • Page 13: Installation

    Rydeen Mobile Electronics at 1-877-777-8811, so that we can assist you. • Dropping your MN312R unit or subjecting it to excessive shock and vibrations as this may cause it to malfunction and is not covered by warranty.
  • Page 14 Installation Most vehicles have the mirror mounted directly onto the glass; therefore improper tools or techniques used in the installation could result in a damaged or broken windshield. Rydeen is not responsible for damages to windshield caused by installation processes.
  • Page 15 Box is sold separately and service activation is necessary. Contact Guidepoint Systems Inc. for more information (Toll-Free 1-877-477-3463). Note Connector B: Pin 11 & 12 are for temperature sensor connections. Please contact Rydeen Tech Support (Toll-Free 1-877-777-8811) for more details.
  • Page 16 Installation Temperature Sensor installation locations (Suggested Installation locations for Optional Temperature Sensor for optimum sensitivity) Sensor Sensor location for location for outside temperature vehicle’s cabin temperature...

  • Page 17: Rydeen Gps Configurations

    5. Rydeen GPS Configurations Operation Mode When MN312R is started the first time, you need to select whether to start the program in Simple mode or in Advanced mode. The two operating modes of MN312R mainly differ in the menu structure and the number of available features.

  • Page 18: Startup Screen: The Navigation Menu

    Device System Settings Startup screen: the Navigation Menu After selecting Simple mode, the Navigation menu will appear. From here you can reach other selections of the MN312R. The Navigation menu contains the following options: to specify an address as your destination.

  • Page 19: Navigating To An Address

    Device System Settings Navigating to an address In the Navigation menu, tap By default, MN312R proposes the country/state and settlement where you are. If needed, tap the button with the name of the country/state, and select a different one from the list.
  • Page 20 Device System Settings Navigating to an address Enter the street name: Start entering the street name on the keyboard. Get to the list of results: After entering a couple of characters, the names that match the string will  appear in a list. to open the list of results before it appears automatically.

  • Page 21: Navigating To A Poi

    Device System Settings Navigating to a POI On the Map screen, tap to return to the Navigation menu. In the Navigation menu, tap Select the area around which the POI searched for: : The POI will search the area by the given address. ...
  • Page 22 To list all POIs in a given POI group, tap  MN312R will list down the results, you can change the list order by pressing button. Tap the desired POI on the list. The map will appear with the selected point in the middle. Tap from the Cursor menu.

  • Page 23: Map Screen

    Device System Settings Map screen The most important and often used screen of MN312R is the Map screen. The map looks similar to a conventional road-map. The blue arrow represents your current position, and the orange line shows the recommended route.

  • Page 24: Device System Settings

    Device System Settings 6. Device System Settings Tap Exit button to go to the Main Menu Screen Starts Rydeen Navigation Opens the mirror Settings screen Tap the arrow button to return to the previous screen...

  • Page 25: Language Settings

    Device System Settings Language Settings This screen lets you select the language to be used for system screen displays. Brightness (Backlight) Settings This screen lets you determine the brightness of the screen.

  • Page 26: Date-Time Settings

    Device System Settings Date-Time Settings This screen lets you select your time zone and set the date and time. System & Touch Screen Calibration From the main menu screen, select the System icon to see the system info as shown below. This screen displays information about the device.

  • Page 27: Map Update And Navigation Software Launch Path Selection

    Device System Settings Map Update and Navigation Software Launch Path Selection Tap “Map Update” to go to next screen Tap search icon to find the map file Tap “Update” to update map automatically  After Update success, please go to “Navi Path” to select the Navigation Path Launcher.(Following steps)
  • Page 28 Device System Settings Tap arrow pointing down to go to next screen Tap “NAVI PATH” to enter the Software Launch Path setting screen Tap the “X” to exit out of the screen. Tap the file name to confirm and select the NAVIGATION PATH Launcher...

  • Page 29: Music And Volume Settings

    Control Menu Screen will show the following. Follow the procedures below to operate your SD Music Player. Create a folder on your Micro SD card. Insert the Micro SD card to your MN312R card slot. Select Select Tap and Song will play...
  • Page 30 Quit Screen Follow the procedures below to operate your BT Music Player. Connect your mobile phone with your MN312R via Bluetooth. Start music player application in your mobile phone and select music, music will start to play automatically through MN312R.
  • Page 31 Music and Volume Settings Short Press the MUTE Button again to go back to Previous Screen. To select more sound control options, please follow the steps below. Select “Audible Touch Tones” to able/disable the “click” sound. Select “Audio Line-Out” to allow Audio Line Out to turn on (this action turns off the audio from internal speaker of the mirror and use the vehicle’s speakers ONLY if auxiliary connectors are connected.

