ID Tech Kiosk V IDVK-5XX Quick Installation Manual

ID TECH Kiosk V Quick Installation Guide

Mounting the Kiosk V

Warning: The NFC antenna's RF field is sensitive to the proximity of metal. If you must mount the Kiosk V in or
on a metal surface, note the following requirements to minimize the impact on RF performance:
Kiosk V readers must not be installed behind any metal surfaces or materials that have metallic
•
content, which blocks the RF field.
Mount Kiosk V readers a minimum of 2cm away from any metal surface.
•
Keep the RF-emitting surface of Kiosk V readers at least 2cm from any metal.
•
Note: For safety reasons, make sure to mount the Kiosk V at a height no greater than two meters from the
floor.
Kiosk V Part# IDVK-5XX:
Note: The Kiosk V is post-compatible with Kiosk III and Kiosk IV dimensions. Posts are 36mm apart in the
lengthwise direction and 32mm apart widthwise. See drawing below.
Copyright© 2022 International Technologies and Systems Corporation. All rights reserved.
ID TECH
10721 Walker Street, Cypress, CA 90630-4720
Tel: (714) 761-6368 Fax (714) 761-8880
www.idtechproducts.com
15 December 2022
Rev A