  • Page 32: Handsfree Bluetooth Operation

    “LINK” icon to connect your phone. 7. Select ‘RYDEEN’ on your phone, and it will ask you to enter the pairing code used by the mirror unit. (The default code is 0000) Once the code is...
  • Page 33 Handsfree Bluetooth Operation 8. Depending on the model of your phone, it may offer you the option of connecting to the mirror unit whenever the mirror unit is on and in range (approximately 10 feet, up to 30 feet distance) of your phone. If you do not select this feature, you will need to manually connect your phone to the mirror unit, either by using your phone’s menu to select and connect, or by using the ‘Paired Devices’...
  • Page 34 Handsfree Bluetooth Operation Receiving and Ending Calls Answer & Hang-up call can be operated by using the hard key button located on the bottom of the mirror. When you receive a call on a phone that is connected to the mirror unit via Bluetooth, you also will see a pop-up graphic on the mirror unit screen, accompanied by the number of the calling party (if Caller ID is enabled).
  • Page 35 Handsfree Bluetooth Operation  After pressing the “BACK” button, the conversation icon will appear on the bottom right.  The purpose of this is to enable the user to go back to conversation screen to adjust the volume, end call, transfer call, dial, etc. During a call, you have the following options: ...
  • Page 36 Handsfree Bluetooth Operation Note This Bluetooth device can connect ONLY ONE PHONE at a time to ensure the safety of a driver.

  • Page 37: Temperature Display Button Function

    Tele-Mute Function Temperatures Display Button Function 9. Temperatures Display Button Function Please follow Page 13 for the installation instructions of temperature sensor. Long Press the Temperature Display Button (located on the bottom of the mirror), to go to ‘Select Temp Unit’ screen as seen below. If temperature sensor probe is not installed, then the display will show N/A as following.

  • Page 38: Tele-Mute Function

    Tele-Mute Function 10. Tele-Mute Function In order to use the Tele-Mute function, connect Tele-Mute line of MN312R to Tele- Mute control line of car audio system. MN312R is capable of controlling car audio system's audio out by muting the audio output when MN312R is sending audio signal for navigation voice prompts.

  • Page 39: Specifications

    Specifications 11. Specifications Hardware Parameters Frequency 57542 GHz Frequency(1F) 6.2MHz Channel Number 20 channels -160 dBm Tracking sensitivity Positioning Sensitivity 10m 2D RMS ， ， WAAS enable Speed Rate 0.1m/s Date update rate Warm Startup Time 20 Sec (average) Cold Startup Time 50 Sec (average) positioning height ，...

  • Page 40: Maintaining Your Gps

    Rydeen North America Inc. (a manufacturer of “Rydeen" products) warrants this product (MN312R) only to the original purchaser as described following: Warranty Period Rydeen warrants this product for a period of one (1) year from the original purchase date. Warranty Coverage This warranty covers all defects in material and workmanship except as specified below.

  • Page 41: To Obtain Warranty Service

    Any cosmetic damages due to normal wear and tear. g) Any consumable items (such as fuse or batteries). If any problems develop with your Rydeen products during or after the Limited Warranty Period, or if you have any questions regarding the operation or installation of the product, you should contact your Rydeen retailer.

  • Page 42: Fcc Compliance Statement

    FCC Compliance Statement 16. FCC Compliance Statement This device complies with Part 15 of the FCC interference limits for Class B digital devices for home or office use. These limits are designed to provide more reasonable protection against harmful interference in a residential installation and are more stringent than “outdoor”...
  • Page 43 End User License Agreemnet 3.1 In issues not regulated by this Agreement, the jurisdiction of the Republic of Hungary shall be applicable, with specific reference to the Act No. 4 of 1959 on the Civil Code (CC) and to Act No 76 of 1999 on Copyrights (CA). 3.2 This agreement is issued in NOTE TO TRANSLATOR - PLEASE INSERT YOUR LANGAUGE and in Hungarian.
  • Page 44 End User License Agreemnet cases, the User is only entitled to use the security copy if the original media copy of the Software Product has become unsuitable for proper and legal use without any doubt, such state thereof being supported by acceptable proof. 7 Limitations of use 7.1 The User is not entitled 7.1.1 to duplicate the Software Product (to make a copy thereof);...

  • Page 45: Disclaimer

    End User License Agreemnet observing the traffic regulations and rules (e.g. use of obligatory and/or reasonable and suitable security measures, proper and generally expected care and attention in the given situation, and special care and attention required due to utilising the Software Product) is the exclusive responsibility of the User;...

  • Page 46: Index

    Precautions & Warnings • 2 Product Overview • 6 Connectors • 8, 9 Contents • 1 Receiving and Ending Bluetooth • 32 Rydeen GPS Configurations • 15-21 Date-Time Settings • 24 Device System Settings •22 Disclaimer • 43 Software Launch Path Selection • 25 Specifications •...
  • Page 47 Phone: 1-877-777-8811 Fax: 1-310-943-3778 Copyright © 2014 Rydeen North America Inc. All Rights Reserved. RYDEEN ® is a registered trademark of Rydeen North America Inc. These materials are protected by copyright law and international treaties. Any unauthorized use, reproduction or distribution of these materials, or any portion herein, will result in severe civil and criminal penalties and fines.
